MSI X340 Disassemble Manual

MSI X340 Disassemble Manual

Hide thumbs Also See for X340:

Advertisement

Quick Links

Download this manual See also: User Manual
X340 (MS-1352) Disassemble Guide
■ 1、BATTERY PACK
■ 2、LOWER CASE ASSY
■ 3、KEYBOARD
■ 4、SEPARATE UPPER CASE AND LOWER CASE
■ 5、HDD MODULE
■ 6、WLAN MODULE
■ 7、LOWER CASE ASSY-1
■ 8、RAM MODULE
■ 9、LOWER CASE ASSY-2
■ 10、UPPER CASE ASSY
■ 11、LCD MODULE ASSY

Advertisement

loading

Related Manuals for MSI X340

Summary of Contents for MSI X340

  • Page 1 X340 (MS-1352) Disassemble Guide ■ 1、BATTERY PACK ■ 2、LOWER CASE ASSY ■ 3、KEYBOARD ■ 4、SEPARATE UPPER CASE AND LOWER CASE ■ 5、HDD MODULE ■ 6、WLAN MODULE ■ 7、LOWER CASE ASSY-1 ■ 8、RAM MODULE ■ 9、LOWER CASE ASSY-2 ■ 10、UPPER CASE ASSY...
  • Page 2 X340（MS-1352）Disassemble Guide 1、BATTERY PACK 1.1：Move the “Unlock’ button base on left picture shows; 1.2：Release the “Release” button and move the battery pack base on left picture. Component Battery Pack S9N-2141200-SB3...
  • Page 3 X340（MS-1352）Disassemble Guide 2、LOWER CASE ASSY 2.1：Push the Dummy card firstly, then remove it after it pop up; Component Dummy Card E2P-3512611-Y31 2.2：Remove the 10 screws (M2*2.5mm); Attention: the screw driver touque is: 1.5-2.0Kgf-cm Component Screw E43-1202506-H29...
  • Page 4 X340（MS-1352）Disassemble Guide 3、KEYBOARD 3.1：Before removing K/B, firstly release the 2 hooks of the middle of the keyboard upside. 3.2：Insert the stick below the keyboard 3.3：Release the 2 hooks of the two sides of the keyboard upside, then raise upside of the keyboard...
  • Page 5 X340（MS-1352）Disassemble Guide 3、KEYBOARD 3.4：Insert the plate, then move the plate from left to right to remove double-sided adhesive pad. 3.5：Remove the keyboard. 3.6：Firstly push the handspike on two sides of the K/B cable connector according to the direction as pic shows; then remove the cable;...
  • Page 6 X340（MS-1352）Disassemble Guide 4、SEPARATE UPPER CASE AND LOWER CASE 4.1：Remove the 6 screws(M2*3.5mm); Attention: the screw driver torque is: 1.5-2.0Kgf-cm Component Screw E43-1203501-H29 4.2：When remove the Upper case, firstly remove the right side. Lift the inside of the upper with the thumb;...
  • Page 7 X340（MS-1352）Disassemble Guide 4、SEPARATE UPPER CASE AND LOWER CASE 4.4：When remove the Upper case, detach the Upper case down side from Lower case; Attention: Don’t use the heavy strength to pull the Upper case; and the Touchpad cable is connected with the main board;...
  • Page 8 X340（MS-1352）Disassemble Guide 5、HDD MODULE 5.1：Remove the 2 screws(M2*3.5mm); Attention: the screw driver torque: 1.5-2.0Kgf-cm Component Screw E43-1203501-H29 5.2：Remove the HDD Module according to the direction as pic shows;...
  • Page 9 X340（MS-1352）Disassemble Guide 5、HDD MODULE 5.3：Remove the 3 screws(M3*3.5mm) that stabilize the bracket; Attention: the screw driver torque is 3.0-3.5Kgf-cm Component Screw E43-1303502-H29 5.4：Remove the 3 HDD bracket; Component HDD Bracket 307-3510611-A89 HDD Module S71-2432504-F06...
  • Page 10 X340（MS-1352）Disassemble Guide 6、WLAN MODULE 6.1：Remove 2 screws(M2*3.5mm) Attention: the screw driver torque is 1.5-2.0Kgf-cm Component Screw E43-1203501-H29 6.2：Remove the Wlan board as left pic shows: Component Wlan Board 607-1352P-01S 6.3：Remove the two side wireless card antenna as pic shows:...
  • Page 11 X340（MS-1352）Disassemble Guide 6、WLAN MODULE 6.4：Remove one screw(M2*3.5mm); Attention: the screw driver torque is: 1.5-2.0Kgf-cm Component Screw E43-1203501-H29 6.5：Remove the WLAN module according to the direction of pic shows; Component WLAN Module S57-0800183-I06...
  • Page 12 X340（MS-1352）Disassemble Guide 7、LOWER CASE ASSY-1 7.1：Remove the LVDS cable as pic shows: 7.2：Then remove the LINK cable 7.3：Remove the Speaker cable and MIC cable separately as pic shows； MIC Cable Speaker Cable...
  • Page 13 X340（MS-1352）Disassemble Guide 7、LOWER CASE ASSY-1 7.4：Remove the 3 screws(M2*3.5mm) Attention: the screw driver torque is 1.5-2.0Kgf-cm Component Screw E43-1203501-H29 7.5：Remove the I/O board of right side as pic shows: Component Right Side I/O Board 607-1352N-02S 7.6：Remove the LINK cable that connect with the Right side I/O board, then remove the Audio cover and DCIN cover on this board;...
  • Page 14 X340（MS-1352）Disassemble Guide 7、LOWER CASE ASSY-1 7.7：Remove the 4 screw (M2*3.5mm)that stabilize the right hinge Attention: the screw driver torque is 2.0-2.2Kgf-cm Component Screw E43-1203501-H29 7.8：Remove the 3 screw (M2*3.5mm)that stabilize the left hinge Attention: the screw driver torque is 2.0-2.2Kgf-cm...

