- Page 1 LMB162ABC LCD Module User Manual Shenzhen TOPWAY Technology Co., Ltd. Rev. Descriptions Release Date Prelimiay release 2005-03-17 URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 1 of 11...
-
Page 2: Table Of Contents
Function Specifications ......................7 Basic Setting........................7 Resetting the LCD module ....................7 Adjusting the LCD display contrast..................7 Display Memory Map......................8 Display Commands ......................10 Design and Handling Precaution ..................11 URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 2 of 11... -
Page 3: Basic Specifications
: 80.0 x 36.0 x 15.8MAX (See attached Outline Drawing for details) Block Diagram LCD Panel 16 x 2 Char (5x8dots) S6A2067 S6A0065 equivalent equivalent DB0 – DB7 RS, R/W, E URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 3 of 11... -
Page 4: Terminal Functions
In 8 bit mode, DB0 ~ DB7 are in use In 4 bit mode, DB4 ~ DB7 are in use, DB0~DB3 leave open Power Backlight positive supply Power Backlight negative supply URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 4 of 11... -
Page 5: Absolute Maximum Ratings
Applicable Pin Forward Voltage Forward Current Cautions: Exceeding the recommended driving current could cause substantial damage to the backlight and shorten its lifetime. No. of LED = 10 x 2 pcs URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 5 of 11... -
Page 6: Ac Characteristics
E rise time E fall time Address set-up time Address hold time Data set-up time tdsw Data delay time tddr Data hold time Host Write Timing Diagram Host Read Timing Diagram URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 6 of 11... -
Page 7: Function Specifications
A Variable-Resistor must be connected to the LCD module for providing a reference supply to V0. Adjusting the VR will result the change of LCD display contrast. The recommended value of VR is 5k Ohm. LCD Module URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 7 of 11... -
Page 8: Display Memory Map
5 x 8 dots Not Use (0Dh) font pattern 5 x 8 dots Not Use (0Eh) font pattern 5 x 8 dots Not Use (0Fh) font pattern CGRAM Address Map URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 8 of 11... - Page 9 DDRAM Address DDRAM Address Map Note: *1. The mapping is based on top view of the LCD module *2. N=1, 2-line display *3. F=0, 5x8 dots font *4. D=1, display on URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 9 of 11...
-
Page 10: Display Commands
Note: *1. Do not use any other command not listed, or the system malfunction may result. *2. For the details of the Display Commands, please refer to S6A2067 datasheet. URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 10 of 11... -
Page 11: Design And Handling Precaution
LCD module reliability may be reduced by temperature shock. When storing the LCD module, avoid exposure to the direct sunlight, high humidity, high temperature or low temperature. They may damage or degrade the LCD module URL: www.topwaydisplay.com Document Name: LMB162ABC-Manual-Rev0.1.doc www.topwaysz.com Page: 11 of 11...
