DORNA TECHNOLOGY DLA1 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

DORNA TECHNOLOGY CO., LTD
DLA1 Series Inverter
User Manual (V2.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DLA1 Series and is the answer not in the manual?

Questions and answers

Related Manuals for DORNA TECHNOLOGY DLA1 Series

Summary of Contents for DORNA TECHNOLOGY DLA1 Series

  • Page 1 DORNA TECHNOLOGY CO., LTD DLA1 Series Inverter User Manual (V2.0)

  • Page 2: Table Of Contents

    Table of Contents 1 Summary ....................... 4 1.1 Name plate ......................4 1.2 Product series ...................... 5 1.3 Technical standards ..................... 6 1.4 Peripheral Electrical Devices and System Configuration ........8 1.5 Product outline and installation dimensions ............9 1.5.1 Product outlines (unit: mm) ................... 9 1.5.2 Production dimension table .................
  • Page 3 5.2 Other fault and solutions ................... 94 6 Repair and maintenance ................96 6.1 Routine maintenance ..................96 6.2 Replacement of vulnerable components ............96 7 MODBUS communication protocol .............. 97 7.1 Communication protocol ................... 97 7.2 Verification mode .................... 100 7.3 Communication addresses ................
  • Page 4 Safety Precautions Please pay close attention to all safety-related information in this user manual; otherwise there may be fatal consequences. Please note the manufacturer shall bear no liabilities to damages of any sorts resulting from false operations which is not following this user manual. Warning ---- potential risks.
  • Page 5 Quick installation guide Flowchart for installation & maintenance: Tasks References Remove the packaging and Chapter 1 check inverter model. Confirm inverter capacity is compatible with motor. Check environment and input/ output cables. Main circuit wiring. Chapter 2.5 Control circuit wiring. Chapter 2.6 Check installations Chapter 2.4...
  • Page 6 Attention: please follow inverter installation location requirements strictly.  Environmental requirements for installation of inverters: -10°C to +40°C (derate 1% for every °C if the ambient temperature is between Temperature 40°C and 50°C) Less than 1000m (derate 10% for every 1000m if the altitude is above 1000m) Altitude ...

  • Page 7: Summary

    POWER： 2.2kW Power INPUT： AC3PH 380V 50Hz/60Hz 6A Input power OUTPUT： AC3PH 0～380V 0～300Hz 5A Output S/N： Barcode Dorna Technology CO.,ltd DLA 1-0D75 T 4 G G: general-purpose 【1】 【6】 Inverter series P: Light load Rated input voltage： 【2】 【5】...

  • Page 8: Product Series

    1.2 Product series Rated output Rated input current Rated output Inverter model power (kW) current (A) Single Phase input: AC 220V -15%~+10%, 50/60Hz DLA1-0D40S2G DLA1-0D75S2G 0.75 DLA1-01D5S2G 14.1 DLA1-02D2S2G 11.8 Three phase input: AC 380V -15%~+10%, 50/60Hz DLA1-0D75T4G 0.75 DLA1-01D5T4G DLA1-02D2T4G DLA1-0004T4G 10.5...

  • Page 9: Technical Standards

    1.3 Technical standards Item Specifications Control system Current Vector General Purpose Inverter. Compatible motor Induction motors. Maximum Vector control: 0~500Hz; frequency V/F control: 0~500Hz. Carrier frequency 0.8kHz~12kHz; Depending on load, can automatically adjust. Input resolution Digital: 0.01Hz; Analog: maximum frequency×0.025%. Open vector control (SVC);...
  • Page 10 Two-motor Two motors can be switched over via two groups of motor switchover parameters. Fieldbuses RS485  Keyboard  Control terminals Command source  Serial communication port You can perform switchover between these sources in various ways. 10 frequency sources, such as digital setting, analog voltage setting, analog current setting, pulse setting and serial communication port Frequency source setting.

  • Page 11: Peripheral Electrical Devices And System Configuration

    1.4 Peripheral Electrical Devices and System Configuration Power Circuit braker Contactor Brake AC reactor resistor filter Brake unit Inverter DC reactor Grounding reactor filter Motor Grounding...

  • Page 12: Product Outline And Installation Dimensions

    1.5 Product outline and installation dimensions 1.5.1 Product outlines (unit: mm)

  • Page 13: Production Dimension Table

    1.5.2 Production dimension table Dimensions Holes Gross Model (Kg) (Kg) (mm) (mm) (mm) (mm) (mm) (mm) (mm) DLA1-0D40S2G DLA1-0D75S2G 136.5 79.5 112.5 122.5 DLA1-01D5S2G DLA1-0D75T4G DLA1-01D5T4P DLA1-01D5T4G 145.5 94.5 116.5 126.5 DLA1-02D2T4P DLA1-02D2T4G DLA1-03D7T4P DLA1-03D7T4G DLA1-05D5T4P DLA1-05D5T4G DLA1-07D5T4P -10-...

