Quick Links

C192PF8-RPR
Power Factor
Manager &
Reactive Power Regulator
Installation
and Operation
Manual
BG0347 Rev. A1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C192PF8-RPR and is the answer not in the manual?

Questions and answers

Related Manuals for Satec C192PF8-RPR

Summary of Contents for Satec C192PF8-RPR

  • Page 1 C192PF8-RPR Power Factor Manager & Reactive Power Regulator Installation and Operation Manual BG0347 Rev. A1...
  • Page 2 C192PF8-RPR Power Factor Manager and Reactive Power Regulator Installation and Operation Manual...
  • Page 3 LIMITED WARRANTY The manufacturer offers the customer an 24-month functional warranty on the instrument for faulty workmanship or parts from date of dispatch from the distributor. In all cases, this warranty is valid for 36 months from the date of production.
  • Page 4 The secondary of an external current transformer must never be allowed to be open circuit when the primary is energized. An open circuit can cause high voltages, possibly resulting in equipment damage, fire and even serious or fatal injury. Ensure that the current transformer wiring is made through shorting switches and is secured using an external strain relief to reduce mechanical strain on the screw terminals, if necessary.

  • Page 5: Table Of Contents

    Table of Contents Chapter 1 Introduction............... 1 About This Manual ..................1 About The C192PF8-RPR ................1 Chapter 2 Installation................. 7 Mechanical Installation ................7 Electrical Installation................. 8 Chapter 3 Using The Menus .............. 18 Chapter 4 Setup Menus ..............20 Basic Setup Menu..................

  • Page 6: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 About This Manual This manual is intended for the user of the C192PF8-RPR Power Factor Manager and Reactive Power Regulator. The C192PF8-RPR is a multi-function microprocessor-based instrument used for power factor or reactive power correction and for the measurement, monitoring, and management of electrical parameters in low-voltage and mid-voltage power systems.
  • Page 7 • Manual, self-adapting automatic and optimizing automatic operation • Full four-quadrant operation • Selectable target power factor or reactive power setpoints • Two PFC setpoint ranges for day and night operations selectable via a status input • Target power factor range from 0.5 (inductive) to -0.5 (capacitive) •...
  • Page 8 One digital input can be used as a status input for monitoring external contacts or as an external synchronization input for power demand interval synchronization. When no external synchronization pulse is provided, the power demand interval can be synchronized through communications. Three user-selectable options are provided: Power calculation mode Power calculations can be made using directly measured reactive power or...
  • Page 9 Parameter Dis- Output play Analog Pulse Alarm √ Apparent power accumulated demand √ Active power demand √ Active power sliding demand √ Apparent power demand √ Apparent power sliding demand √ Active power predicted demand √ Apparent power predicted demand √...
  • Page 10 Parameter Dis- Output play Analog Pulse Alarm Real-time Harmonic Values √ RT voltage THD per phase √ RT current THD per phase √ RT current TDD per phase √ RT K-Factor per phase Average Harmonic Values √ √ Average Voltage THD per phase √...
  • Page 11 Instrument Dimensions Figure 1-1 C192PF8-RPR Dimensions Chapter 1 Introduction...

  • Page 12: Chapter 2 Installation

    Prepare the panel cut-out, 136 x 136 mm, prior to mounting. STEP 1: Place the instrument through the cut-out. STEP 2: Assemble the latches onto the outer wall of the enclosure. STEP 3: Tighten the screws. Figure 2-1 Mounting the C192PF8-RPR Chapter 2 Installation...

