Rev: A1
Body Composition Analyzer and Scale
SF1402B
Instruction Manual
Thanks for purchasing the
Body Composition Analyzer and Scale
manufactured by
Bpump.
Please read the instruction manual before usage;
Please dispose the
Body Composition Analyzer and Scale
and battery in accordance with
local regulations.
page1of23
Advertisement
Table of Contents
Summary of Contents for Pump Medical SF1402B
- Page 1 Rev: A1 Body Composition Analyzer and Scale SF1402B Instruction Manual Thanks for purchasing the Body Composition Analyzer and Scale manufactured by Bpump. Please read the instruction manual before usage; Please dispose the Body Composition Analyzer and Scale and battery in accordance with local regulations.
-
Page 2: Table Of Contents
Rev: A1 Table of Content 1. Safety Information ........................3 1.1. Danger ..........................3 1.2. Warning ..........................3 1.3. Precaution ......................... 3 2. Indication for Use ........................4 3. Product Structure ........................5 4. Operation Instruction ......................... 6 4.1. Precautions in Use ......................6 4.1. -
Page 3: Safety Information
Rev: A1 1. Safety Information 1.1. Danger (Operation errors lead to death or serious injury) Do not use in conjunction with following electronic medical device in avoid of life threating. ● Implantable medical device such as pacemakers; ● Life-sustaining medical device such as artificial heart; ●... -
Page 4: Indication For Use
Rev: A1 falling. Please do not reverse the battery poles during battery replacement in avoid of harm caused by battery leakage, fever or broken. Please take out the battery in case of non-use for a long time (3 months above). Please stand up straight and keep still during the measurement in avoid of affecting measurement result. -
Page 5: Product Structure
Rev: A1 3. Product Structure Water contentratio Bluetooth Battery symbol Group Numerical display Muscle mass Weight Visceral fat index Physical Age Basal metabolism Unit Bone content Measurement Indicators Left Arrow: use to select mode or Right Arrow: use to select mode decreasenumericalvalues or increase numericalvalues SET Key... -
Page 6: Operation Instruction
Rev: A1 4. Operation Instruction 4.1.Precautions in Use Do not use the device under strong electrostatic or electromagnetic environment, otherwise may cause inaccurate measurementor device failure; Take measurement barefoot, otherwise it is unable to gain accurate physiological indexes such as body fat ratio; Do not use the device above soft surfaces such as mats or carpet, otherwise the device surface may sunk due to impact stepped on, which may lead to inaccurate measurement;... -
Page 7: Personal Data Setting
Rev: A1 ifmeasurements are taken once a day at room temperature (23°C); 2) The batteries enclosed are used for trial, which may be used up soon; 3) Do not use rechargeable batteries, otherwise may cause misoperation. Battery symbol flashing means that the battery is running out, replace four new AAA alkaline new batteries of same model if happens;... -
Page 8: Take Measurement
Rev: A1 confirmation (fig6); Fig 3 Fig 6 Fig 4 Fig 5 Setting is complete till now, you can start physiological indexesmeasurement such as weight, the body fat ratio, visceral fat index and others. 4.4. Take Measurement 4.4.1. Precautions for Measurement Personal data setting is needed if you want to use under “Group”... - Page 9 Rev: A1 on the screen indicates the device has finished measurement (fig 12); Note: barefoot step on the electrode slice double foot at the same time Fig 10 Fig 11 Fig 12 4.4.2.2. Weight Measurement Only Power On/Off Power on the device and wait for a while, "0.0 kg" will appearon the screen (fig 2); Note: automaticpower on can be triggered in casea person/thingupon weighting over page9of23...