  • Page 14: Wirings

    2 Wirings 2.1 Standard wiring diagrams Brake resistor Circuit breaker DLA1 Input power Motor Main circuit Control circuit P4.00=1 FWD P4.01=4 FJOG P4.02=9 RESET P4.03=12 Speed 1 P4.05=2 REV NPN (default) RS485 Shielding P5.07=0 0-10V Max load current: 5mA 0-20mA Max load resistance: 250Ω +10V Default: 0-10V input +10V...

  • Page 15: Main Circuit Wirings

    2.2 Main circuit wirings  380V class: Terminals Functions R、S、T Input power P+、PB External brake resistor U、V、W Output power  220V class Terminals Functions L1、L2 Input power P+、PB External brake resistor U、V、W Output power -12-...

  • Page 16: Control Circuit Wirings

    2.3 Control circuit wirings 2.3.1 Control circuit signals AGND +10V Type Terminal Name Function Specifications Input terminal X1 Default: Forward run (FWD) Opti-coupler insulation Input terminal X2 Default: Forward JOG (FJOG) DC24V/8mA Input terminal X3 Default: Fault reset (RESET) External power Input terminal X4 Default: Multi-speed terminal 1 voltage range: 9～...

  • Page 17: Control Circuit Wiring Notes

    2.3.2 Control circuit wiring notes  Analog input wirings As analog signals can be easily affected by external interference, shielded cables shall be used. Cables shall be as short as possible and not exceeding 20 meters. As shown in graphs below, in some severe circumstances, filter capacitor or ferrite bread shall be used in analog signal side.

  • Page 18: Control Circuit Jumpers

    +24V +24V 9-30V +VCC PNP input: Use external 24V power; 3.3Ω external power negative node is 4.7K connected with SP terminal; external terminal positive node is common; 信号 external power voltage range is 9~30V; J9 is 12 jumped; also known as source wiring mode.

  • Page 19: Panel Operations

    3 Panel operations 3.1 Keyboard interface Keyboard outline is as below: Keys/Lights Function Descriptions Rotating direction ON: FWD DIR (light) status OFF: REV Operation status ON: RUN RUN (light) OFF: STOP terminal control Command source LOCAL (light) OFF: keyboard control status BLINK: remote (communicational) control ON: in torque control mode...

  • Page 20: Parameter Setting Example

    3.2 Parameter setting example DLA1 inverter panel has a three-level structure: function code group (level 1menu) → function code (level 2 menu) → function code setting (level 3 menu). Example: Change P2.02 from 10.00Hz to15.00Hz, as shown in graph below: Parameter monitoring: please refer to P7.03, P7.04, P7.05 for parameter monitoring settings.

  • Page 21: Jog Run

    3.4 JOG run DLA1 series default setting value Parameter Default value P0.01 Sensorless vector control (SVC) P0.02 Keyboard command channel (LED OFF) Keyboard setting frequency (P0.08, UP/DOWN P0.03 can edit, not retentive at power of) After correctly set motor parameter P1.00-P1.05 and auto-tuning, user can control motor operation using keyboard DIR/JOG.

  • Page 22: Function Codes (Parameters)

    4 Function codes (Parameters) Legends: “★”: this parameter’s setting value is not editable when inverter is at operation status; “●”: this parameter’s value is observed value, not editable; “☆”: this parameter’s setting value is editable when inverter is at stop or operation status; “▲”: this parameter is “factory parameter”...
  • Page 23 2 12 2 11 VDI5 VDI4 VDI3 VDI2 VDI1 DI10 d0.08 DO output status This displays the current state of DO terminals and the value is hexadecimal. Each bit corresponds to a DO. "1" indicates high level signal, and "0" indicates low level signal. The corresponding relationship between bits and DOs is described in the following table.
  • Page 24 PG feedback speed, accurate to 0.1Hz. P7.12 determines location of decimal point for value of d0.19 & d0.29.  If P7.12=2, value range is -320.00Hz~320.00Hz;  If P7.12-1, value range is -500.0Hz~500.0Hz. d0.20 Remaining running time 0.1Min Used for timer control. Refer to P8.42~P8.44. d0.21 AI1 voltage/current before correction.

