AMIC A9280-A-000 User Manual

Compact flash rfid reader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AMIC A9280-A-000
13.56MHz Compact Flash
RFID Reader
User Manual
Rev 1.0
© AMIC 2004
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in
any form or by any means, electronic or mechanical, including photocopying and microfilm, without
permission in writing from AMIC.
AMIC Communication Co.
th
No.2, Li-Hsin 6
Road, SBIP, 300 Hsinchu, Taiwan, R.O.C
TEL: 886-3-5679966
FAX: 886-3-5679977
© AMIC Dec. 2004 – All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A9280-A-000 and is the answer not in the manual?

Questions and answers

Summary of Contents for AMIC A9280-A-000

  • Page 1 AMIC. AMIC Communication Co. No.2, Li-Hsin 6 Road, SBIP, 300 Hsinchu, Taiwan, R.O.C TEL: 886-3-5679966 FAX: 886-3-5679977 © AMIC Dec. 2004 – All rights reserved...
  • Page 2 Philips, and I•Code SLI are registered trademarks of Philips Semiconductor. TI, and Tag-It HF-I are registered trademarks of Texas Instruments. HP and IPAQ are registered trademarks of Hewlett-Parker. All other trademarks mentioned herein are properties of their respective companies. © AMIC Dec. 2004 – All rights reserved...

  • Page 3: Product Contents

    AMIC’s A9280-A-000 is a user-friendly RFID operating at 13.56MHz frequency range. This RFID reader is to be used with PDA or handheld devices equipped with Compact Flash Type-1 or Type-2 slot. AMIC’s A9280-A-000 is a Compact Flash RFID reader is compliant with the international recognized ISO-15693 standard. It has built-in antenna for easy of use, and it is capable of 200mW RF power output.

  • Page 4: Installation Requirements

    AMIC A9280-A-000 User Guide 2.1. Installation Requirements AMIC A9280-A-000 requires the following minimum system environment for proper PDA device driver installation and reader operation: Minimum System Requirement: − Processor: Intel XScale ARM processor running at 400MHz or faster − Memory: Minimum 2MB SDRAM −...
  • Page 5 AMIC A9280-A-000 User Guide Setup Your PC Before installing AMIC 9280-A-000 device driver onto your PDA, make sure that the PC used to connect to your PDA has the appropriate synchronization software installed. PDA’s synchronization software will enable user to install the necessary device driver and GUI utility for AMIC 9280-A-000 CF on to your PDA.
  • Page 6 AMIC A9280-A-000 User Guide Install A9280-A-000 Pocket PC Device Driver To install A9280-A-000 Pocket PC device driver on your PDA, please follow the following procedures: Make sure that the required PDA synchronization software has been installed on your PC. Turn on your PC and wait for it to boot up completely.
  • Page 7 11. Select “I accept the terms in the license agreement” 12. Click on the Finish button The A9280-A-000 Pocket PC device driver is now installed on your PDA. For detail operating instructions on how to establish communication link between PC and PDA, please refer to PDA manufacturer’s operating manual.
  • Page 8 AMIC A9280-A-000 User Guide Install AMIC A9280-A-000 GUI Utility on PDA Make sure that the required PDA synchronization software has been installed on your PC. Turn on your PC and wait for it to boot up completely. Connect your PDA to your PC through PDA manufacturer recommended method.
  • Page 9 16. Auto Scan button Block data 17. CARD UID Read history window Exit button 18. Response Information window Clear button 19. Operation OK / Fail Display 10. Auto Scan Counter 7 of 20 © AMIC Dec. 2004 – All rights reserved Rev 1.0...

  • Page 10: Launch The Gui Utility On Pda

    AMIC A9280-A-000 User Guide Launch the GUI Utility on PDA Make sure that the AMIC A9280-A-000 RFID CF reader is inserted into PDA’s CF slot securely “New Hardware Found” window will be displayed as in figure – 5 Use PDA’s stylus and single tap on “OK” button Use PDA’s File Explorer to list application files available...
  • Page 11 COM port on the PDA. The available COM port for CF reader is dependent on the type of PDA that you used. Please select another available COM port and initialize the reader again. 9 of 20 © AMIC Dec. 2004 – All rights reserved Rev 1.0...
  • Page 12 AMIC A9280-A-000 User Guide Read Card UID Each RFID tag has an unique identification number (UID). You can use AMIC CF reader to read UID from RFID tags. Make sure the GUI screen displays Init OK in the System Status Dialog Box. To read UID from tags follow the steps listed below: Hold the PDA such that the distance between the tag and the CF reader is no longer than 7 cm.
  • Page 13 4 bytes of data for tags complying with ISO-15693 standard. Please refer to RFID tag manufacturer’s data sheet for details. AMIC’s A9280-A-000 CF reader will read 4 bytes of data per block from RFID tags at a time. Please follow the steps below for Read Block Data.
  • Page 14 4 bytes of data for tags complying with ISO-15693 standard. Please refer to RFID tag manufacturer’s data sheet for details. AMIC’s A9280-A-000 CF reader will write 4 bytes of data per block to RFID tags at a time. Please follow the steps below for Read Block Data.
  • Page 15 Write Data has been performed successfully and correctly. Please refer to Read Block Data for how to read data from RFID tags. 13 of 20 © AMIC Dec. 2004 – All rights reserved Rev 1.0...
  • Page 16 Hold the PDA containing the CF reader near the tag to be read. RFID tag’s UID read by the reader should be displayed in the Response Information box. 14 of 20 © AMIC Dec. 2004 – All rights reserved Rev 1.0...
  • Page 17 AMIC A9280-A-000 User Guide Figure – 10 15 of 20 © AMIC Dec. 2004 – All rights reserved Rev 1.0...
  • Page 18 AutoScan ON function of the CF reader, please follow the steps below: Single click on the Auto OFF box. The reader shall stop reading RFID tags. Figure – 11 16 of 20 © AMIC Dec. 2004 – All rights reserved Rev 1.0...
  • Page 19 The Clear button enables the user to clear the Response Information box any time during CF reader operation. Clear button can be tapped any time to clear the Response Information display. Figure – 12 17 of 20 © AMIC Dec. 2004 – All rights reserved Rev 1.0...
  • Page 20 AutoScan ON function by single click on the Auto Off button first before exiting from the GUI utility. Single click on the Exit box. The GUI utility should be closed and return to your previous PDA display screen. 18 of 20 © AMIC Dec. 2004 – All rights reserved Rev 1.0...

  • Page 21: Revision History

    AMIC A9280-A-000 User Guide Revision History Revision Date Description _____________________________________________________________________________ 12/30/2004 Initial creation H. Yu 19 of 20 © AMIC Dec. 2004 – All rights reserved Rev 1.0...

  • Page 22: Fcc Information

    Consult the dealer or an experienced radio/TV technician for help. The user should not modify or change this equipment without written approval Form AMIC Communication Co. Modification could void authority to use this equipment. 20 of 20 ©...
