Armour39™ Watch

User Manual

Model: A39W01

Table of Contents

Need help?

Do you have a question about the A39W01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Armour39 A39W01

Page 1 Armour39™ Watch User Manual Model: A39W01...
Page 2: Table Of Contents
TABLE OF CONTENTS What Is Armour39™ How Does Work? Armour39™ What Does Measure? Armour39™ System Requirements In The Box Control Buttons Main Navigation Flow Getting Started: Initial Set-Up Date/ Time Set-Up Device Set-Up Proﬁle Set-Up Starting A Workout Workout Screens...
Page 3 Speciﬁcations Precautions About Under Armour® Limited Warranty EU- Declaration Of Conformity FCC/IC- Statement...
Page 4: What Is Armour39
Armour39™ is the ﬁrst system that detects and responds to every move athletes make – any direction, any speed, any position. So every athlete—regardless of sport or workout activity—has precise information...
Page 5: How Does Armour39™ Work
The Armour39™ chest strap, made from the same comfortable, moisture-wicking material that Under Armour® is famous for, collects athletes’ information and transfers it to the Armour39™ module in the strap. The module automatically transmits this information in real-time to a Bluetooth® Smart display device, the Armour39™...
Page 6: What Does Armour39™ Measure
WHAT DOES Armour39™ MEASURE? With Armour39™, athletes of all sports can measure, track, and analyze the data that matters most. Armour39™ measures heart rate, calorie burn, real-time intensity and WILLpower™, Under Armour®’s unique measure that reﬂects overall workout difﬁculty in a single score.
Page 7 IMPORTANT: Armour39™ is optimized by completion of the Armour39™ Assessment workout. The Assessment captures an athlete’s baseline data and informs all other Armour39™ measures, customizing the system speciﬁcally to the athlete. A user should perform the Assessment regularly, about once a month, to ensure the system takes into account an...
Page 8: System Requirements
(Enhanced display and extended calendar of past workouts) NOTE: The Armour39™ Module can only connect to the Armour39™ Watch and Armour39™ Mobile App indepently. (i.e. You cannot use both the Armour39™ Watch and Armour39™ Mobile App as a display during a workout.)
Page 9: In The Box
1X Under Armour® Warranty Card 1X User Manual NOTE: Armour39™ is an application-based system. As such any or all software updates may not be reﬂected in this printed manual. For more information or to access the latest manual for your watch and current...
Page 11: Control Buttons
CONTROL BUTTONS 1] Top (A) Button: Pause workout, Enter sub-screen, Conﬁrm settings. 2] Middle (B) Button: Toggle between displays, Toggle through data. 3] Bottom (C) Button: Exit current display, Return to previous screen, Trigger workout ﬂag. 4] Touch (D): Tap on lens to activate backlight (only viewable at nighttime).
Page 12: Main Navigation Flow
MAIN NAVIGATION FLOW 1A] Top (A) Button: Enter current subsection. 1B] Top (A) Button: Start workout. 2] Middle (B) Button: Toggle between displays. 3A] Bottom (C) Button: Toggle between date and secondary time. 3B] Bottom (C) Button: Enter past workouts calendar (MEM).
Page 13: Getting Started: Initial Set-Up
Complete DEVICE Set-Up to pair your module with the watch. See page 23 for details. See page 30 to learn how to connect your Armour39™ watch with the Armour39™ Mobile App. Remember to complete the Initial Set-Up after every battery NOTE: replacement or reset.
Page 14: Date/ Time Set-Up
DATE/ TIME SET-UP In the TIME Mode of the Armour39™ watch, you can: Set the Main Time (TIME) Set an Alarm (ALARM) Set the Date (DATE) Set the Secondary Time (TIME 2) Activate/Deactivate Beep Sound (BEEP) Setting the Main Time (TIME): 1] Navigate to the TIME mode.
Page 15 5] Set HOUR setting. Press the Middle (B) Button on the CLOCK setting to enter the HOUR setting. Press the Top (A) Button to increase the current hour. Press the Bottom (C) Button to decrease the current hour. NOTE: To set time for PM, you must scroll through the digits 1- 12 as the watch defaults to an AM setting.
Page 16 Setting the Date: 1] Navigate to the TIME mode. Press the Top (A) Button to enter the TIME mode. 2] Select a selection item. Press the Middle (B) Button to scroll between selection items, TIME 1 (Main Time), DATE, TIME 2, ALARM, BEEP.