  • Page 13: Electrical Installation

    OFF. Failure to observe this practice can result in serious or even fatal injury and damage to equipment. Connections to the C192PF8-RPR are made via terminals (voltage and current inputs, power supply, communication, relay and analog output) as shown in Figure 2-2.
  • Page 14 Figure 2-2 C192PF8-RPR Connections - Rear View Chapter 2 Installation...
  • Page 15 2.2.5 Wiring Configurations Wiring Configuration Wiring (See parameter setup instructions in Section 4.1) Setup Mode Connection 3-wire direct connection using 2 CTs (2-element) 3dir2 Figure 2-3 4-wire WYE direct connection using 3 CTs (3-element) 4Ln3 or 4LL3 Figure 2-4 4-wire WYE connection using 3 PTs, 3 CTs (3-element) 4Ln3 or 4LL3 Figure 2-5 3-wire open delta connection using 2 PTs, 2 CTs (2-element)
  • Page 16 Figure 2-4 Four Wire WYE Direct Connection Using 3 CTs (3-element) Wiring Mode = 4LL3 or 4Ln3 Figure 2-5 Four Wire WYE Connection Using 3 PTs, 3 CTs (3-element) Wiring Mode = 4LL3 or 4Ln3 Chapter 2 Installation...
  • Page 17 Figure 2-6 Three Wire Open Delta Connection Using 2 PTs, 2 CTs (2-element) Wiring Mode = 3OP2 Figure 2-7 Three Wire Open Delta Connection Using 2 PTs, 3 CTs (2½-element) Wiring Mode = 3OP3 Chapter 2 Installation...
  • Page 18 Figure 2-8 Four Wire WYE Connection Using 2 PTs, 3 CTs (2½-element) Wiring Mode = 3Ln3 or 3LL3 Figure 2-9 Four Wire Delta Direct Connection Using 3 CTs (3 element) Wiring Mode = 4LL3 or 4Ln3 Chapter 2 Installation...
  • Page 19 Figure 2-10 Three/Four Wire Direct Connection Using 1 CT Wiring Mode = 2LL1 2.2.6 Relay Eight relays are provided for capacitor bank control (or energy pulsing/alarms). Figure 2-11 Relay Connection Chapter 2 Installation...
  • Page 20 Figure 2-12 Status Input Connection 2.2.8 Analog Output The C192PF8-RPR provides one optically isolated analog output with current output options of 0-20 mA and 4-20 mA (current loop load of up to 500 Ohm). The analog output must be used with a 24 V DC external power supply.
  • Page 21 2.2.9 Communications The C192PF8-RPR is provided with an RS-232 or RS-485 communication port. Figures 2-14 through 2-18 illustrate the connections. RS-232 25-PIN DB25 MALE CONNECTOR POWERMETER MODEM DSR/CTS C99-11012 Figure 2-14 RS-232 Connection for 25-pin Modem Connector RS-232 9-PIN DB9 MALE CONNECTOR...
  • Page 22 RS-232 9-PIN DB9 FEMALE CONNECTOR POWERMETER IBM PC/COMPATIBLE c99-11015 Figure 2-17 RS-232 Simple 3-Wire Computer Connection, 9-pin Figure 2-18 RS-485 Multi-drop Computer Connection NOTE: Where the manufacturer's RS-232/RS-485 converter is used on a computer connection, R1 is not applicable since it is built in to the converter. Activity on the communications port lines is indicated via the TXD and RXD LEDs, on the front panel and via the Status Information menu (see Chapter 6).

  • Page 23: Chapter 3 Using The Menus

    Chapter 3 Using The Menus Press and release to enter the setup mode. The primary menus will SELECT appear: Status Information Menu (see Chapter 6) Setup Options Menu Setup Change Menu (see Chapter 4) Press again to activate the window of the desired primary menu. SELECT Press ENTER...
  • Page 24 SELECT ENTER Status Information Setup Options ENTER Setup Change Password PASS PFC Manual Mode PFC Status PFC.H PFC Setup Device Diagnostics diAG Reset Functions Phase Rotation PHAS Manual Relay Control Relay Status rELc Basic Setup Status Inputs bASc St.In Port Setup Counter #1 Port Cnt.1...

  • Page 25: Chapter 4 Setup Menus

    Chapter 4 Setup Menus 4. CHAPTER 3 SETUP MENUS NOTE: Instrument setup can be performed directly on the front panel using the setup menus or via communications using PAS communication software. PAS is supplied with your instrument and provides full setup capabilities for your instrument. For information on using PAS, refer to the user documentation supplied with your instrument.
  • Page 26 (0∗) When the power demand period is specified in minutes, synchronization of the demand interval can be made through communications (see the C192PF8-RPR Modbus Reference Guides) or via the front panel (see Section 4.11). If the power demand period is set to External Synchronization, an external synchronization pulse denoting the start of the next demand interval can be provided through a digital input or can be simulated by using the synchronization command sent via communications.

