Air Rage Microfighters Instruction Manual

PLEASE! DO NOT RETURN THIS
PRODUCT TO ANY RETAIL STORE!
For any questions or problems with this product please contact us at:
Web site: www.interactivetoy.com
Email: info@interactivetoy.com
Phone: Outside North America: +1 416 444 6873
Inside North America: 1 866 214 2220
Address: Interactive Toy Concepts
1192 Martin Grove Road
Toronto, Ontario, Canada
IMPORTANT SAFETY INFORMATION
Do not modify your Micro Fighter! Do not point the antenna directly at the plane! Do not use in strong winds, use only in 'very'
mild conditions! Do not use in rain, snow or around heavy debris! Do not use near electrical lines! Do not use around smoke or
flames! Do not use around water! Do not use around electricity! Do not use in crowded areas! Do not use around air
conditioning! Do not use around air vents! Do not use around ceiling fans! Do not use around large obstacles! Do not use in very
small spaces! Do be conscious of changes in your area! Any changes or modifications to this product are strictly prohibited and
will void product warranty. Keep moving propellers away from eyes, hands, hair and loose clothing. Always turn off your
Micro Fighter and transmitter when not in use. Always remove batteries from transmitter during storage. Always place transmitter
with NEW alkaline batteries for optimal performance. Keep your Pilots manual in a safe place for future use. Only use the
provided charger included with the Micro Fighter to charge the lithium polymer battery installed in the Micro Fighter.
IMPORTANT BATTERY INFORMATION
Use only batteries recommended in this instruction manual. Do not mix old and new batteries.
Battery installation should be performed by an adult. Be careful to install the batteries with the correct polarity, as indicated.
Do not use rechargeable batteries. Do not mix alkaline, standard, lithium, rechargeable, or different types of batteries.
The supply terminals are not to be short-circuited. Exhausted batteries are to be removed as they will hinder performance.
Never leave a battery unattended while it is being charged. Never leave a battery unattended in the presence of children.
Micro Fighter charging time will increase with usage as the condition of the AA cells diminish. Battery performance may greatly
influence flight characteristics. Micro Fighter's Li-Po rechargeable battery is not replaceable.
Micro Fighter takes 6 AA battery (not included).
FCC NOTE: U.S. ONLY
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference. 2) This device must accept any interference received including interference
that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These Limits are designed to provide reasonable
protection against harmful interference in a residential installation. This generates, uses and can radiate radio frequency
energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try and correct the interference by one or more of the following measures: - Reorient or relocate the
receiving antenna - Increase the separation between the equipment and receiver - Connect the equipment to an outlet on a
circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Notice: Canada only.
This radiocommunication device complies with all the requirements of Industry Canada Standard RSS-310.
Operation is subject to the following two conditions: 1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause undesired operation.
Field Strength and measurement distance: 27.195MHz – ???? dBμV/m at 3 meter. 49.890MHz - ???? dBμV/m at 3 meter.
Avis d'Industrie Canada: Canada seulement
Ce dispositif de radiocommunication rencontre toutes les exigences de la norme CNR-310 d'Industrie Canada. Son fonctionnement est
sujet aux deux conditions suivantes: 1) ce dispositif ne doit pas causer d'interférences nocives et. 2) ce dispositif doit accepter toutes les
interférences reçues, y compris les interférences susceptibles de provoquer un fonctionnement indésirable.
Puissance du champ et distance: 27.195mHz ???? dBμV/m à 3 mètres. 49.890mHz ???? dBμV/m à 3 mètres.
Limited 90-day warranty
This product is warranted by Interactive Toy Ltd. against manufacturing defects in material and workmanship
under normal use for ninety (90) days from the date of purchase.
Lithium Polymer
Rechargeable Batteries
must be recycled or
disposed of properly.
M9W 5M9
AirRage Series and Micro Fighter are registered
trademarks of Interactive Toy Concepts © 2006
All Rights Reserved. Manufactured by and distributed
by Interactive Toy Concepts Ltd. Conforms to Safety
Standards ASTM F963-03 Regulatory Requirements.
Products and colors may vary. MADE IN CHINA.
FCC NOTE:
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user's authority to operate the equipment.
Thank you for purchasing the Micro Fighter, the world's smallest and most progressive digital proportional
radio control aircraft. To insure safe and reliable operation, please read the entire contents of this manual
before removing the aircraft from its package.
IMPORTANT!
Micro Fighter is an advanced aircraft
that uses sophisticated onboard technology
unlike any found in similar vehicles. Even
experienced pilots should read the full contents
of this manual carefully to receive the
most from your flying experience.
Parts Index
MICRO FIGHTER
3
4
1.Propellers
2.Tail stabilize
3.Charge port
4.ON/OFF Switch
1
2
IMPORTANT! To prevent damage during shipping, your Micro Fighter is securely fastened in the
package. Please insure that all tie downs and fastening locations have been unfastened before
attempting to remove the aircraft from its package.
Before You Fly
1. Use a Phillips head screw driver (cross head) to loosen screw
and remove cover.
2. Insert 6AA batteries in the correct polarity as indicated inside the
battery compartment.
3. Place cover back and re-tighten screw.
4. Screw antenna in place.
Charging The Micro Fighter
1. Make sure the power switch of the Micro Fighter is in the OFF position.
NOTE: Always switch OFF the plane after flying!
2. Make sure the controller antenna is collapsed to avoid breaking it while not flying and to prevent
accidentally interfering with another RC aircraft on the same frequency.
3. Remove the charge Lead on the transmitter and insert it into the charge port on the Micro Fighter.
NOTE: Always insure the lead is in the correct orientation.
4. Turn the transmitter switch to the ON position.
5. Green LED will blink indicating plane is now being charged.
6. Charge the Micro fighter fully which typically takes about 30min.
7. Green LED will steady, indicating that the plane is fully charged.
8. Remove Lead and place back inside storage compartment.
9. Turn transmitter OFF, and your Micro Fighter is ready to fly!
NOTE: If you forget to turn off the transmitter and not moving the
control sticks, after 3 minutes the Red LED will start blinking to
remind you to turn it off!
TIP!
Unlike other types of re-chargeable batteries, Lithium Polymer re-chargeable Batteries do not
require a full charge for operates. However, it is necessary to FULLY charge on the first
flights for best results.
*Shorter Charges Times = Shorter Flight Times.
PACKAGE CONTENTS
•Micro Fighter
•Transmitter
•Antenna
•Instruction manual
•Landing gear
Do not touch the running propeller! •Spare Propeller
Adult supervision is required!
•Mylar tape