  • Page 25: Basic Functions Group: P0.00-P0.28

    This uses 5 nixie tubes to display whether terminal functions 1~40 are valid. Each nixie tube can display 8 functions. From right to left: 1~8, 9~16, 17~24, 25~32, 33~40. d0.44 DI function display 2 Same as d0.43, this uses 3 nixie tubes to display whether terminal functions 41~59 are valid. From right to left: 41~48, 49~56, 57~59.
  • Page 26 Keyboard (LED OFF) Command source ☆ P0.02 Terminals (LED ON) channel selection Communication (LED blinks) This is to determine the input channel of the control commands, such as run, stop, forward rotation, reverse rotation and jog operation. 0: Keyboard ("LOCAL" indicator off) Commands are given by pressing keys on the keyboard (keyboard).
  • Page 27 6: Multi-speed operation setting In multi-speed operation setting mode, combinations of different DI terminal states correspond to different set frequencies. The DLA1 supports maximum 16 speeds implemented by 16 state combinations of four DI terminals in Group PC. The multi-speed operation setting indicates percentages of the value of P0.10 (Maximum output frequency).
  • Page 28 Y and “X and Y combination” switchover Ten’s X and Y combinations place MAX [X, Y] MIN [X, Y] The final output frequency can be simple X setting, or it can be a sophisticated result after Y is included and/or combined. Preset frequency 0.00Hz~ P0.10 ( valid when frequency ☆...
  • Page 29 It is used to set the source of the frequency upper limit, including digital setting (P0.12), AI, or communication setting. If the frequency upper limit is set by means of AI1, AI2, AI3, or communication, the setting is similar to that of the main frequency source X. For details, see the description of P0.03.
  • Page 30 Deceleration time is the time required by the Inverter to decelerate from "Acceleration/Deceleration base frequency” (P0.25) to 0 Hz, that is, t2 in figure below. The DLA1 provides totally four groups of acceleration/deceleration times. You can perform switchover by using a DI terminal. •...
  • Page 31 This parameter is valid only when the frequency source is digital setting. It is used to set the base frequency to be modified by using keys and or the terminal UP/DOWN function. Binding frequency source to One’s place keyboard No binding Digital setting Reserved Multi-speed...

  • Page 32: First Motor Parameters: P1.00-P1.37

    4.3 First motor parameters: P1.00-P1.37 Code Description Setting range Normal asynchronous motor ★ Motor type selection P1.00 Variable frequency asynchronous motor ★ Motor rated power P1.01 0.1kW~1000.0kW ★ Motor rated voltage P1.02 1V~2000V 0.01A~655.35A (inverter rated power≦55kW) ★ Motor rated current P1.03 0.1A~6553.5A (inverter rated power >55kW) Motor rated...
  • Page 33 2: Asynchronous motor complete auto-tuning To perform this type of auto-tuning, ensure that the motor is disconnected from the load. During the process of complete auto-tuning, the inverter performs static auto-tuning first and then accelerates to 80% of the motor rated frequency within the acceleration time set in P0.17. The inverter keeps running for a certain period and then decelerates to stop within deceleration time set in P0.18.

  • Page 34: Vector Control Parameters: P3.00-P3.22

    4.4 V/F control parameters: P2.00-P2.27 Group P2 is valid only for V/F control. The V/F control mode is applicable to low load applications (fan or pump) or applications where one inverter drives multiple motors or there is a large difference between the inverter power and the motor power.
  • Page 35 To compensate the low frequency torque characteristics of V/F control, user can boost the output voltage of the inverter at low frequency by modifying P2.01. If the torque boost is set to too large, the motor may overheat, and the inverter may suffer overcurrent.
  • Page 36 V1~V3: 1st, 2nd and 3rd voltage percentages of multi-point V/F F1~F3: 1st, 2nd and 3rd frequency percentages of multi-point V/F Vb: motor rated voltage Fb: motor rated running frequency ☆ P2.09 V/F slip compensation gain 0%~200.0% This parameter is valid only for the asynchronous motor. It can compensate the rotational speed slip of the asynchronous motor when the load of the motor increases, stabilizing the motor speed in case of load change.
  • Page 37 Digital setting ( P2.14) ☆ Reserved Voltage source for V/F P2.13 separation Multi-speed Simple PLC Communication 100.0% corresponding to motor rated voltage (P1.02) V/F separation voltage digital ☆ P2.14 0V~ motor rated voltage setting V/F separation is generally applicable to scenarios such as induction heating, inverse power supply. If V/F separation is enabled, the output voltage can be set in P2.14 or by means of analog, multi- speed, simple PLC, PID or communication.
  • Page 38 4.5 Vector control parameters: P3.00-P3.22 P3 group is valid for vector control, and invalid for V/F control. Code Description Setting range ☆ P3.00 Speed loop proportional gain G1 1~100 ☆ P3.01 0.50s Speed loop integral time T1 0.01s~10.00s ☆ P3.02 5.00Hz Switchover frequency 1 0.00~P2.05...
  • Page 39 ☆ P3.06 150% Vector control slip gain 50%~200% This is used to adjust speed stability accuracy of the motor. When the motor with load runs at a very low speed, increase the value of this parameter; when the motor with load runs at a very large speed, decrease the value of this parameter.

