Summary of Contents for Skidata KeyD ANT DUO
- Page 1 Reading Device KeyD 232 DUO KeyD 485 DUO KeyD ANT DUO Manual and operational description...
- Page 2 Copyright © 2004 by SKIDATA AG. All rights reserved. All information in the following document is protected by copyright law. No part of this document may be reproduced without the written consent of SKI- DATA AG. SKIDATA AG reserves the right to make any changes of specification and other information in this document without further notice.
- Page 3 FCC 15.21: IMPORTANT: Any changes to or modifications of KeyDetector DUO unless expressly approved by SKIDATA AG, may void the user's authority to operate this device. FCC only: the DC cable or combined DC/interface cable must be fitted with a ferrite element of type “Würth 74271131” near the lo- cation where the cable connects to the KeyDetector (see image;...
- Page 4 Manual and operational description KeyDetector DUO KeyDetector DUO Document Management – Version Table Tab. 1: Document Version Table for Installation & Maintenance Instructions Section Document Pages Version Date KeyDetector DUO 2004-02-02 Page 4 © SKIDATA AG, February 2004...
- Page 5 KeyDetector DUO KD DUO KeyDetector DUO is the standard interface module for SKIDATA’s keymotion technology. As such it constitutes a connecting link interfacing keycard and Swatch Access data carriers with higher systems and applications. Proximity 122 kHz and 13 MHz transmission technology.
-
Page 6: Pin Description - Desktop Versions
All cables must be fed in vertically to prevent water from leaking in. Adjust cable feed as needed. Note that fixing screws are not included in delivery Figure 3 Cable hole Fixing screw Cable feed hole (desktop version) Break-out for mounting Snap-in latch Copyright by SKIDATA AG 2004... -
Page 7: Deinstalling Keydetector Duo
Power supply voltage TxD/A KeyD: Data out KD Figure 7 TxD/B KeyD: Data in KD Power Ground LEDs red/green/orange Connector for external antenna beeper Connector “power/data 2” Connector “power/data 1” Copyright by SKIDATA AG 2004... - Page 8 (use connector JST-PHR-5 or JST-08KR) Power supply Pin # Signal Function Power Ground Host RS232: Receive Data KD DUO RS232: Transmit Data KD DUO Power supply, 9 to 12 VDC Signal in / out e.g. Door opener e.g. button Copyright by SKIDATA AG 2004...
- Page 9 ... Thus the external antenna must not be placed between the external antenna and a data carrier, data near electrical devices. Also metal surfaces placed transmission will be impossible at all in most cases. Copyright by SKIDATA AG 2004...
-
Page 10: Connector For External Antenna
Version 1.0 • 2003-01-29 • Copyright © 2004 by SKIDATA AG This documentation may contain representations of registered product or service trademarks owned by SKIDATA AG or third parties, as well as references to proprietary know-how protected by copyright laws or other legal provisions.