  • Page 27: Communications Port Setup Menu

    ENTER This menu allows you to access the communications port options that the C192PF8-RPR uses to communicate with a master computer. Table 4-2 lists the communications options, their code names and applicable choices. Activate the middle window to scroll through the list of available options, and then activate the lower window to set the option value.

  • Page 28: Digital Input Setup Menu

    SELECT ENTER ENTER This menu is used to set up a digital input provided by the C192PF8-RPR. The digital input can be configured as: - a status input to monitor external contact status, or - an external synchronization pulse input to receive an external synchronization pulse indicating the beginning of a new demand interval for power demand measurements.

  • Page 29: Analog Output Setup Menu

    4.4 Analog Output Setup Menu [This section is relevant to instruments ordered with this option.] Aout SELECT ENTER ENTER This menu allows you to set up an output value and its zero and full scales for the internal analog output. Table 4-3 explains the analog output setup options, and Table 4-4 lists all measurement parameters that can be directed to analog output.
  • Page 30 Table 4-3 Analog Output Setup Options Code Option Description OutP Output parameter The output parameter for the analog output channel Zero scale (0/4 mA) The reading of the parameter corresponding to a zero- scale current output Full scale (1/20 mA) The reading of the parameter corresponding to a full-scale current output Table 4-4 Analog Output Parameters...

  • Page 31: Pulsing Output Setup Menu

    ENTER This menu allows you to program any of the eight relays provided by your C192PF8-RPR instrument to output energy pulses. Relays #7 and #8 are especially recommended for use as pulsing relays because of their high endurance. Available pulsing parameters are listed in Table 4-5.

  • Page 32: Alarm/Event Setpoints Setup Menu

    Code Parameter Units rE.EE Reactive energy export kvarh export (capacitive) rE.Et Reactive energy total kvarh total (absolute) AP.Et Apparent energy total kVAh total NOTES You will not be able to store your setup in the instrument if you assigned a parameter to a relay output with a zero number of unit-hours per pulse.
  • Page 33 SP 1 Operate delay } On d The delays before operation (On d) and release (OFFd) are set at 5 seconds and 10 seconds respectively. SP 1 Release delay } OFFd SP 1 Setpoint action The action to be triggered is operation of relay #1. rEL.1 To select a setpoint: Scroll to the desired setpoint using the up/down arrow keys.
  • Page 34 Table 4-6 Setpoint Setup Options (middle window) Code Option Description trig Trigger parameter The measurement parameter or signal to be monitored by the setpoint. Operate limit The threshold at which the setpoint becomes operative. Release limit The threshold at which the setpoint is released (becomes inoperative).
  • Page 35 Code Parameter Unit Range A. Lo.C3 Low current L3 0 to Imax Average Values on any Phase A. Hi. U High voltage 0 to Vmax A. Hi. LU High L-L voltage 0 to Vmax A. Lo. U Low voltage 0 to Vmax A.
  • Page 36 The No-Volt trigger is intended for the use as a fast setpoint override condition for PFC operations in order to protect the capacitor banks against voltage interruptions. When used with the Hard Switch-Off action, it can de-energize the output relays in approximately 25 ms.

  • Page 37: Relay Operation Control Menu

    not be affected. After the alarm condition passes, the PFC will return to automatic operation after the safety delay which is 50 times the power factor setpoint operate delay (see Note to Table 4-11). The Stop action freezes the PFC operations in automatic operation modes. The PFC avoids any automatic switching operations on the capacitor banks while the alarm condition is present.

  • Page 38: Display Setup Menu

    4.8 Display Setup Menu SELECT diSP ENTER ENTER This menu allows you to view and change display properties. Table 4-9 lists available options with their code names and applicable ranges. Table 4-9 Display Options (∗ default setting) Display Code Parameter Options Description UPdt...

