Summary of Contents for Piscines Magiline FX30
- Page 1 INSTALLATION MANUAL FX30 ADDITIONAL DIRECTIONS FOR...
- Page 2 Piscines MAGILINE provide this installation manual for the products they make. Piscines MAGILINE do not install these products: this work is the sole responsibility of the installer. These directions are mandatory: the application of the maker’s warranty depends on their observance.
- Page 3 PRACTICAL DATA SHEET - GLUING GLUING SHEET 30 s 15 s LWAYS LOWER THROUGH RIGID TUBE TO BOTTOM OF EXCAVATION ONCRETE HOLDING STUD IGID LEXIBLE OTTOM OF EXCAVATION The hoses can be placed in sleeves: ø75 to 80 for ø50 hoses ø90 for ø63 hoses 3/16 07/2012...
-
Page 4: Parts Lists
PARTS LISTS SGB0400AX - Electic Pump Module Associated kit SGC0103XX Ø63 / 650 mm Ø63 / 90° Gluing kit Ø63 / 110 mm 1 Screw kit for adjustable frame 2 Upstand frame (option) 3 Cover of box 4 Isolation valve 5 Motor separation screws (x 3) 6 Motor equipment room 7 Motor separation screws (x 5) - Page 5 SGB0416BX - SGB4016BX - Screw kit for adjustable frame Associated kit SGC0356AX SGC0356AX Adjustable frame for compartment Cover of compartment Ø50 / 920 mm Basket cover Filter basket Filter cartridge Suction grille screws (x 3) Suction grille Filter unit compartment Ø63 / 90°...
- Page 6 Only one discharge allowed Option : Additional discharge Associated kit Associated kit Associated kit Associated kit SGC0348XX SGC0104XX Ø50 / 920 mm TØ63 Ø50 / 90° Trim on discharge Flange gasket Option : Additional discharge for Shutter box Associated kit Associated kit SGC0104XX SGC0348XX...
- Page 7 EARTHWORKS Positioning A) Classic FX 30 : imperative to refer to the drawing.Any in case of validation by our technical service). B) FX 30 with Additional discharge / FX 30 with shutter Box : Use the drawing to correctly position hte Additional Discharge Module.
-
Page 8: Installation
INSTALLATION Assembly of the main group unit, assemble it with the motor unit, and clic ERFECTLY ALIGNED TTACH A LATH FX 30 with Separation of the electric pump : 1) Remove the frame and the slab 2) Unscrew the box of the electric pump from the structure (8 screws) 3) Separate the compartment Placement... - Page 9 CONNECTIONS Classic FX 30 Overview SGB0416BX The several options of the FX 30 Filtration generate many types of connections. These 3 examples are represantative of all cases. Ø63 A) Classic FX 30, without option B) FX 30 with optional main drain and optonal additionnal discharge.
- Page 10 Pump suction A) Open the Pump Compartment B) Unscrew and withdraw the valve. C/D/E) Glue the tube of the kit with the sleeve of the valve. F) Glue the assembly inside the direct suction unit. G) Replace the valve in its housing.
- Page 11 FX 30 with separated Electric Pump : Connect as shown by the diagram The original junction is beforehand cut opposite and connect the booster pipe to the electric pump. Ø50 / 865 mm booster pipe Ø50 / 90° connected to the electric pump Ø63 / 650 mm Pump Discharge...
- Page 12 FX 30 with separated electric pump : Ø50 / 90° Ø50 / 920 mm Connect as shown by the diagram opposite Ø63 / 90° Main Drain Ø50 / 90° Ø50 / 840 mm Main Drain Option Connect as shown by the diagram opposite Bed the base of the drain(s) in ce- ment after connecting.
- Page 13 Additional Discharge option and Shutter Box additional Discharge Connect the additional Discharge to the outlet of the pump as shown by the diagram opposite. For the shutter box additional discharge, screw the elbowed broom connection (diagram below). Screw with Oriented at 45°...
- Page 14 POURING OF THE CONCRETE Pouring of block Make sure that the concrete is correctly placed under the - push it with a batten. Concrete footing be blocked in a concrete footing linked to the structure by bars. SEE «MAGICLASSIC INSTALLATION MANUAL» Pouring of the volute Fill the formwork of the volute when pouring the structure.
- Page 15 FINISHING Fill materials (not earth). Slabs of the Terrace below coping compartments Adjustable frame OPTIONAL : Adjustable frames could be add to align the terrace with the copings. In the case of the alignment of terrace with coping : top ABS frames against the decks ) then screw them directly to the bottom frames ( 15/16...
- Page 16 MONTAGE ÉLECTROPOMPE THIS OPERATION IS PERFORMED WHEN THE SWIMMING POOL IS FILLED WITH WATER Installation of the electric pump graissé. B) Positionner l’électropompe dans la volute. C) A l’aide de la clé, visser fermement l’électropompe dans la volute D) fermer le verrou de volute. Key of assembly Spurs of...
