(Part-no. VFD 1285 0277) affect the EMC. CP114 will be controlled by the ABS Pump Controller PC111 (part-no. 1270 0002). Useable PC111 units with the Figure 1 Pump controller PC111 connections must be carried out in accordance to the enclosed wiring diagram.
Page 3
Installation and Operating Instructions ABS Control panel CP114 Options • Backup-battery 12 V; 1,2 Ah (part-no. 6216 0961) It is possible to operate parts of the PC111 unit independent of mains. An integrated charger functions as a • Thermostatic controlled heater 230 V, 10 W (part-no. 6216 0088) If unfavourable mounting is necessary e.g.
Page 4
Installation and Operating Instructions Installation and Operating Instructions ABS Control panel CP114 part-no when distributed. An examination of the parameters is urgently recommend. Figure 2 Frequency converter (Fa. Schneider Electric) A VFD of the Schneider Electric company, type Altivar ATV12 is used.
Installation and Operating Instructions ABS Control panel CP114 Technical data (further technical data see manual PC111 and ATV12) Ambient operating tempera- ture Ambient storage temperature Humidity 5 – 95 % non-condensing Dimensions HxBxT 420 x 300 x 230 mm Depth top edge lock...
Page 6
I ABS Production Lohmar GmbH I Scheiderhöher Straße 30-38, D-53797 Lohmar, Germany I I Tel. +49 22 46 900 0 I Fax +49 22 46 900 200 I www.absgroup.com I GB 0825-A...