  • Page 40: Input Terminals: P4.00-P4.39

    4.6 Input terminals: P4.00-P4.39 DLA1 provides six DI terminals (DI5 can be used for high-speed pulse input) and three analog input (AI) terminals. Code Description Setting range ★ P4.00 DI1 function selection 0~59 ★ P4.01 DI2 function selection 0~59 ★ P4.02 DI3 function selection 0~59...
  • Page 41 Multi-speed terminal K4 Terminal 1 for acceleration/ deceleration time Totally four groups of acceleration/deceleration time can selection be selected through combinations states of these two Terminal 2 for terminals. acceleration/ deceleration time selection Frequency source This terminal is used to perform switchover between two switchover frequency sources according to the setting in P0.07.
  • Page 42 PID action direction The PID action direction is opposite to the direction set negation in PA.03. External STOP terminal This terminal can be used to stop the Inverter, equivalent to the STOP key on the keyboard. It is used to perform switchover between terminal Command source control and communication control.
  • Page 43  Multi-speed control Speed setting Parameter Speed 0 PC.00 PC.01 Speed 1 PC.02 Speed 2 PC.03 Speed 3 PC.04 Speed 4 PC.05 Speed 5 PC.06 Speed 6 PC.07 Speed 7 PC.08 Speed 8 PC.09 Speed 9 PC.10 Speed 10 PC.11 Speed 11 PC.12 Speed 12...
  • Page 44 DIx (FOR) DIy (REV) It is the most commonly used two-line mode, in which the forward/reverse rotation of the motor is decided by DI1x and DIy. The parameters are set as below: Value Function Description Forward operation (FWD) Reverse operation (REV) 0: invalid;...
  • Page 45 DIx (FWD) DIn RUN enabled DIy (REV) SB1: Stop button SB2: FWD button SB3: REV button In this mode, DIn is enable terminal, and DIx & DIy terminal decides operation directions. Value Function Description Forward operation (FWD) Reverse operation (REV) RUN enabled 0: invalid;...
  • Page 46 Operation Stop ☆ P4.12 1.00Hz/s Terminal UP/DOWN rate 0.01Hz/s~655.35Hz/s It is used to adjust the rate of change of frequency when the frequency is adjusted by means of terminal UP/DOWN. • If P0.22 (Frequency reference resolution) is 2, the setting range is 0.001-65.535 Hz/s. •...
  • Page 47 ☆ AI curve 2 minimum input percentage P4.19 0.0% -100.00%~100.0% ☆ AI curve 2 maximum input P4.20 10.00V P4.18~10.00V ☆ AI curve 2 maximum input percentage P4.21 100.0% -100.00%~100.0% ☆ AI2 filter time P4.22 0.10s 0.00s~10.00s ☆ AI curve 3 minimum input P4.23 0.10V -10.00V~P4.25...
  • Page 48 If the value of a certain digit is 0, when analog input voltage is less than the minimum input, the corresponding setting of the minimum input (P4.14, P4.19, P4.24) is used. If the value of a certain digit is 1, when analog input voltage is less than the minimum input, the corresponding value of this analog input is 0.0%.

  • Page 49: Output Terminals: P5.00-P5.22

    4.7 Output terminals: P5.00-P5.22 DLA1 provides one analog output (AO) terminals, one digital output (DO) terminal, and one relay terminal. Code Description Setting range ☆ P5.02 Relay 1 function (TA1-TB1-TC1) 0-41 ☆ P5.04 DO1 function selection (open-collector output) 0-41 The functions of the output terminals are described in the following table. Value Function Description...
  • Page 50 If the set frequency exceeds the frequency upper limit or lower limit and the output frequency of the Frequency limited inverter reaches the upper limit or lower limit, the terminal becomes ON. In speed control mode, if the output torque reaches Torque limited the torque limit, the inverter enters stall protection state and meanwhile the terminal becomes ON.
  • Page 51 If AI1 input is larger than the value of P8.46 (AI1 protection upper limit) or lower than the value of AI1 input limit exceeded P8.45 (AI1 protection lower limit), the terminal becomes ON. Load becoming 0 If the load becomes 0, the terminal becomes ON. If the inverter is in the reverse running state, the Reverse running terminal becomes ON.
  • Page 52 Count value 0 to maximum count value Communication setting 0.0%-100.0% 0 to rotational speed corresponding to Motor rotational speed maximum output frequency Output current 0.0-1000.0A Output voltage 0.0-1000.0V -2 times of motor rated torque ~ +2 Output torque (actual value) times of motor rated torque -100.0%~+100.0% ☆...

