NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Exploded diagram
Assembly Instruction
Parts List
Ordering Parts
Model
50519
Retain This
Manual for
Reference
OWNER'S
MANUAL
Boxing Stand
Please contact HUNTER LEISURE AUSTRALIA Should any questions
arise at 1800-632-792.
Spare part Service: If you require service, please do not return the
Boxing stand to the store. Contact Hunter Leisure Australia on
1800-632-792.
50519
Advertisement
Summary of Contents for Gymtech 50519
-
Page 1: Before You Begin
NOTE: Please read all instructions carefully before using this product Table of Contents Boxing Stand Safety Notice 50519 Exploded diagram Assembly Instruction Parts List Ordering Parts Model 50519 Retain This Manual for Reference Please contact HUNTER LEISURE AUSTRALIA Should any questions OWNER'S arise at 1800-632-792. -
Page 2: Table Of Contents
ORDERING PARTS…………………………………………………………………………………..11 BEFORE YOU BEGIN Thank you for selecting the 50519 Boxing Stand by Gym Tech. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. -
Page 3: Hardware Pack
PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1. -
Page 4: Assembly Instructions
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach Mid Base Support (#2) to Rear Base Support (#1). Align the holes... - Page 5 and secure them with four M10×20 Allen Bolts (#15) and four Φ10 Washers (#16). B.) Insert two Weight Plate Holders (#5) into the holes in Rear Base Support (#1). Secure each of them with one M10×65 Allen Bolt (#17), two Φ10 Washer (#16) and M10 Aircraft Nut (#18). DIAGRAM 1 STEP 2 (See Diagram 2)
- Page 6 STEP 3 (See Diagram 3) A.) Attach Lower Support (#6) to the Mid Base Support (#2). Align the holes and secure with with two M10×70 Carriage Bolts (#20), two Φ10 Washers (#16) two M10 Aircraft Nuts (#18). DIAGRAM 3...
- Page 7 STEP 4 (See Diagram 4) A.) Insert the Heavy Bag Hanging Hook (#10) through the hole of the Heavy bag Support Frame (#8). B.) Attach the Heavy bag Support Frame (#8) to Upper Support (#7). Secure it with four Φ10 Washers (#16), two M10 Aircraft Nuts (#18) ,M10×70 Carriage Bolts (#20) and one Bracket (#9).
- Page 8 STEP 5 (See Diagram 5) A.) Connect the Upper Support (#7) and Lower Support (#6) together, and attach the Left Slanting Support and Right Slanting Support (#11,12) to Upper Support (#7) and Left Base Support and Right Base Support(#3,#4). B.) Align the top holes and secure with four M10 Allen Bolts (#15) and four Φ10 Washers (#16). Attach the Left Support (#11) to the base with one M10 Allen Bolt (#15) andΦ10 Washer (#16), repeat for other side DIAGRAM 5...
-
Page 9: Exploded Diagram
EXPLODED DIAGRAM... -
Page 10: Parts List
PART LIST KEY NO. DESCRIPTION DESCRIPTION... -
Page 11: Ordering Parts
Rear Base Support Right Slanting Support Mid Base Support □50×50×1.5 End Cap Left Base Support Φ25*1.2 End Cap Right Base Support M10×20 Allen Bolt Weight Plate Holder Φ10 Washer Lower Support M10×65 Allen Bolt Upper Support M10 Aircraft Nut Heavy bag Support Frame M12 Aircraft Nut Bracket M10×70 Carriage Bolt... - Page 12 Operating Instructions Model Number (located on the cover sheet of these instructions) Description of attachments Attachment Number Proof of purchase with purchase date Please don’t send the device to our firm without being requested to do so by our Service team. The costs of unsolicited shipments will be borne by the sender.