  • Page 39: User Selectable Options Menu

    To select a display option: SELECT Press to activate the middle window, and then use the up/down arrow keys to scroll to the desired option. To change the display option: Press SELECT to activate the lower window. Use the up/down arrow keys to set the desired option. ENTER Press to store your new setting or press...
  • Page 40 Code Parameter Options Description Ph.En , En Phase energy Enables/disables measurements of energies measurements per phase Power calculation mode (P.cAL): Mode 1: Reactive power calculation (rEAc) Active power P and reactive power Q are measured directly and apparent power S = √ P Mode 2: Non-active power calculation (nAct) Active power is measured directly, apparent power S = V ×...

  • Page 41: Access Control Menu

    4.10 Access Control Menu AccS SELECT ENTER ENTER This menu can be only accessed via the Setup Change Menu (CHG). It is used in order to: • change the user password • enable or disable password check To view an option setting: SELECT Press to activate the middle window.

  • Page 42: Reset/Synchronization Menu

    4.11 Reset/Synchronization Menu SELECT ENTER ENTER This menu allows you to reset to zero the accumulators and Min/Max registers in your instrument, and also to synchronize the power demand interval. The menu can be only accessed via the Setup Change Menu (CHG). If the reset is disabled from the Basic Setup Menu (see Section 4.1), you will not be able to enter this menu.

  • Page 43: Manual Relay Control Menu

    data display mode (see Section 5.1), and reset of counters from the Status Information Menu (see Section 6.1) without entering the reset menu. If you select the d.Snc entry, take into consideration the following: a) If the power demand period is specified in minutes (see Section 4.1, Basic Setup Options), this action provides synchronization of the instrument’s internal timer.

  • Page 44: Pfc Setup Menu

    4.13 PFC Setup Menu SELECT ENTER ENTER This menu allows you to configure the PFC setup options and to set the PFC operation mode. Table 4-11 lists the PFC setup options, their code names and applicable ranges. For more information on the PFC options and operation, refer to Chapter 5, PFC Operation.
  • Page 45 Code Parameter Options Description Two target setpoint ranges are defined by SP1-2∗ setpoints SP1 and SP2 (generally, to differentiate between day and night operations). The active setpoint range is selected through a digital (status) input. U.CAP Nominal voltage of the 1V to 999V if PT RATIO = 1 0∗, capacitor banks...
  • Page 46 Code Parameter Options Description CAP3 Size of the capacitor On, nonE, Power rating of the capacitor bank. bank #3, kvar 1 to 10000 kvar nonE = not used, (1500∗) On = permanently switched in Size of the capacitor On, nonE, Power rating of the capacitor bank.
  • Page 47 4. The target power factor limits are always specified for the I and IV quadrants regardless of the location of the instrument on the source or load side. The PFC will automatically account for the direction of power flow providing full four-quadrant operation. 5.

  • Page 48: Pfc Manual Mode Menu

    4.14 PFC Manual Mode Menu PFC.H SELECT ENTER ENTER This menu allows you to manually operate (connect or disconnect) the PFC capacitor banks in progressive order by entering commands from the front panel. The menu can be only accessed via the Setup Change Menu (CHG) if the PFC is running in Manual Mode (see Section 4.13, PFC Setup).

  • Page 49: Chapter 5 Pfc Setup And Operation

    (Data Display) and Chapter 7 (Viewing Status Information). 5.1 Capacitor Bank Control Options The C192PF8-RPR offers you three options to control capacitor banks in order to meet the conditions of your electrical equipment and avoid unnecessary switching. All options may be used at the same time when applied to different banks.