  • Page 53: Start/Stop Control: P6.00-P6.15

    4.8 Start/stop control: P6.00-P6.15 Code Description Setting range Direct start ☆ P6.00 Start mode Speed tracking Pre-excited start 0: Direct start -If the startup DC braking time is set to 0, the inverter starts to run from the startup frequency. -If the startup DC braking time is not 0, the inverter performs DC braking first and then starts to run from the startup frequency.
  • Page 54 During switchover between forward rotation and reverse rotation, the startup frequency holding time is disabled. The holding time is not included in the acceleration time but in the running time of simple PLC. Example 1: P0.03 = 0 The frequency source is digital setting. P0.08 = 2.00Hz The digital setting frequency is 2.00 Hz.
  • Page 55 output 1: S-curve acceleration/deceleration A frequency Hz The output frequency increases or frequency decreases along the S curve. This mode is applicable where start and stop processes needs to be smooth, such as elevator and conveyor belt. P6.08 and P6.09 time t respectively define the time proportions of the start segment and the end segment.
  • Page 56 When the running frequency decreases to the initial frequency of stop DC braking, the inverter stops output for a certain period and then starts DC braking. This prevents faults such as overcurrent caused due to DC braking at high speed. ...

  • Page 57: Keyboard And Display: P7.00-P7.14

    4.9 Keyboard and display: P7.00-P7.14 Code Description Setting range DIR/JOG disabled Switchover between keyboard control and terminal/communication control Switchover between forward rotation ★ P7.01 DIR/JOG key and reverse rotation Forward JOG Reverse JOG DIR/JOG key is a multifunctional key. 0: DIR/JOG key disabled This key is disabled.
  • Page 58 ☆ 0000~FFFF P7.04 Running state display 2 PID feedback Linear speed PLC phase Power-on time (Hour) Running time (Min) Input pulse frequency (kHz) Running frequency 2 (Hz) Input pulse frequency (Hz) Remaining running time Communication AI1 voltage Encoder speed before correction AI2 voltage before correction AI3 voltage...
  • Page 59 One’s Place 0 decimal place 1 decimal place 2 decimal place Number of decimal places ☆ P7.12 for load speed display 3 decimal place Ten’s Place 1 decimal place 2 decimal place One’s Place: P7.12 is used to set the number of decimal places for load speed display. The following gives an example to explain how to calculate the load speed: If P7.06 (Load speed display coefficient) is 2.000 and P7.12 one’s place is 2.

  • Page 60: Auxiliary Functions: P8.00-P8.54

    4.10 Auxiliary functions: P8.00-P8.54 Code Description Setting range ☆ P8.00 JOG running frequency 0.00Hz~ maximum frequency 2.00Hz ☆ P8.01 JOG acceleration time 0.0s~6500.0s 20.0s ☆ P8.02 JOG deceleration time 0.0s~6500.0s 20.0s These parameters are used to define the set frequency and acceleration/deceleration time of the inverter when Jogging.
  • Page 61 Output Frequency Hz time t dead-zone time Enabled ☆ P8.13 Reverse control Disabled It is used to set whether the inverter allows reverse rotation. In the applications where reverse rotation is prohibited, set this parameter to 1. Run at lower limit Running mode when set frequency ☆...
  • Page 62 This parameter is used to set whether to enable the safety protection. If it is set to 1, the inverter does not respond to the still valid run command upon inverter power-on (for example, an input terminal is ON before power-on). The inverter responds only after the run command is cancelled and becomes valid again.
  • Page 63 Disabled Jump frequency validity in ☆ P8.22 acceleration/deceleration Enabled When P8.22=1, and the running frequency is within the frequency jump range, the actual running frequency will jump over the set frequency jump amplitude. The figure shows when the jump frequencies are valid in acceleration/deceleration.
  • Page 64 During acceleration, if the running frequency is smaller than the value of P8.25, acceleration time 2 is selected. If the running frequency is larger than the value of P8.25, acceleration time 1 is selected. During deceleration, if the running frequency is larger than the value of P8.26, deceleration time 1 is selected.
  • Page 65 If the output frequency of the inverter is within the positive and negative amplitudes of frequency reached detection value, the corresponding DO (P5.01=26/27) becomes ON. DLA1 provides two groups of frequency reached detection parameters, including frequency detection value and detection amplitude, as shown in the graph above. ☆...
  • Page 66 Output current P8.36 Output over-current signal P8.37 If the output current of the inverter is equal to or higher than the overcurrent threshold and the duration exceeds the detection delay time, the corresponding DO (P5.01=36) becomes ON. The output overcurrent detection function is shown in the graph above. ☆...

