Summary of Contents for Sunpai DB316
- Page 1 使用说明书 Base Station Product Manual...
-
Page 2: Table Of Contents
Contents 1) Summary........................1 1.1 Product Introduction...................1 1.2 Dimensions and Weight..................1 1.3 Unpacking and checking..................1 1.4 Features and Usage.....................1 1.5 Environmental Requirements................2 1.6 Electronic Shelf Label System Overview ............2 2) Technical Characteristics ..................3 2.1 Key Perfomance Areas ..................3 2.3 Base Station Antenna Pattern ................4 3) Base Station Installation ..................5 3.1 Panel Description ....................5 3.2 Power Supply and Networking ................6... -
Page 3: Summary
1.1 Product Introduction DB316 is the third-generation wireless base station. It is a new Active RFID system and the new ESL Tags. Sunpai Tag Shanghai produces the base station for its electronic shelf label system (ESLs) and other products. 1.2 Dimensions and Weight... -
Page 4: Environmental Requirements
1.5 Environmental Requirements Temperature Range: -10°C to +55°C(14°F to +131°F)Humidity range: 20% to 95%Supply Voltage: AC/DC Adapter. Base Station Input Voltage 6VDC, 2.5A 1.6 Electronic Shelf Label System Overview An electronic shelf label system (ESLs) consists of electronic shelf labels, ESL server, switches, base stations, Handset and software. -
Page 5: Technical Characteristics
2. Technical Characteristics 2.1 Key Performance Areas Uses 2.4GHz frequency within ISM band, worldwide compatibility Sunpai Tag proprietary wireles protocol to ensure data securitySupports Power over Ethernet SunpaiTag ability to cascade Base Stations to reduce installation complexity and cost. (1) Electrical Characteristics Parameter DC6V, 2.5A... -
Page 6: Base Station Antenna Pattern
2.3 Base Station Antenna Radiation Pattern Horizontal Pattern Vertical Pattern 3D plot of Base Station Atenna Radiation Pattern... -
Page 7: Base Station Installation
3. Base Station Installation 3.1 Panel Description DC6V Label Name RX Recieve Data LED Lights when data from an ESL is recieved TX Send Data LED Lights when Base Station sends data to ESL Indicates normal System Status SYS System Status LED PWR Power LED Lights when Base Station Powered 6VDC Power Connection... -
Page 8: Power Supply And Networking
Border Switch provides power via Connect PoE Ethernet to LAN Ethernet port Port DB316 Base Station provides power to next Connect PoE Switch to LAN Port Border Cascade Base Station using PoE(do and connect Base Station to EXT... -
Page 9: Installation Conditions
The choice of Base Station position depends on its installation, it should be where possible, in a place free of obstacles that is safe and easy to operate. The DB316 Base Station can be mounted on the ceiling and or walls depending on 3.5 Installation Method Before Installation: Configure all Base Station IP Addresses (refer software manual for instructions for this step). -
Page 10: Precautions
Ensure the distance betwen base stations is less than or equal to 20m. 3.6 Precautions 1) The DB316 power supply shipped has an input range of 100V to 240Vac 360mA please ensure it is able to be supplied with the correct voltage. -
Page 11: Troubleshooting
5. Warranty Thank you for purchasing Sunpai Tag product. The products you have purchased have a limited warranty service during the given warranty period in which w e w i l l provide the warranty services. The product warranty card is sent along with t h e product, please t keep it safe, if the product needs warranty service, please returnit together with the warranty card to Sunpai Tag. - Page 12 Disclaimer: This manual belongs to Shanghai Sunpai Trading Limited, It cannot be reprodu- ced in paert or whole without the express permission of Sunpai Tag, parties that do reproduce in part, or whole ,this document risk legal action. Copyright: Sunpai...
- Page 13 Shanghai Sunpai Trading Limited Address： Room1512,No.145,Lane1399,Husong Load,Songjiang District ,Shanghai,China.201615 :+86 21 67663780 Fax :+86 21 67663781 Web:www.sunpai.com.cn BASE STATION...