  • Page 50: Pfc Operation

    To specify the bank as a permanently switched bank, set the bank size parameter to On (see Section 4.13, PFC Setup). The permanently switched banks are switched in automatically when the PFC is put into either manual or automatic operation mode and before a switching program begins, and are switched out when the PFC shuts down, following all switching and re-connection time delays.
  • Page 51 the target. When no leading (capacitive) target power factor is allowed, only combinations that provide lagging (inductive) power factor will be checked. The banks are connected and disconnected starting from the low-size banks, following all pre-set switching and re-connection delays. Alternation of switching operations is provided when needed to avoid excessive deviation from the target power factor.
  • Page 52 Shutting the PFC Down From the PFC setup menu, set the PFC operation mode to OFF. This will put the PFC into Shut Down mode. Shut Down mode provides step-by-step disconnection of all the capacitor banks that are under the PFC control. The banks switch out progressively, following disconnection intervals (switch-off delays).
  • Page 53 PFC will not take into account the status of the digital input. The second setpoint will not even appear in the PFC setup menu. If you want to use different target setpoints and switch them depending on the time schedule or another external condition, specify the operational setpoints as SP1-2.
  • Page 54 defined setpoint operate delay. This makes the trigger less sensitive to fast changes in load thus avoiding excess switching. The operate delay timer is reloaded each time the measured power factor oversteps the setpoint range limits. The allowable range for the operate delay is 1 to 3600 sec. The default value is 3 sec.
  • Page 55 Normally, the capacitors discharge through fixed resistors that are connected to the capacitors directly or via auxiliary contacts of the contactors. Refer to the capacitor data sheet for the recommended discharge time for your capacitors. The re-connection delay can be adjusted in the range of 3 to 3600 sec. The default setting is 300 sec.
  • Page 56 The C192PF8-RPR allows you to choose between manual and automatic adjustment of the capacitor bank powers. If you choose to make this manually, specify the bank nominal voltage in the PFC setup as zero, and then enter the reactive powers for each bank being recalculated for the operating voltage of the...

  • Page 57: Capacitor Banks Protection

    (with minimal cycling whenever possible). In the C192PF8-RPR, all protective functions are provided through the universal mechanism of programmable alarm setpoints (see Section 4.6, Alarm/Event Setpoints Menu).
  • Page 58 5.3.2 PFC Protection Setpoints Protection against Voltage Interruptions The fast disconnection of the capacitor banks is required in the event of short- term voltage interruptions that would cause damage to the still-charged capacitors when the voltage is restored. The No-Volt alarm override condition (see Table 4.6) along with the Hard Switch- Off action can de-energize the output relays in approximately 25 ms whenever voltage interruption is detected.
  • Page 59 Protection against High Harmonics High THD protection prevents damage to capacitors at high levels of voltage harmonics, which can be caused by voltage resonance at a higher frequency. The effect of the high THD setpoint protection is limited progressive disconnection of the capacitor banks until resonance conditions disappear, and then, after a long safety delay, returning the PFC into normal operation.

  • Page 60: Chapter 6 Data Display

    Chapter 6 Data Display 6.1 Navigating in the Display Mode The front panel has a simple interface that allows you to display numerous measurement parameters in up to 43 display pages. For easier reading, the parameters are divided into three groups, each accessible by a designated key. These are: Common measurements - no selection key...
  • Page 61 Alarm/Man Mode LED This LED has two functions. The blinking LED indicates that the PFC is operating in Manual Mode. The constantly lit LED gives you an alarm indication. It is controlled by the alarm/event setpoints (see Section 4.6) and operates in latched mode. Even if alarm conditions are no longer present, the alarm LED will continue to warn.

  • Page 62: Data Display Formats

    Selecting Total Harmonic Measurements THD/TDD Press the key until the THD or TDD LED is illuminated. Use the up/down arrow keys to scroll through the different harmonic parameters. Selecting Energy Measurements ENERGY Press the key. Use the up/down arrow keys to scroll through the different energy readings.
  • Page 63 Page Window Indicator Parameter Digits Unit A NEUT Neutral current Frequency Total kW kW/MW Power factor L1 Ph.L1 Label kW L1 kW/MW kVA L1 kVA/MVA Ph.L1 Label kvar kvar L1 kvar/Mvar Power factor L2 Ph.L2 Label kW L2 kW/MW kVA L2 kVA/MVA Ph.L2 Label...
  • Page 64 Page Window Indicator Parameter Digits Unit Min. real-time current L1 Min. real-time current L2 Min. real-time current L3 Min. real-time total power factor Min. real-time total kVA kVA/MVA kvar Min. real-time total kvar kvar/Mvar A NEUT Min. real-time neutral current Min.
  • Page 65 Page Window Indicator Parameter Digits Unit Total Energies Ac.En. Label Label MWh import Mvarh rE.En. Label Label Mvarh import Mvarh MVAh AP.En. Label MVAh MVAh Ac.En. Label Label MWh export Mvarh rE.En. Label Label Mvarh export Mvarh Phase Energies Ac.En. Label IP.L1 Label...