Page 17 setting to enter the MONTH setting. Press the Top (A) Button to increase the current month. Press the Bottom (C) Button to decrease the current month. 7] Set DAY setting. Press the Middle (B) Button on the MONTH setting to enter the DAY setting. Press the Top (A) Button to increase the current day.
Page 18 Press the Top (A) Button to enter the TIME mode. 2] Select a selection item. Press the Middle (B) Button to scroll between selection items, TIME 1 (Main Time), DATE, TIME 2, ALARM, BEEP. Press the Bottom (C) Button to exit the selection item list and return to the TIME mode start-up screen.
Page 19 minute. Press the Bottom (C) Button to decrease the current minute. 7] Return to Selection Item List. Press the Middle (B) Button on the MINUTE setting to return to the selection item list. 8A] To exit TIME mode: Press the Bottom (C) Button on the TIME 2 selection screen to return to the main watch navigation.
Page 20 3] Enter ALARM set-up. Press the Top (A) Button on the ALARM screen to enter the selection item set-up. 4] Select ALARM ON/OFF setting. Press the Top (A) Button or the Bottom (C) Button to toggle between the alarm ON mode and the alarm OFF mode.
Page 21 6] Set MINUTE setting. Press the Middle (B) Button on the HOUR setting to enter the MINUTE setting. Press the Top (A) Button to increase the current minute. Press the Bottom (C) Button to decrease the current minute. 7] Return to selection item list. Press the Middle (B) Button on the MINUTE setting to return to the selection item list.
Page 22 2] Select a selection item. Press the Middle (B) Button to scroll between selection items, TIME 1 (Main Time), DATE, TIME 2, ALARM, BEEP. Press the Bottom (C) Button to exit the selection item list and return to the TIME mode start-up screen. 3] Enter BEEP set-up.
Page 23: Device Set-Up
4] DEVICE SET-UP complete. Press Top (A) Button to exit the DEVICE SET-UP mode. A paired module will be automatically removed when your Armour39 A paired module will be automatically removed when your Armour39™ watch successfully pairs with a different module.
Page 24: Proﬁle Set-Up
PROFILE SET-UP Profile Set-Up Gender Weight (Unit Selection) Weight Height (Unit Selection) Height Max Heart Rate Unit Selection...
Page 25 1A] Top (A) Button: Enter PROFILE SET-UP. 1B] Top (A) Button: Increase/ Toggle proﬁle category options. 2] Middle (B) Button: Toggle between proﬁle categories. 3] Bottom (C) Button: Decrease/ Toggle proﬁle category options.
Page 26: Starting A Workout
STARTING A WORKOUT 1] Navigate to Armour39™ mode. Press Middle (B) Button from the main navigation to access Armour39™ mode. 2] Wear strap & module. Wear strap and module on chest. Moisten the chest strap pads to ensure better connectivity.
Page 27: Workout Screens
WORKOUT SCREENS Heartrate with Time Intensity with Time Calories with Time WillPower with Time Flag Counter Clock with Date 1A] Top (A) Button: Pause/ End the workout. 1B] Top (A) Button: Resume workout. 2] Middle (B) Button: Toggle between displays. 3A] Bottom (C) Button: Triggers Toggle between displays.
Page 28: Calender (Mem): Accessing Past Workouts
Press Bottom (C) Button to open the past workout calendar. 3] Toggle between workouts. Press Middle (B) Button to toggle through workout history. 4] View workout details. Press Top (A) Button to view workout details. Press Bottom (C) Button to return to Armour39™ mode.
Page 29: Calendar (Mem): Workout Data
CALENDAR (MEM): WORKOUT DATA Heart Rate Intensity/ Calories WillPower/ Time 1] Middle (B) Button: Toggle between workout results. 3] Bottom (C) Button: Exit workout results.
Page 30: Connect To App
Keep the phone and the watch in close proximity to each other. Ensure that both the Armour39™ watch and the phone are well-charged. DO NOT close the Armour39™ App or touch on the Armour39™ watch buttons while syncing, except when prompted to do so. ALERT:...
Page 31 Connect the Armour39™ Watch to the Armour39™ Mobile App: 1] Navigate to the WATCH section of the Armour39™ Mobile App. Use the top navigation to scroll to the WATCH section of the app. CONNECT WATCH If you do not see the WATCH...
Page 32 UPLOADING WORKOUTS downloading all of your workouts to your Armour39™ Mobile App Calendar; Updating your proﬁle on the Armour39™ watch to match your Armour39™ Mobile App; and Updating any Armour39™ Watch Updates. This may take a minute. 5] Finish. Press EXIT WATCH SYNC on YOU HAVE the Armour39™...
Page 33: Alerts