-
Page 10: Display The Measurement Result
Rev: A1 10kg on the device. Weight Measurement (1) Step onto the platform with correct posture barefoot, otherwise the device is unable to display correct physiological indexes (fig 10, fig 11); (2) Stand still and keep your posture for a while, the weight value will display on the screen (fig 13);... -
Page 11: Data Transmission
Rev: A1 4.4.3.2. Unit Switch Under standby status (showing "0.0 kg" on the screen), you can enter “unit switch” interface by long pressing "SET" button; use buttons to select the unit, then press SET button for confirmation; The available units are metric and imperial such as "cm , kg","ft, lb "(fig15, fig 16). -
Page 12: Reference Standards
Rev: A1 5. Reference Standards 5.1. Weight Standard Weight Result ≤-10.0% -9.9%~9.9% Normal 10.0%~19.9% Mild High ≥20.0% 5.2. Body Fat Ratio Standard Body Fat Ratio is the proportion of fat to the total body weight. Body Fat Ratio Result Male Female 2.0~13.9% 10.0~20.9%... -
Page 13: Muscle Mass
Rev: A1 Result 18.8～22.9 Normal 24～27 Mild ≤28 High 5.6. Muscle Mass Muscle Mass (including skeletal and smooth muscle) make up 70% of weight in ordinary population. 5.7. The Average Bone Mass Presumption Male Female ≤ 60kg～75kg ≥ 75kg ≤ 45kg 45kg～60kg ≥... -
Page 14: Error Indication
Rev: A1 6. Error Indication Error Cause Correction Do not sway or leave during 1) The user sways or leaves the measurement; device during measurement; 2) Do not take measurement Take measurement barefoot; barefoot; Step onto the platform with correct 3) The device is unable to detect the posture barefoot to take human impedance. -
Page 15: Trouble Shooting
Rev: A1 7. Trouble Shooting PROBLEM CAUSE CORRECTION Device shows "0.0 kg", or almost no value. increase Step onto the device before Step onto the device after after stepping on; "0.0" displayed; "0.0" displayed; Abnormally high or low measurement value; Please follow the correct Wrong Posture;... -
Page 16: Product Specification
Rev: A1 8. Product Specification Body Composition Product Name Model SF1402B Analyzer and Scale Power Supply 4 AAA battery Auto power off Unattended 1min ≤50kg: ±0.4kg 4 groups parameters which Accuracy 50kg～100kg: ±0.5kg Memory have been seted up ≥100kg: ±0.6kg Weight: 0.0kg～150.0kg... - Page 17 Rev: A1 Disposal This product must not be disposed together with the domestic waste. All users are obliged to hand in all electrical or electronic devices, regard less of whether or not they contain toxic substances, at a municipal or commercial collection point so that they can be disposed of in an environ mentally accept able manner.
-
Page 18: Care And Maintenance
Rev: A1 9. CARE AND MAINTENANCE 9.1. Daily Maintenance The device should be cleaned before storage; Soft dry cloth can be used to remove dirt on the device; Do not wash the device, otherwise it may malfunction; Do not use volatile and harsh detergent to remove dirt, or device will be faded or malfunctioned;... -
Page 19: Electromagnetic Compatibility Guide
Rev: A1 ◆ Electromagnetic Compatibility Guide Important information regarding Electro Magnetic Compatibility (EMC) With the increased number of electronic devices such as PC’s and mobile (cellular) telephones, medical devices in use may be susceptible to electromagnetic interference from other devices. Electromagnetic interference may result in incorrect operation of the medical device and create a potentially unsafe situation. - Page 20 Rev: A1 Guidance and manufacturer’s declaration – electromagnetic immunity The [EQUIPMENT or SYSTEM] is intended for use in the electromagnetic environment specified below. The customer or the user of the [EQUIPMENT or SYSTEM] should assure that it is used in such an environment. Immunity test IEC 60601 test Compliance...
- Page 21 Rev: A1 Guidance and manufacturer’s declaration – electromagnetic immunity – for EQUIPMENT and SYSTEMS that are not LIFE – SUPPORTING Guidance and manufacturer’s declaration – electromagnetic immunity The [EQUIPMENT or SYSTEM] is intended for use in the electromagnetic environment specified below.
- Page 22 Rev: A1 Recommended separation distances between portable and mobile RF communications equipment and the EQUIPMENT or SYSTEM – For EQUIPMENT and SYSTEMS that are not LIFE – SUPPORTING Recommended separation distances between portable and mobile RF communications equipment and the [EQUIPMENT or SYSTEM] The [EQUIPMENT or SYSTEM] is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled.
-
Page 23: Product Registration Information
Production license No.: Guangdong FDA Device Production: 20081657 Registration certificate No/product specification No: Guangdong Device Registration: xxxxxxxx ◆After-Sale Service Manufacturing Enterprises: Shenzhen Pump Medical System Co., Ltd. ADD: 2/F, M-7 SinosteelBuilding, Maqueling Estate, Hi-Tech Industrial Park, Nanshan District, Shenzhen, People’s Republic of China...