  • Page 67: Fault And Protection: P9.00-P9.73

    ☆ P8.44 Timing duration 0.0Min~6500.0Min 0.0Min If P8.42 is set to 1, the inverter starts timing at startup. When the set timing duration is reached, the inverter stops automatically and meanwhile the corresponding DO (P5.01=30) becomes ON. The inverter starts timing from 0 each time it starts up and the remaining timing duration can be queried by d0.20.
  • Page 68 The motor overload protective function is disabled. The motor is exposed to potential overheating. A thermal relay is suggested to be installed between the Inverter and the motor. P9.00 = 1 The inverter judges whether the motor is overloaded according to the inverse time-lag curve of the motor overload protection.
  • Page 69 Ten’s place Contactor energizing protection Disabled Enabled It is used to determine whether to perform input phase loss or contactor energizing protection. (Only available for DLA1 series inverter over 18.5KW models) Disabled Output phase loss protection ☆ P9.13 selection Enabled It is used to determine whether to perform output phase loss protection.
  • Page 70 It is used to record the types of the most recent three faults of the inverter. 0 indicates no fault. For possible causes and solution of each fault, refer to Chapter 6. Fault types: Number Fault display Fault type No fault 1=E.IGbt IGBT protection 2=E.oCAC...
  • Page 71 It displays the status of all DI terminals when the latest fault occurs. The sequence is as follows: BIT9 BIT8 BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0 If a DI is ON, the setting is 1. If the DI is OFF, the setting is 0. The value is the equivalent decimal number converted from the DI status.
  • Page 72 P9.40 1st fault DI status ● Refer to P9.20 P9.41 1st fault output status ● Refer to P9.21 P9.42 1st fault inverter status Reserved ● P9.43 1st fault power-on time ● It displays the present power-on time when the 1 fault occurs.
  • Page 73 -70-...
  • Page 74 If "Coast to stop" is selected, the inverter displays E.**** and directly stops. If "Stop by stop mode" is selected, the inverter displays A.**** and stops according to the stop mode. After stop, the inverter displays E.****. If "Resume running" is selected, the inverter continues to run and displays A.****. The running frequency is set in P9.54.
  • Page 75 Invalid Instantaneous power failure ☆ P9.59 DC bus voltage constant control action selection Decelerate to stop Instantaneous power failure ☆ P9.60 85.0%~120.0% 85.0% resuming voltage Instantaneous power failure voltage ☆ P9.61 0.00s~100.00s 0.50s judging time 60.0%~85.0% (Standard DC bus Instantaneous power failure ☆...
  • Page 76 Disabled Protection upon load becoming ☆ P9.63 Enabled Detection level of load 0.0%~100.0% (motor rated ☆ P9.64 10.0% becoming 0 current) Detection time of load becoming ☆ P9.65 0.0s~60.0s 1.0s If protection upon load becoming 0 is enabled, when the output current of the inverter is lower than the detection level (P9.64) and the lasting time exceeds the detection time (P9.65), the output frequency of the inverter automatically declines to 7% of the rated frequency.

  • Page 77: Pid Functions: Pa.00-Pa.28

    4.12 PID functions: PA.00-PA.28 PID control is a general process control method. By performing proportional, integral and differential operations on the difference between the feedback signal and the target signal, it adjusts the output frequency and constitutes a feedback system to stabilize the controlled counter around the target value. It is applied to process control such as flow control, pressure control and temperature control.
  • Page 78 When the feedback value is smaller than the PID setting, the inverter's output frequency rises. For example, the winding tension control requires forward PID action. 1: Reverse action When the feedback value is smaller than the PID setting, the inverter's output frequency reduces. For example, the unwinding tension control requires reverse PID action.
  • Page 79 PA.12 is used to filter the PID feedback, helping to reduce interference on the feedback but slowing the response of the process closed-loop system. PA.13 is used to filter the PID output frequency, helping to weaken sudden change of the Inverter output frequency but slowing the response of the process closed-loop system.
  • Page 80 PID initial value holding 0.00s ☆ PA.22 0.00s~650.00s time Output Frequency PA.21 PA.22 When the Inverter starts up, the PID starts closed-loop algorithm only after the PID output is fixed to the PID initial value (PA.21) and lasts the time set in PA.22. This function is used to limit the deviation between two PID outputs (2 ms per PID output) to suppress the rapid change of PID output and stabilize the running of the Inverter.

  • Page 81: Swing Frequency, Fixed Length And Count: Pb.00-Pb.09

    4.13 Swing Frequency, Fixed Length and Count: PB.00-PB.09 The swing frequency function is applied to the textile and chemical fiber fields and the applications where traversing and winding functions are required. The swing frequency function indicates that the output frequency of the inverter swings up and down with the set frequency as the center.
  • Page 82 • If relative to the maximum frequency (PB.00 = 1), the swing jump frequency is a fixed value. The swing frequency is limited by the frequency upper limit and frequency lower limit. ☆ PB.03 Swing frequency cycle 0.0s~3000.0s 10.0s Triangular wave rising time ☆...

