Summary of Contents for Brightwin Electronics LC200A
- Page 1 OPERATING MANUAL LC200A Portable LC Meter www.brightwinelectronics.com brightwinelectronics@hotmail.com...
-
Page 2: Table Of Contents
Contents 2. Inspecting Package Contents ..............1 3. Summary ..................... 1 3.1 Brief introduction .................. 1 3.2 Main function ..................1 3.3 Technical data ..................2 3.4 Environmental Requirements ............... 3 4.Instrument Introduction ................. 4 4.1 Structure Description ................4 4.2 Button Description ................ -
Page 3: Inspecting Package Contents
LC200A Portable LC Meter 2. Inspecting Package Contents When you get a new Portable Meter of LC200A, please inspect the instrument as follows: 2.1 Check if there is damage due to transportation If the package is damaged, please retain them until the instrument and accessories are tested. -
Page 4: Technical Data
LC200A Portable LC Meter 3.2.1 Measurement LC200A is easy to use, it has four measuring range position: 1. C range ..Capacitance (0.01pF-10uF) 2. L range ...Inductance (0.001uH-100mH) 3. Hi.L range ..Big inductance (0.001mH-100H) 4. Hi.C range ..Big capacitance (1uF-100mF) 3.2.2 Calibration Capacitance Mode----- open circuit calibration;... -
Page 5: Environmental Requirements
LC200A Portable LC Meter Measurement resolution of large capacitance 0.01uF （Hi.C Range） L Range、C Range 500kHz Test Frequency Hi.L Range 500Hz ~50KHz Measurement method of capacitance、 LC Resonance Inductance and Large Inductance Measurement method of large capacitance Charge-discharge Display 1602 LCD... -
Page 6: Instrument Introduction
Test terminals 4-1 The introduction of LC-200A LC200A can be powered by a mini USB interface or 5V power adapter with Φ5.5DC Socket. Note: The supply voltage is 5V, if you want to use the DC adapter, make sure the polarity is positive in the hole, peripheral negative. You... -
Page 7: Button Description
4-2 LC200A menu 5. Operation 5.1 Power On 5.1.1 Plug 5V adapter, LC200A can be powered by a mini USB interface or 5V power adapter with Φ5.5DC Socket. You can also power the instrument with 4 of AA Batteries. 5.1.2 Switch on. The meter will show the company name and product model. -
Page 8: Calibration
LC200A Portable LC Meter clips open or short. Test clips open Test clips short MEASURE Cx MEASURE Cx Capacitance (C) 0.00pF OVER RANGE show MEASURE Lx MEASURE Lx Inductance (L) show OVER RANGE 0.000uH MEASURE Hi.L MEASURE Hi.L Large inductance OVER RANGE 0.000mH... -
Page 9: Check The Frequency
LC200A Portable LC Meter 10uF range. In the Hi.C gear, make sure the test capacitor is fully discharged, then pick the red test clip to the capacitor positive, the black one to the capacitor negative. The test result can be read from the display. -
Page 10: Warranty And Service
LC200A Portable LC Meter 7. Warranty and service Thank you for purchasing our products. To maximize the use of the new product features, we recommend that you take the following steps: 1. Read safe and efficient use instruction. 2. Read the warranty terms and conditions.
