802.11N Broadband wireless access point S0-738

台揚集團智慧財產

任何未經授權逕予複製、重製、公開或使用本文之行為，將被視為侵害

台揚集團之智慧財產權，將可因此負擔法律責任。

S0-738 User Manual

43-S0-738 User Manual

Orinda Networks

English user manual

MTI Group Proprietary Information

Any unauthorized use, duplication, reproduction, or disclosure of this document may be

considered as infringement of MTI Group's intellectual property rights, the infringer may

be accused and liable applicable legal penalties.

PAGE：

DATE:10-14-2008

Table of Contents

Need help?

Do you have a question about the S0-738 and is the answer not in the manual?

Questions and answers

Summary of Contents for Orinda Networks S0-738

Page 1 PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Orinda Networks 802.11N Broadband wireless access point S0-738 English user manual MTI Group Proprietary Information 台揚集團智慧財產 Any unauthorized use, duplication, reproduction, or disclosure of this document may be 任何未經授權逕予複製、重製、公開或使用本文之行為，將被視為侵害 considered as infringement of MTI Group’s intellectual property rights, the infringer may 台揚集團之智慧財產權，將可因此負擔法律責任。...
Page 2 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Key information The contents of this manual because of the different software versions vary, the latest specification, Products of the new functional, manual content, etc., without prejudice to the normal operation of equipment...
Page 3 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified of this product Questions or doubts, please refer to the last page of the above manual customer support Contact us To obtain answers.
Page 4: Table Of Contents
3.2 Enter the web interface settings ..............17 3.3 AP configuration ......................20 3.3.1 System Settings..................... 21 9 Appendix ............................35 9.1 S0-738 Specifications ....................35 9.2 Abbreviations ........................37 9.3 Frequently Asked Questions and Answers ............38 MTI Group Proprietary Information 台揚集團智慧財產...
Page 5: 1.1 Performance
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 1 Orinda interior network can be wireless access points outlined 1.1 Performance A new generation of broadband wireless access point products - 11n enterprise-class interior AP, working at 2.4GHz frequency band, in line...
Page 6: 1.2 Applications
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified security Supporting VoIP, Protocol Supporting QoS； Supporting network management protocol SNMP Using all-metal shell mold casting, beautiful, convenient transportation and installation. 。...
Page 7: Product Packaging Information
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Audit Working Group in the Customer Service; Mobile workers access to the database Doctors, nurses, retailers, at hospitals, retail stores or offices on campus to access the database when the mobile office；...
Page 8: Product Appearance
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 220V, output +6 V/2A The installation 1 Deputy of the back plane Installation of 1 Packet structural parts Note: If more than the omission of missing or fittings can not be used to come in the original...
Page 9: Backplane Interface
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified To ensure the power supply is at the normal circumstance, Net lines used to connect to the CABLE / ADSL MODEM or other entities on the network, the normal green light for always.If instructions are not normal, first check the cable...
Page 10: Equipment Installation
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified RESER key Reset button 2.3 Equipment Installation 2.3.1 Basic installation principles AP signal coverage up to 1000 meters at the outdoor, indoor 400 meters up, in this context at any place you can wirelessly access network resources.
Page 11: Equipment Installation
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 2. The estimated AP, the presence of gateways, routers and the straight-line distance between the hosts. 3. Signal the scope of building materials due to differ.
Page 12: Configuration Ap
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Install the antenna to the ANT port AP on, fastening, installation has finished. 3 Configuration AP 3.1 Computer network adapter settings 1.
Page 13 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 4.In the Internet agreement (TCP/IP) attribute, the revision “uses following IP address” and “uses following DNS server site”, inputs in order, IP address: 192.168.0.x (x cannot be 0, 1, 254), the subnet covers the code: 255.255.255.0 and...
Page 14 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 5.Confirmed whether the computer does obtain the correct IP address Please to start to move is opening the field input “cmd”, and presses the Enter Enters the DOS pattern, the input “ipconfig”, and according to Enter.Confirmed...
Page 15: Enter The Web Interface Settings
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 3.2 Enters the web establishment contact surface Click “Internet Explorer” browser Presses down “the stop” the key, the choice “the tool”, the spot chooses “the Internet option”.
Page 16 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified the blank, then the click “determines”. Finally clicks “determined” the key leaves Turns on the IE browser, arranges in order URL place in the website to input MTI Group Proprietary Information 台揚集團智慧財產...
Page 17 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 192.168.0.1, the carriage return determination; User Name: admin Pass word:( Password Empty) Enter the user name and password, mouse click "OK", enter the AP software interface index.
Page 18: Ap Configuration