  • Page 83: Multi-Speed And Simple Plc: Pc.00-Pc.51

    4.14 Multi-speed and simple PLC: PC.00-PC.51 DLA1 multi-speed has many functions. Besides multi-speed, it can be used as the setting source of the V/F separated voltage source and setting source of process PID. Code Description Setting range ☆ PC.00 Multi-speed 0 -100.0%~100.0% 0.0% ☆...
  • Page 84 PC.19 running PC.21 direction PC.14 PC.02 PC.15 PC.00 time t PC.01 PC.20 PC.18 PC.23 DO or RELAY Output 250ms pulse 0: Stop after one cycle The inverter stops after running one cycle, and will not start up until receiving another command. 1: Keep final values after one cycle The Inverter keeps the final running frequency and direction after running one cycle.
  • Page 85 Simple PLC section 0 running ☆ PC.19 acceleration/deceleration time ☆ PC.20 Simple PLC section 1 running time 0.0s (h) ~6553.5s (h) 0.0s (h) Simple PLC section 1 running ☆ PC.21 acceleration/deceleration time ☆ PC.22 Simple PLC section 2 running time 0.0s (h) ~6553.5s (h) 0.0s (h) Simple PLC section 2 running...
  • Page 86 ☆ PC.46 Simple PLC section 14 running time 0.0s (h) ~6553.5s (h) 0.0s (h) Simple PLC section 14 running ☆ PC.47 acceleration/deceleration time ☆ PC.48 Simple PLC section 15 running time 0.0s (h) ~6553.5s (h) 0.0s (h) Simple PLC section 15 running ☆...

  • Page 87: Communication Parameters: Pd.00-Pd.06

    4.15 Communication parameters: PD.00-PD.06 Please refer to DLA1 communication protocol in Chapter 7. Code Description Setting range One’s place MODBUS 300BPS 600BPS 1200BPS 2400BPS ☆ PD.00 Bit rate 4800BPS 6005 9600BPS 19200BPS 38400BPS 57600BPS 115200BPS 8-N-2 8-E-1 ☆ PD.01 Data type 8-O-1 8-N-1 ☆...

  • Page 88: Function Code Management

    4.16 Function code management: PP.00-PP.04 Code Description Setting range Def Res ☆ PP.00 User password 0~65535 If it is set to any non-zero number, the password protection function is enabled. After a password has been set and taken effect, you must enter the correct password in order to enter the menu. If the entered password is incorrect you cannot view or modify parameters.

  • Page 89: Torque Control Parameters: B0.00-B0.08

    4.17 Torque control parameters: B0.00-B0.08 Code Description Setting range Speed control ★ B0.00 Speed/Torque control selection Torque control DLA1 provides DI terminals with two torque related functions, function 29 (Torque control prohibited) and function 46 (Speed control/Torque control switchover). The two DI terminals need to be used together with B0.00 to implement speed control/torque control switchover.

  • Page 90: Control Optimization Parameters: B5.00-B5.09

    4.18 Control optimization parameters: B5.00-B5.09 Code Description Setting range DPWM switchover 12.00Hz ☆ B5.00 0.00Hz~15.00Hz frequency upper limit This parameter is valid only for V/F control. It is used to determine the wave modulation mode in V/F control of asynchronous motor. If the frequency is lower than the value of this parameter, the waveform is 7-segment continuous modulation.
  • Page 91 Current detection ☆ B5.05 0~100 compensation It is used to set the Inverter current detection compensation. Too large value may lead to deterioration of control performance. Do not modify it generally. ☆ B5.06 Under voltage threshold 210V ~ 420V 350V It is used to set the under voltage threshold of 9=E.LU.

  • Page 92: Fault And Solutions

    5 Fault and solutions 5.1 Alarms and solutions DLA1 provides a total of 51 fault information and protective functions. After a fault occurs, the inverter implements the protection function, and displays the fault code on the keyboard (if the keyboard is available).
  • Page 93 Fault Name Display Possible Causes Solutions 1: Eliminate external faults. 1: The output circuit is grounded 2: Perform the motor auto- or short circuited. tuning. 2: Motor auto-tuning is not Constant speed 3: Adjust the voltage to performed. 4=E.oCCo over current normal range.
  • Page 94 Fault Name Display Possible Causes Solutions 1: F9-01 is set improperly. 1: Set F9-01 correctly. 2: Reduce the load and check 2: The load is too heavy or the motor and the mechanical Motor overload 11=E.oLt locked- rotor occurs on the motor. condition.
  • Page 95 Fault Name Display Possible Causes Solutions 1: Replace the faulty HALL Current 1: The HALL device is faulty. 2: device. 18=E.HALL detection fault The drive board is faulty. 2: Replace the faulty drive board. 1: The motor parameters are not 1: Set the motor parameters Motor auto- set according to the nameplate.
  • Page 96 Fault Name Display Possible Causes Solutions 1: Reduce the load and check 1: The load is too heavy or the motor and mechanical Pulse-by-pulse locked- rotor occurs on the motor. condition. current limit 40=E.CbC 2: The Inverter model is of too 2: Select an Inverter of higher fault small power class.

