UltraCOOL CP70 Troubleshooting

Problem:
Cooler does not pump
water
Fan does not operate
No. Description
1 Evaporative Media..................................................................................110132-3
2 Evaporative Media Frame Assembly......................................................110874-1
3 Water Tray ..............................................................................................110874-3
4 Water Distributor Nozzle ........................................................................110874-4
5 Keepers (Set of 4) ...................................................................................110871
6 Pump .......................................................................................................110439-1
7 Drain Plug ...............................................................................................110698
8 Float Assembly .......................................................................................110873
9 Swivel Casters - Non-Locking ...............................................................110822-6
10 Swivel Casters - Locking........................................................................110822-7
11 Pedestal ...................................................................................................110874-2
12 Water Distributor Tubing ........................................................................110734-1
13 M4 x 12mm Pan Head S.S. Screws (Qty 2) ...........................................111130
14 M4 x 12mm Truss Head S.S. Screws (Qty 4) ........................................111131
10
Trouble Shooting
Cause/Remedy:
• Water level is low. Fill with water and make sure Pump is activated.
• Pump may be defective. Replace pump.
• Check that unit is plugged into a 120V power receptacle.
• Check the fuse or breaker.
• If connected to a GFCI outlet, check if it is tripped.

Replacement Parts

8
11
10
14 9
9
4
4
5
7
6
CP70
3
1
12
2
13
5
