Summary of Contents for AudioControl DQDX
Page 1
Six-Channel Pre-amp Processor with Signal Delay, Equalization and Selectable Electronic Crossover Greetings from the rainforests of the Pacific Northwest. The DQDX is your gateway to amazing sound from any aftermarket audio system. It is a compact, six channel, high-performance signal processor with in-...
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manu- facturer’s instructions.
Page 3
The lightning flash with arrowhead symbol within an equilateral trian- gle is intended to alert the user to the presence of uninsulated “danger- ous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user of the presence of important operating and maintenance (ser- vicing) instructions in the literature accompanying the appliance.
Remote turn on output provides a 12-volt trigger to turn on your amplifier • Built in Pink Noise for easy Signal Delay and Equalizer tuning and system set-up • Bulletproof 5 year warranty (when installed by an authorized AudioControl dealer) ----------------------------------------------- 4 -----------------------------------------------...
Note: If your source unit has front, rear, and subwoofer RCA Line Level outputs, connect them to the corresponding inputs on your DQDX. If your source unit has only front and rear inputs fear not! Just connect these to the front and rear inputs on the DQDX and switch the “Sub to Front”...
Page 6
VERY IMPORTANT! Make sure the input gain control on your aftermarket amplifier(s) are all the way down (usually counter clockwise). Turn on the system and level match your DQDX to your source unit and amplifiers. Select the correct crossover point on your DQDX to create a Hi-...
Page 7
AudioControl components. To reinforce this point, if you have an Authorized AudioControl dealer install your DQDX, we will extend the normal one-year war- ranty to a full FIVE years parts and labor. Complete details of this warranty are listed at the end of this manual and on our website at www.audiocontrol.com.
Page 9
If your source unit has front, rear, and subwoofer RCA line-level outputs, connect them to the three sets of corre- sponding inputs on your DQDX. If the source unit only has one output, the Front to Sub circuitry in your DQDX selectively routes the Front input channels to the subwoofer channels when you have the jumper in the appropriate position.
Page 10
2 Amp. Doing so may damage your DQDX. Remote In: This is the ‘on’ and ‘off’ selector for your DQDX. Con- nect this wire directly to your source unit 12Volt trigger wire. If...
Page 11
Subwoofer level. Additionally, if you press and hold the remote down for 4 seconds, the outputs of the DQDX will turn from music to Pink Noise. This will assist in the proper setting of the EQ and Delay. When the DQDX is in Normal mode, pressing the remote momentarily will defeat all process- ing on the DQDX (Equalizer and Signal Delay).
Page 12
Under the Covers - Internal Jumpers You can optimize your DQDX using most of the controls mounted on the top of the chassis. However, we recognize there are situations where advanced users may have the need to configure the DQDX for specific applications.
Page 13
DQDX. If your source unit has only front and rear inputs, just connect these to the front and rear inputs on the DQDX and switch this “Sub to Front” jumper to the ON position. Changing this jumper to ON will route the low pass signal (as defined by your crossover selection) to the Sub outputs of the DQDX.
Page 17
The following steps will guide you in delaying the appropriate speakers for just a few milliseconds, so the DQDX is able to allow the different signals to arrive at the same time, putting the driver in perfect acoustical alignment.
Page 18
Normal Mode (ACR-3 Dash Knob controls the Sub Out) NORMAL LED ON ACR-3 Both LEDs ON • Signal Delay Engaged • Equalizer Engaged ACR-3 Blue LED Only • Signal Delay Disengaged • Equalizer Disengaged Set-up Mode (Dash Knob controls the Signal Delay) SET-UP LED ON Blue LED Flashing, Red LED Solid • Signal Delay Adjustment is Left to Right Blue LED Flashing, Red LED Off •...
Page 19
Once you have everything where you want, it you are done! Easy right? Now just go back to the Signal Delay knob on the DQDX and turn it back to Normal mode (its blue LED will come on) and you are ready to move to the next step of set-up.
Page 20
Take a careful look at the “curve” on your analyzer and how one frequency combines with the next. There is no one curve that will satisfy every person, as we all have different tastes. The key is to use your DQDX to help balance your -----------------------------------------------20 ----------------------------------------------...
Page 21
The key in this area is to have enough speakers and power to produce the amount of bass you desire but don’t use the controls on the DQDX to try and force your speakers to produce sounds they can’t. Too much bass boost creates a condition called “speakerus explodus”, which is not pretty.
Page 22
Many autosound systems start a gradual decline in this area which is why speaker placement is very important. The DQDX only gives you a few controls in this area because too much boosting can really make a speaker sound un-natural.
Page 23
The DQDX comes with a 24/dB Octave Linkwitz Riley alignment crossover that lets you select the exact crossover point you need for your system. The crossover frequency markings on your DQDX are for reference purposes only. The exact crossover frequency can be found in...
If you are hearing music, go back to step #2… If you are hearing voices, please go see a doctor! Starting with the DQDX input level controls, adjust the control knob clockwise until the Input Maximized LED just begins to flicker.
Parallel Outputs The DQDX has our unique Front to Sub circuit input that allows the Front input signal to feed the Subwoofer outputs, when no Subwoofer input is available. This allows your DQDX to accept front and rear inputs channels and give you Front, Rear, and Subwoofer output channels.
Page 26
DQDX. With this diagram you can follow each input through the proces- sor. If you do have an issue with the hook-up of your DQDX and need to call for technical assistance, please have this diagram available so we can help you trace the problem and get your system up and running and sounding as awesome as we know it can.
Page 28
If you meet all of these conditions, we will warranty all materials and workmanship on the DQDX for one year from the date you bought it (five years if it is installed by an authorized United States AudioCon- trol dealer).
Page 29
DQDX has been used improperly. Now that may sound like a big loophole, but here is all we mean by it. Unwarranted abuse is: (A) physical damage (don’t use the DQDX for a car jack); (B) im- proper connections (120 volts into the power jack can fry the poor thing);...
Page 30
DQDX SPECIFICATIONS All specifications are measured at 14.4 VDC (standard automotive voltage.) As technology advances, AudioControl reserves the right to continuously change our specifications, in our never-ceasing quest for audio righteousness. Maximum output level ............... 7.5 Vrms Output attenuation ..............+/-12 dB Frequency response ............
Page 31
AudioControl, Making Good Sound Great and DQDX are all trademarks of AudioControl Inc. This manual was conceived, designed, and written on a cold and windy day in the Pacific Northwest which is what the locals from Seattle call “spring.” -----------------------------------------------31 ----------------------------------------------...
Page 32
® Making Good Sound Great ™ 22410 70 Ave West Mountlake Terrace, WA 98043 USA Phone 425-775-8461 • www.audiocontrol.com P/N 913-125-0 Rev B...
