Summary of Contents for Da-Lite Da-Lift 10M
- Page 1 INSTRUCTION BOOK FOR Da-Lift Projector Lift 10M, 15M, 15, 19, 19L...
- Page 2 Milestone assumes no responsibility for accuracy, completeness or sufficiency of the information contained in this document. Da-Lite® is a registered trademark of Milestone AV Technologies. All rights reserved. Important Safety Instructions When using your video equipment, basic safety precautions should always be followed, including the following: Read and understand all instructions before using.
- Page 3 NOTE: Da-Lift projector lift must be installed level! Be sure to leave access from above for installation. Lifting Width Height Depth Height DIm. Dim. Model Capacity Da-Lift 10M 40 lbs. 22-5/8” 15” 22” 4-1/2” 24-1/8” 14” Da-Lift 15M 40 lbs. 22-5/8”...
- Page 4 Side View Of Red (Up) Be Used With L. V .C. Switch & Box 240 Volt Wiring Diagram Da-lite offers two styles of 240-volt wall switches for standard operation. Please see wiring diagram included in wall switch box included with screen.
- Page 5 Side View Of Black (Up) Be Used With L. V .C. Switch & Box 240 Volt Wiring Diagram Da-lite offers two styles of 240-volt wall switches for standard operation. Please see wiring diagram included in wall switch box included with screen.
- Page 6 Da-Lift Projector Lift Adjustment Models 10M, 15M Use a small screwdriver or 5/32” hex wrench and insert in The bottom frame of the Da-Lift is removable and adjustable number 2 switch. Turn counter clockwise for less drop. Check for to ceiling level. Finish the bottom frame to match the ceiling. proper stopping height.
- Page 7 Optional Install 1-1/2 pipe coupling plate for a projector mount. See Figure 6. Loosen set screws to move Mount Channel. Tighten set screws to hold position. 3/8" Screws, Washers, Mount And Nuts Channel Figure 6 Set Screws Coupling Plate Optional Finish the Ceiling Tile Plate by attaching a ceiling tile to it, painting it or other finishing ideas.
- Page 8 Da-Lite’s sole obligation under this warranty shall be to repair or to replace (at Da-Lite’s option) the defective part of the merchandise. Returns for service should be made to your Da-Lite dealer. If it is necessary for the dealer to return the screen or part to Da-Lite, transportation expenses to and from Da-Lite are payable by the purchaser and Da-Lite is not responsible for damage in shipment.