  • Page 15: Component P/N Qty

    X340（MS-1352）Disassemble Guide 8、RAM MODULE 8.1：Push the two side shielding of RAM as pic shows; 8.2：Then remove the RAM module according the direction as pic shows; Component RAM Module S7C-S357102-T10...
  • Page 16 X340（MS-1352）Disassemble Guide 9、LOWER CASE ASSY-2 9.1：Remove the 3 screw (M2*3.5mm) Attention: the screw driver torque is 1.5-2.0Kgf-cm Component Screw E43-1203501-H29 9.2：Remove the left side I/O port as left pic shows: Component Left Side I/O Board 607-1352O-01S...

  • Page 17: Audio Cover E2P-3511411-D37

    X340（MS-1352）Disassemble Guide 9、LOWER CASE ASSY-2 9.3：Remove the DSUB cover and MODE cover on left side I/O board; Component DSUB Cover E2P-3510811-D37 MODE Cover E2P-3510711-D37 9.4：Remove the Bluetooth cable as left pic shows: Component Bluetooth Cable K10-3008091-H39 9.5：Remove the 1 screw (M2*3.5mm) Attention: the screw driver torque is 1.5-2.0Kgf-cm...
  • Page 18 X340（MS-1352）Disassemble Guide 9、LOWER CASE ASSY-2 9.6：Remove the B/T module; Component Bluetooth Module 605-6837D-150...
  • Page 19 X340（MS-1352）Disassemble Guide 9、LOWER CASE ASSY-2 9.7：Firstly remove the Mylar pasted on heatsink, then remove the 3 screws(M2*3.5mm), after that remove the heatsink Attention：the screw driver torque is 1.5-2.0Kgf-cm Component Screw E43-1203501-H29 Heatsink E31-0801210-TA9 9.8：Remove 2 screws (M2*3.5mm) Attention: the screw driver torque is 1.5-2.0Kgf-cm...
  • Page 20 X340（MS-1352）Disassemble Guide 9、LOWER CASE ASSY-2 9.10：Remove the main board from Lower case and Pull out the fan cable as pic shows; 9.11：Remove the fan from main board Attention: the fan cable should be pulled out from the breach of main board.
  • Page 21 X340（MS-1352）Disassemble Guide 9、LOWER CASE ASSY-2 9.12：Remove the L HDMI cover from Lower case; Component L_HDMI_COVER E2P-3511211-D37 9.13：Remove the SD card cover from Lower case; Component SD Card Cover E2P-3511311-D37 9.14：Remove the R USB cover from Lower case; Component R USB Cover...
  • Page 22 X340（MS-1352）Disassemble Guide 9、LOWER CASE ASSY-2 9.15：Remove the 3 screws (M2*3.5mm), then remove the Speaker module from lower case; Attention: the screw driver torque is 1.5-1.8Kgf-cm Component Screw E43-1203501-H29 Speaker Module S33-A020210-F33 Lower Case 307-351D212-W28...
  • Page 23 X340（MS-1352）Disassemble Guide 10、UPPER CASE ASSY 10.1：Release the connector that stabilize the T/P cable(To Button Board), then remove the T/P module according the to direction of left pic shows; Component FFC Cable K1C-1012038-J36 (To MB) FFC Cable K1C-1020009-J36 (To Button) 10.2：Remove the 2 screws (M2*3.5mm); then remove the T/P board from upper case;...
  • Page 24 X340（MS-1352）Disassemble Guide 11、 LCD MODULE ASSY 11.1：Remove the 4 cover rubber and 1 bezel rubber; Component Cover Rubber E2Y-3510111-Y40 Bezel Rubber E2Y-3510211-Y40 11.2：Insert the stick into the Hinge-cap, then get off the Hinge-cap with the stick. Component Hinge Cap E2P-3510321-Y31 11.3：When removing the LCD bezel, should begin...
