PRODUCT MANUAL

Magro RGB-W Wireless LED Wall Controller / Wall Switch

Manual Content

• Product Information

• Product Diagram & Parts

• Product Wiring and Installation

Product Description

Solid Apollo's Magro RGB-W Wireless Controller is a powerful low-profile controller

that gives you full control of your RGB and RGBW LED fixtures either in your hand as

a remote or by directly mounting it on any standard gang box.

Installation is basically effortless. You just have to screw the unit to any free gang box

and it's ready to work. Thanks to its included 3V DC durable battery, there is no messy

cable connections.

The Magro Wireless Controller Switch lets you use it in two different exciting ways: as

a hand-held remote or as a wall controller/switch. The unit is magnetically attached

to the faceplate which makes it easy to detach and carry as a hand-held remote or

dock and use as an in-wall controller.

Product Features

• 1 x Magro Wireless Wall Controller

• 1 x White Wall-Plate

• 4 x 5A Receiver

• Perfectly installs in any standard gang box

• Controls RGB and RGBW LED fixtures

• Separate W and RGB control buttons

• Can be docked or used as hand-held remote

• Full dimming from 100% - 1%

• Impressive 65ft wireless range

• Battery operated (3V DC - CR2025)

• Soft ramping ON/OFF technology

• Easy installation and operation

• Memory function - Remember last

setting before losing power.

• Product Operation

• Product Troubleshooting

Product Specs

Magro RGB-WController

• Dimming :

• Input Voltage :

• Battery Type :

• Weight :

• Control System :

• Frequency :

• Range :

• Dimension :

Receiver

• Input Voltage :

100% to 1%

• Max Power :

3V DC Battery

CR2025 (included)

• Max Amps :

0.12 lb

• Dimensions :

Radio Frequency

• Weight :

916.5 MHz

• IP Rating :

65ft

• Working Temp :

2.6" x 1.2" x 0.37"

• Warranty :

• Certificates :

™

www.SolidApollo.com

Andrew@SolidApollo.com

12V - 36V DC

240W@12V DC

720W@36V DC

4x 5A

7" x 1.8" x 0.87"

0.30 lb

IP20

- 30F - 160F

3 Years

CE, RoHs, UL listed

page 1