Armour39™ Mobile App before a workout can start. Module Not Found Appears when the watch cannot connect with the Armour39™ Module. Be sure to wear the module and strap before connecting. Moisten chest strap sensors on the Armour39™ TIP: Chest Strap to ensure strong connectivity.
Page 34 Armour39™ Update Failed Appears when the Armour39™ watch/ Armour39™ app software update fails. You must successfully update the Armour39™ software to exit the update failed mode. Update Failed Appears when the Armour39™ watch/ Armour39™...
Page 35 App Not Found Appears when the watch could not sync with the Armour39™ Mobile App. Make sure to push the sync button on both the phone and the app.
Page 36: Water Resistance
WATER RESISTANCE The Armour39™ watch is water-resistant up to 3 meters. You can use your Armour39™ watch for swimming or other watch sport activities (such as surﬁng), but it must NOT be used for snorkeling and/or deep water diving. TIPS:...
Page 37: Watch Backlight/ Screen Icon Display
To activate the backlight in the Armour39™ watch, tap on the lens two times consecutively. For a longer backlight, tap on the lens three times consecutively. The Armour39™ Watch backlight is only visible at night or NOTE: under extreme darkness conditions.
Page 38: Replace Watch Battery
REPLACE WATCH BATTERY If the power on your Armour39™ Watch is low, a low battery icon will be displayed on your watch screen. For optimal performance, replace your battery as described below: New Battery Replace Watch Battery: 1] Use a coin to open the battery compartment lid.
Page 39: Speciﬁcations
SPECIFICATIONS WATCH Head Diameter 42mm CLOCK Time Format 12/24 hour format with hour/ minute/ second Date Format DD/MM or MM/DD Year Range 2012 to 2062 Alarm Alarm with daily, weekday, or weekend settings WORKOUT Workout Time 00:00:00 to 99:59:00 Range Heart Rate Range 0, 130 to 240 bpm Maximum ﬂag (lap)
Page 40 Weight Range 20kg to 225kg (44 to 496 lbs) Height Range 69cm to 231cm (2’3 to 7’7) POWER Watch 1X CR2032 3V Battery OPERATING ENVIRONMENT Operating For watch: 0ºC to 49º C (32ºF Temperature to 120ºF) Storage For watch: -20ºC to 60ºC (-4ºF Temperature to 140ºF)
Page 41: Precautions
PRECAUTIONS To ensure you use your Armour39™ watch correctly and safely, read these warnings and the entire user manual before using the Armour39™ watch: To Clean: Use a soft, slightly moistened cloth. Do not use abrasive or corrosive cleaning agents, as these may cause damage.
Page 42 When replacing batteries, use new batteries meeting the speciﬁcations in this manual. Disposal: When disposing of your Armour39™ watch, ensure it is collected separately for special treatment and not disposed in normal household waste. Additional Safety & Servicing Precautions: This product is a precision instrument. Never attempt to take this device apart.
Page 43: About Under Armour
ABOUT UNDER ARMOUR® Visit our website www.underarmour.com to learn more about Armour39™ or other Under Armour® products. For additional inquiries, please contact Under Armour® Customer Service at 1-888-727-6687.
Page 44: Limited Warranty
Limited Warranty Under Armour, Inc., its subsidiaries and afﬁliates (“UA”) warrants to the original purchaser that its Armour39 watch (“Product”) shall be free from defects in workmanship and materials under normal use for a period of one (1) year from the date of original purchase. This limited warranty excludes...
Page 45 the original sales receipt. GENERAL LIMITATIONS OF WARRANTY EXCEPT AS SET FORTH HEREIN, UA MAKES NO WARRANTIES, EXPRESSED OR IMPLIED, AND BUYER ACKNOWLEDGES THAT NO REPRESENTATIONS, WARRANTIES, PROMISES OR STATEMENTS HAVE BEEN MADE BY UA, WITH RESPECT TO THIS PRODUCT, OR ANY PART OR PORTION THEREOF. IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE (1) YEAR FROM THE DATE OF ORIGINAL PURCHASE.
Page 46: Eu- Declaration Of Conformity
EU- DECLARATION OF CONFORMITY Hereby, Under Armour®, declares that Armour39™ watch (model: A39W01) is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the signed and dated Declaration of Conformity is available on request via our...
Page 47: Fcc/Ic- Statement
FCC/IC- STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modiﬁcations not expressly approved by WARNING: the party responsible for compliance could void the user’s authority to...
Page 48 This device complies with Industry Canada license- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil s’accorde avec Industrie Canada licence- exempte RSS standard.