  • Page 25 X340（MS-1352）Disassemble Guide 11、 LCD MODULE ASSY 11.4： Pay attention to the 5 hooks on downside, need to push the bezel and then separate it from panel; 11.5：Lift the downside of the bezel, then press the black MYLAR with the stick so as to remove the double-sided adhesive.
  • Page 26 X340（MS-1352）Disassemble Guide 11、 LCD MODULE ASSY 11.7：Remove the 3 magnet on LCD bezel; Component LCD Cover Magnet E2Y-3510711-SF7 LCD Cover Magnet E2Y-3511011-SF7 11.8：Remove the 8 screws(M2*3mm) that stabilize the left& right LCD hinge Attention: the screw driver torque is 2.0-2.2Kgf-cm...
  • Page 27 X340（MS-1352）Disassemble Guide 11、 LCD MODULE ASSY 11.10：Remove the 2 hook sponge on two side of hooks of panel; then remove the hooks as pic shows; Component Hook Sponge E2Y-3511411-Y42 11.11：Raise the display module from right side, then remove the module;...
  • Page 28 X340（MS-1352）Disassemble Guide 11、 LCD MODULE ASSY 11.13：Remove the display module from LCD cover; Component Display Module S1J-342G001-CC1 11.14：Remove the coaxial cable(Camera Cable)according to the sequence as pic shows; 11.15：Remove the CMOS camera module; Attention：don’t use too heavy strength when removing the camera module to avoid damaging camera module;...
  • Page 29 X340（MS-1352）Disassemble Guide 11、 LCD MODULE ASSY 11.16：Remove the MIC sponge covered on MIC module Component MIC Sponge E2Y-3511911-Y42 11.17：Remove the MIC Module as left picture show Attention: MIC module should be align with LCD cover dent. Component MIC Module S34-2100900-N44 11.18：Remove the Antenna board from LCD...
  • Page 30 （MS-1352）screws specification Photo Screw specification Label (M2*L2.5MM) white (M2*L3MM) white (M2*L3.5 MM) black (M3*L3.5 MM) white...
  • Page 31 （MS-1352） screws specification ■ 1、Lower Case ASSY total 10pcs screws; specification： Photo Screw specification Label (M2*L2.5 MM) white...
  • Page 32 （MS-1352） screws specification ■ 2、Upper Case ASSY total 6pcs Screws; specification： Photo Screw specification Label (M2*L3.5 MM) black...
  • Page 33 （MS-1352） screws specification ■ 3、Lower Case ASSY total 16pcs Screws; specification： Photo Screw specification Label (M2*L3.5 MM) black...
  • Page 34 （MS-1352） screws specification ■ 4、WLAN Module total 1pcs screws; specification： Photo Screw specification Label (M2*L3.5 MM) black...
  • Page 35 （MS-1352） screws specification ■ 5、HDD Module total 5pcs screws; specification： Photo Screw specification Label (M2*L3.5 MM) black (M3*L3.5 MM) white...
  • Page 36 （MS-1352） screws specification ■ 6、THERMAL-KIT total 5pcs screws: specification： Photo Screw specification Label (M2*L3.5 MM) black...
  • Page 37 （MS-1352） screws specification ■ 7、Mainboard total 2pcs screws: specification： Photo Screw specification Label (M2*L3.5 MM) black...
  • Page 38 （MS-1352） screws specification ■ 8、 Speaker Module total 3pcs screws； specification： Photo Screw specification Label (M2*L3.5 MM) black...
  • Page 39 （MS-1352） screws specification ■ 9、 LCD Hinge total 8pcs screws； specification： Photo Screw specification Label (M2*L3MM) white...

This manual is also suitable for:

Ms-1352
