Page 2 Hanaro Cam (Model : KBHC-1) User Manual rœ‰–•ŽGp•–™”ˆ›–•G{ŒŠ•–“–Ž Gj–USGs›‹UG G rœ‰–•ŽGp•–™”ˆ›–•G{ŒŠ•–“–Ž Gj–USGs›‹U rœ‰–•ŽGp•–™”ˆ›–•G{ŒŠ•–“–Ž Gj–USGs›‹U rœ‰–•ŽGp•–™”ˆ›–•G{ŒŠ•–“–Ž Gj–USGs›‹U ››—aVVžžžU’‰›UŠ ››—aVVžžžU’‰›UŠ ››—aVVžžžU’‰›UŠ ››—aVVžžžU’‰›UŠ–U’™ –U’™ –U’™ –U’™G G G G...
Page 3 Before Use FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
Page 4: Table Of Contents
4. KBIT USB Camera Installation ........... 6 5. Hanaro Cam Driver Installation ........... 7 6. Hanaro Cam Setup .............. 13 7. Hanaro Cam Server Program Instructions ......15 8. System Configuration ............30 9. Running Server Program ............ 34 10. Monitoring Camera from Remote Site ......35...
Page 5: Product Specifications And Features
: USB Dimension : 69.5 x 71.2 x 36.0 mm Frame speed USB Camera Mode : VGA(640x480) 15 frames/sec CIF(320x240) 30 frames/sec QCIF(160x120) 30 frames/sec Hanaro Cam Mode : CIF(320x240) max. 30 frames/sec Client View Mode : CIF(320x240) max. 30 frames/sec...
Page 6: Software Included And System Requirements
Installation and User Guide 2. Software Included and System Requirements Software Included: • Windows 98/2000 Driver • Hanaro Cam POP Security Program • Hanaro Cam Program Package Included: • Hanaro Cam Main Body • Install CD • Manual • Audio Cable •...
Page 7: Usb Camera Specification
Hanaro Cam 3. USB Camera Specification 1) Snap shot : Press the button to capture an image and save it to your hard disk. 2) Focus volume : Use this to focus the lens. 3) Indicator : You’ll see a red light when camera is running.
Page 8: Kbit Usb Camera Installation
For further information, check “Chapter 5 HANARO CAM Driver Installation” Next, Click on the “HANARO CAM Setup” to setup a server to watch images using a camera and to copy homepage files to your hard drive in order to watch camera images from other computers not in the area.
Page 9: Hanaro Cam Driver Installation
Hanaro Cam 5. HANARO CAM Driver Installation 1) Windows 98/SE/ME driver installation Insert the program CD and click “HANARO CAM Driver Setup” (USB port installation will begin when you have finished installing the USB driver.) This dialog box indicates that USB driver setup has began Click “Next”...
Page 10 Installation and User Guide Click “Next” Click “Finish” to complete the setup. The Hanaro Cam USB camera Driver installation is complete. As soon as you plug your camera to the USB port, your computer will automatically detect your USB camera.
Page 11 Hanaro Cam You will see this dialog box when you first install the USB camera. Insert Windows 98 CD into the CD-ROM drive, then it will automatically install the driver. However, if driver files can’t be found in your Windows 98 CD, you will see a dialog box below.
Page 12 Installation and User Guide 2) Windows 2000 Driver Installation Insert the program CD into the CD-ROM drive, and then click “HANARO CAM Driver Setup”. (USB port installation will begin when you have finished installing the USB driver.) This dialog box indicates that the USB driver installation is processing.
Page 13 Hanaro Cam Click “Next”. Click “Finish” to complete the setup Plug your camera to the USB port and your computer will automatically detect your USB camera.
Page 14 Installation and User Guide Click “Yes” as seen below. The Hanaro Cam USB camera Driver installation is complete.
Page 15: Hanaro Cam Setup
6. HANARO CAM Setup Insert the program CD into the CD-ROM drive, and then click “HANARO CAM Setup”. You will see following dialog box. Read the License Agreement and then click “Yes” Specify the program folder. If you don’t change the folder, click “Next”.
Page 16 Installation and User Guide When the installation is complete, the “HANARO CAM ” is registered at [Hanaro Cam] in [start]-[programs] menu. And the HANARO CAM shortcut icon is made in desktop.
Page 17: Hanaro Cam Server Program Instructions
Hanaro Cam 7. Hanaro Cam Server Program Instructions Start Hanaro Cam.exe program and the first dialog box will appear. Enter “1234” for password, then click “OK”. Later, you may change the password by clicking “Option” from the menu. 1) File Menu There are “Image Save”, “Image Play”, and “Exit”...
Page 18 Installation and User Guide Select the folder and enter the file name, then click “Save”. You will see a light from the LED dialog box below, which indicates that it is saving the file to the folder. To end saving, click on the “Stop” button below: Clicking on the “Save Mjpeg”...