  • Page 97: Other Fault And Solutions

    5.2 Other fault and solutions You may come across the following faults during the use of the inverter. Refer to the following table for simple fault analysis. Fault Possible Causes Solutions 1: There is no power supply to the Inverter or the power input to the Inverter is too low.
  • Page 98 Fault Possible Causes Solutions 1: Check the motor and the motor cables. 1: Ensure the cable between the 2: The Inverter parameters are set Inverter and the motor is normal. The motor does not improperly (motor parameters). 2: Replace the motor or clear rotate after the 3: The cable between the drive board mechanical faults.

  • Page 99: Repair And Maintenance

    6 Repair and maintenance 6.1 Routine maintenance The influence of the ambient temperature, humidity, dust and vibration will cause the aging of the devices in the Inverter, which may cause potential faults or reduce the service life of the Inverter. Therefore, it is necessary to carry out routine and periodic maintenance.

  • Page 100: Modbus Communication Protocol

    (known as the response). For broadcast information, slave no need to send response to the host. DLA1 series inverter Modbus data communication protocol format is as follows: using RTU mode, sending a message must start with an at least 3.5 characters’ interval time.
  • Page 101 previous message, receiver will regard the new message as continuation of previous message. This will lead to an error, because at last the CRC domain value will be wrong. RTU frame format: Frame START At least 3.5-character time Slave address ADR Communication address: 0~247 Command code CMD 03: Read slave parameter;...
  • Page 102 Command code: 06H write one word For example: write 5000 (1388H) to F00AH of slave address 02H Master command information Information address high place Information address low place Information content high place Information content low place CRC CHK low place CRC CHK value CRC CHK high place Slave response information...

  • Page 103: Verification Mode

    7.2 Verification mode CRC mode: CRC (Cyclical Redundancy Check) uses RTU frame format message, including error detection method based on CRC fields. CRC field detects the entire contents of the message. CRC field includes two bytes, and contains a 16-bit binary value. It adds to the message after calculations from the transmission equipment.

  • Page 104: Communication Addresses

    7.3 Communication addresses Function code address rules (EEPROM): High place bytes: F0~FF (P0~PF), A0~AF (B0~BF) , 70~7F (D0~DF) . Low place byte: 00~FF. For example: P2.12, the address is expressed as F30C. Note: PF group: not readable or editable; Group d: read-only and cannot be changed. In addition, frequent EEPROM storage will reduce the life of the EEPROM.
  • Page 105 Note: Communication setting value is relevant percentage value, 10000 corresponding to 100.00%, -10000 corresponding-100.00%. For frequency data, this percentage is relevant to maximum frequency (P0.10); torque data is percentage to P2.10 (torque upper limit). Command input: (write only) Command address Command function 0001: FWD operation 0002: REV operation...
  • Page 106 Analog output AO2 control: (write only) Command address Command content 2003 0~7FFF means 0％~100％ Pulse output control: (write only) Command address Command content 2004 0~7FFF means 0％~100％ Inverter fault description: Inverter fault address Inverter fault information 0000: No fault 0001: reserved 0002: Over-current during acceleration 0003: Over-current during deceleration 0004: Over-current at constant speed...
  • Page 107 005B: Encoder not connected 005C: Initial position fault 005E: Speed feedback fault Communication fault information: Communication fault Fault description address 0000: No fault 0001: Wrong password 0002: Command code fault 0003: CRC detection fault 8001 0004: Invalid address 0005: Invalid parameter 0006: Parameter editing invalid 0007: System locked 0008: Writing EEPROM in operation...

  • Page 108: Appendix I: Brake Accessories

    Appendix I: Brake accessories Recommended value of brake units and brake resistors 220V class: Recommended brake resistor Brake unit (100% brake torque) Inverter capacity Equivalent Specs Quantity Quantity resistance/power 0.4G 200Ω/80W 0.75G 150Ω/80W Built-in 1.5G 100Ω/100W 2.2G 70Ω/200W 380V class: Recommended brake resistor Brake unit (100% brake torque)
