Page 2: Package Content
IAdea PSP 2-Port True 4K Advanced HDMI Splitter Solution Package content: Power adapter Velcro Instruction Sheet Smart splitter Copyright© 2019 IAdea all rights reserved... - Page 3 IAdea 2-Port True 4K Advanced HDMI Splitter Solution Physical views and features: Copyright© 2019 IAdea all rights reserved...
- Page 4 IAdea PSP 2-Port True 4K Advanced HDMI Splitter Solution Power LED: Visible light indicates splitter is ready for use. Micro USB Port: Input to connect splitter to the 5 V DC power supply. EDID Mode: Choose splitter performance by adjusting DIP switch.
-
Page 5: Installation
IAdea 2-Port True 4K Advanced HDMI Splitter Solution Installation: How to broadcast one HDMI signal to two HDMI-compatible displays? Power down all devices intended for use, including the HDMI-compatible displays which will be connected to HDMI-Out 1-2. Connect the HDMI-compatible displays to HDMI-Out 1-2. -
Page 6: Troubleshooting
IAdea PSP 2-Port True 4K Advanced HDMI Splitter Solution Troubleshooting: To ensure proper video outputs from the splitter, the user needs to make sure the following splitter implementation requirements are satisfied: Connected HDMI-compatible displays support Full HD videos. Connected HDMI-compatible display with the lowest resolution must be connected to HDMI-Out 1. - Page 7 Resolution downscaling from 4K2K @ 60 4:2:2 to 1080p. 4K2K @ 60 4:2:2 to 4K2K @ 60 4:2:0. Frame rate conversion. PSP-102U can bypass 4K HDR data content but, CANNOT process it and make HDR content completely fit into 1080p. Copyright© 2019 IAdea all rights reserved...
-
Page 8: Technical Specification
IAdea PSP 2-Port True 4K Advanced HDMI Splitter Solution Technical Specification: PSP-102U Functions HDMI compliance HDMI 2.0a HDCP compliance HDCP 2.2 / 1.4 Input HDMI x 1 Output HDMI x 2 HDMI connector Type A (19-pin female) Video bandwidth Single-link 600 MHz (18 Gbps) - Page 9 IAdea 2-Port True 4K Advanced HDMI Splitter Solution PSP-102U Mechanical Dimension 82 mm x 62 mm x 18 mm System (3.2" x 2.4" x 0.7") 198 mm x 137 mm x 74 mm Package (7.8" x 5.4" x 2.9") Weight System 124 g (0.274 lb)
- Page 10 IAdea Headquarters IAdea America Corp. 3F, No.21, Lane 168, Xiangshan Road 20 Fairbanks, suite 170 Taipei, Taiwan 114 Irvine, CA 92618 Phone: +886-2-2791-1110 Fax: +886-2-2791-1170 Phone: +1-949-305-6489 Email: sales@IAdea.com Email: us-sales@IAdea.com...