  • Page 66: Device Diagnostics Display

    (see the communications reference guides shipped with your instrument). When a non-critical error is detected, the C192PF8-RPR sets a corresponding fault bit in the diagnostics register and restart operations showing the last recorded diagnostics code on the display.
  • Page 67 When the device detects a corrupted configuration setup or incompatible setup setting, it sets a corresponding fault bit in the diagnostics register, resets the corrupted setup to default and rises a critical (unrecoverable) error. Diagnostics status can be viewed through the Status Information Menu (see Section 7.2), and tested through a setpoint via the Device Fault trigger.

  • Page 68: Chapter 7 Viewing Status Information

    Chapter 7 Viewing Status Information Through the Status Information Menu (StA), it is possible to view the status of various instrument features. 7.1 The Status Information Menu ENTER SELECT To enter the Status Information Menu: From the display mode, press to enter the Primary Selection Menu.

  • Page 69: Status Display Formats

    7.2 Status Display Formats Table 7-1 lists all the displays available from the Status Information Menu. The display windows are labeled in the table as follows: 1 = upper window, 2 = middle window, 3 = lower window. Table 7-1 Status Information Display Page Window Parameter...
  • Page 70 Table 7-2 PFC Operation Modes Code Operation Mode The PFC is switched OFF Sh.dn The PFC is shutting down Aut.1 Self-adapting automatic operation mode Aut.2 Optimizing automatic operation mode HAnd Manual operation mode Table 7-3 PFC Operation Status Code Operation Status Description ready Ready...

  • Page 71: Appendix: Technical Specifications

    Appendix: Technical Specifications 8. ions Input and Output Ratings 3 galvanically 690 V: DIRECT INPUT (690V + 15% line-to-line voltage and isolated voltage (standard) 400V +15% line-to-neutral) Burden: <0.5 VA inputs INPUT USING PT Burden: <0.15 VA 120 V: INPUT USING PT (120V +20% line-to-line voltage) (optional) Burden: <0.1 VA 3 galvanically...
  • Page 72 Environmental Conditions -20°C to +60°C (-4°F to +140°F) Operating temperature -25°C to +80°C (-13°F to +176°F) Storage temperature Humidity 0 to 95% non-condensing Construction Instrument body Case enclosure: flame resistant ABS & Polycarbonate Blend Dimensions: 144 x 144 x 86 mm ( 5.67 x 5.67 x 3.39 “) Mounting: 136 x 136 mm square cut-out (DIN 43700) Instrument weight 0.9 kg (2.04 lb.)
  • Page 73 Measurement Specifications Accuracy, % Range Display resolution (%Rdg) Parameter Full scale Conditions @ range × Voltage 0.25 10% to 120% FS 0 to 999,000 V Direct wiring (PT=1): 120V For Ln reading 0.1 V @ 0.1V to 999.9 V @ 120V and for ×...
  • Page 74 Accuracy, % Range Display resolution (%Rdg) Parameter Full scale Conditions @ range Neutral (unbalanced) CT PRIMARY CURRENT 2% to 120% FS 0 to 9999 A 0.01 A @ 0.01A to 99.99 A ≤0.1% @ 100.0 A to 9999 A current Starting current 0.5% FS Ampere demand same as for current...
  • Page 75 Index mounting, 1, 7 accuracy, 70 active energy, 4, 70 open delta, 10, 21, 39, 40 active power, 3, 4, 35, 69 options, 15 alarms, 14 overload withstand , 67 ampere demand , 21, 30, 60 analog output , 2, 5, 8, 15, 24, 25 analog outputs , 22 panel cut-out, 7 password, 2, 18, 36, 37, 57, 64...