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Choose https entrance page prompted. Choose "Yes", enter the product configuration page. If you choose "http entrance" directly into the product configuration page.
Page 19: System Settings
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 3.3.1 System Settings 1. IP settings Used to obtain dynamic IP at the network has been forming, AP's IP address linked up by the AP by the three-tier distribution network equipment arbitrary static address is the user's own planning by the AP's IP, easy to manage.
Page 20 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Note: Change all the settings and then click the "Apply" to update, and then click on "restart" OK. 2. Wireless network configuration Click on the "wireless network"...
Page 21 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Channel configuration. Have 11 channels to choose from. Each AP configuration at a time when the same channel should not occur otherwise channel interference. Go through the drop-down menu select the required channel.
Page 22 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified system from disruption or conflict in a faster restore. RTS / CTS mechanism for detailed information please see the IEEE 802.11 standard.
Page 23 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Security settings of two parts ACL Set (Access Control List) Click to enter the settings page There are three buttons MTI Group Proprietary Information 台揚集團智慧財產...
Page 24 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Users according to their own needs or to refuse to allow only a maximum of eight users access. Only required at the following list box fill in the computer's MAC address 2.
Page 25 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 128 bits：Hexadecimal number of 26 You can freely set the password in the password box to control user access. (3) WPA-PSK WPA simplified model, it does not need special authentication server.
Page 26 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified (4)WPA2-PSK The use of pass phrase or key to verify that your wireless online. British number one key for the password mixed, ranging between 8 and 63 characters.
Page 27 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified (5) WPA Provide users with the necessary authentication credentials, such as user name password, through specific implementation of the RADIUS server.
Page 28 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Note: Change all the settings and then click the "Apply" to update, and then click on "restart" to determine 3. DHCP Settings DHCP dynamic allocation of IP.
Page 29 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Note: Change all the settings and then click the "Apply" to update, and then click on "restart" OK. 4. VLAN Setting...
Page 30 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Each VLAN can be under the independent set up your own SSID and security certification Note: setting please refer to: wireless network configuration in a secure manner. One of WEP encryption keys for the four shared.
Page 31 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 5. SNMP settings This feature for network management, network management software, together with the required use.. Groups who read and write at the box fill in your Writing your name can be named.
Page 32 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 7. System Settings Landing on the AP password to modify MTI Group Proprietary Information 台揚集團智慧財產 Any unauthorized use, duplication, reproduction, or disclosure of this document may be 任何未經授權逕予複製、重製、公開或使用本文之行為，將被視為侵害...
Page 33: Appendix
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 9 附录 9.1 S0-738 Technical Specifications Performance Indicators 2.4～2.4835GHz Band job IEEE 802.11N Draft2.0 Network protocol 802.11b 23.5dBm Transmitting 802.11g 22.5-19.5dBm power 802.11n HT20 23.5-12.5dBm...
Page 34 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 0℃ ～ +50℃ Operating temperature -20℃ ～ +80℃ Storage temperature Humidity 0 ~ 95% non-condensing Physical unit Network A 10/100BaseT Ethernet port...
Page 35: Abbreviations
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified DHCP Server/Client Network function Support 8 VLAN & SSID Network Supporting SNMP v1/v2c, MIB-II Management Configuration Web interface and Telnet support support 9.2 Abbreviation...
Page 36: Frequently Asked Questions And Answers
台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified RADIUS Remote Authentication Dial In User Service RSSI Received Signal Strength Indication Request To Send SNMP Simple Network Management Protocol Secure SHell...
Page 37 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Make sure your computer has a wireless connection on Products； Try to ping an existing Internet's IP address AP obtained from the ISP when IP address problem。...
Page 38 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified functions of HTTP, the download speed if a long time more than 100M, will cause excessive load of wireless products, has not been able to handle the data, please restart the power product。...
Page 39 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified outdoors, may I ask is that true? Express these values are the furthest distance transmission distance, as a theoretical value, because in fact the user environment will be...
Page 40 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified 2.4G devices exist other strong interference signals, try to turn off other 2.4G equipment to view the situation is improving; will produce interference shielding device, or location adjustment;...
Page 41 台揚企業集團 S0-738 User Manual PAGE： 43-S0-738 User Manual DATE:10-14-2008 MTI Group. ISO 9001 Certified Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