Page 19 Hanaro Cam Select the folder containing the saved files that you wish to play and click on “OK.” Select a file, then click on the play button to play your file. Play button...
Page 20 Installation and User Guide If you click the “Pause” button while the file is playing, it will stop at that point. Click the “SAVE” button and you will see dialog box below. Enter the new file name. Current frame will be saved as a jpeg file.
Page 21 Hanaro Cam When you press the “Pause” button while you are playing a video clip, press the “Rewind” button to go back to the previous frame. Each time you press the back button, you will go back one image at a time.
Page 22 Installation and User Guide The “Stop” button will stop playing the current image file. Press the “EXIT” button to end the Image Play. Clicking the Mjpeg Play button is a shortcut and performs the same function as “Image Play” of the “File”...
Page 23 Hanaro Cam 2) Security Menu There are “Security Mode”, “Timer Recording”, “Sensitivity” and “MotionBox” sub-menus on the Security Menu. In “Security Mode”, the program will compare a previous image to the current image. If a movement occurs, it will perform all the necessary tasks plus the settings from the “Option”...
Page 24 Hanaro Cam is to brightness of light. For instance, if you set the value to 0, the Hanaro Cam will not react to any changes in brightness. If you set the value to 100, the Hanaro Cam...
Page 25 Hanaro Cam You will see following dialog box if you click on “MotionBox” from the menu. “Boxes” is number of region for motion detection. If you check “Operating Area detection when security mode is on”, motion is detected at the box regions instead of whole image while “Security...
Page 26 Installation and User Guide If you want to change box size, mouse cursor is located at edge of box and then drag mouse like following picture. If you click on box 1 in tab, you can set sensitivity of motion box 1. Each box can have own sensitivity value.
Page 27 Hanaro Cam 3) Setup Menu There are “Option”, and “Camera Setting” in the Setup menu. If you click “Option” from the Setup menu, you will see the following dialog box. If you click the “Edit” button from the Homepage directory, you will see this dialog box.
Page 28 Installation and User Guide Port : Select port number for the “Hanaro Cam Internet View”. This is usually port 80, the default setting. Click “Edit” button from directory of saving video at security mode and you will see a dialog box. This setting...
Page 29 Hanaro Cam Re-enter the new password to confirm your new password. You will need this password to log on to your homepage to see images. If you click “Modem Setup”, you will see following dialog box. You can select your modem port and modem speed, then click “OK.”...
Page 30 Alarm on security mode: When a movement is detected, the program sounds an alarm. Always Top : HANARO CAM server program is always visible, even while it’s running in the background. Print pixel for motion: when motion detection is operated, moving boundary is shown.
Page 31 Hanaro Cam 4) View Menu There are “KBIT”, “Help” and “IP View” submenus in the View Menu. Click the “KBIT” submenu to see all information about program version and copyright. Click the “Help” submenu to get further assistance. Click the “IP View” submenu to get ip address information.
Page 32: System Configuration
Installation and User Guide 8. System Configuration 1) Network Setup The product was designed to use LAN or Dial-Up connections to the program. You must have either LAN card (Ethernet card) or a modem installed on your computer. To check, click [Start], [Setting] and [Control Panel] and open [Network] item.
Page 33 Hanaro Cam Click on the Properties of TCP/IP for LAN card adapter and put the IP address and subnet mask. And also, complete the settings in Gateway and DNS tab. Remember the IP address to connect from outside. Consult your network administrator for the IP address.
Page 34 Installation and User Guide If there is no Dial-Up server icon on the status bar, click [Start], [Settings], [Control Panel] and double click on the ADD/Remove programs icon. Click the Windows Setup tab, then double click on communications and make sure the Dial-Up Network and Dial-Up server are selected.
Page 35 Hanaro Cam Follow the instructions below using [Dial-Up server] on the Connections Menu. 1. Double click on the Dial-Up Network folder on Windows desktop to start the setup procedure. (or click [Start], [Program], [Accessories] and [Dial-Up network] and then click on “cancel’ if the Dial-Up network wizard dialog box appears.
Page 36: Running Server Program
Installation and User Guide 9. Running Server Program ► Running Hanaro Cam Program ► Use “Dial-Up Server” to connect to the internet.
Page 37: Monitoring Camera From Remote Site
Hanaro Cam 10. Monitoring Camera from a Remote Site ► In case of modem connection from outside to modem server: You need to enter your home PC phone number to connect to your home PC using a Dial-up Network. Enter 192.168.55.1 in the address bar when you logon to the Internet.
Page 38 Installation and User Guide Enter your IP address in the Microsoft Internet Explorer address bar and you will see the following picture: Enter the password...
Page 39 Hanaro Cam You will see your computer camera screen at remote site If you press the “Click” button in Internet Explorer, you will see following window.
Page 40: Tips
[Q1]: Can I minimize your Hanaro Cam server? [A1]: Yes, double click mouse right button on any space that is not a button on the Hanaro Cam server. Just left click on the task bar or press Alt+Tab key if you want to be active again.
