Summary of Contents for MAKSIWA CBC.EC
- Page 1 CBC.EC Edge Bander INSTRUCTION MANUAL Attention: Read this manual before using your machine.
- Page 2 Sketch A. Make sure the Channel you will find several videos edgebander is connected to an outlet having the same that will help you whit Maksiwa´s configuration as the plug. No adapter is available or machines. To use the QRCODE.
- Page 3 distance from work area. • Extension cables. Make sure your extension cord is in good condition. When using an extension, be sure • Make the workplace childproof making use of of their ability to transmit the electrical current used padlocks, master keys or removing the ignition key. by your product.
- Page 4 All it is supported is not uneven. equipment MAKSIWA are tested at the factory. If this machine does not work, check the electricity supply. Check the compatibility of your outlet and plug the machine.
- Page 5 UNPACKING AND ASSEMBLY Due to modern mass production techniques, it is unlikely that Edgebander CBC.E MAKSIWA is faulty or have parts missing. If you find anything wrong, do not use the machine until the parts are replaced or the fault is corrected. By doing this you are avoiding serious injury.
- Page 6 Because of factory tests, their CBC.E can go with a certain amount of glue. The Edgebander CBC.E MAKSIWA is designed to work with PVC tape, ABS, paper and wood that do not have glue, only straight parts. Use tapes approximately 4mm wider than the wood panel.
- Page 7 1. STARTING AND CONTROL tape. - Do not remove the piece of tape. To turn on your CBC.E MAKSIWA proceed as follows: - With a piece of wood, make sure the guide is aligned - Connect the previously installed outlet at 110V single with the glue axis.
- Page 8 220°C (428°F), for near and above this temperature GLUE THICKNESS MAKSIWA do not recommended work with glues for high temperature because they can melt the tape. According to the first tests you will find an ideal - Once connected and adjusted with the temperature, amount of glue that must pass the panel.
- Page 9 Periodic maintenance on your Edgebander CBC.E this heat the machine until melt point of the glue, MAKSIWA will ensure optimum performance. Make it facilitating the glue axis cleaning. Once the glue is a habit to inspect your edgebander every time you melted, turn off the machine, stopping the axis in use it.
- Page 10 2. Within the warranty period, the hand labor and the Manufactured by: components replaced by manufacturing defect will be Maksiwa Industria e Comercio de Maquinas LTDA. provided for free as long as duly proved by Maksiwa St Nelson Argenta, 436 Service. Colombo – Parana – Brazil Zipcode: 83402-220 3.
- Page 11 (110V) and turn on the breaker inside of panel. Temperature Controller unregulated. Adjust the temperature settings. The glue is not heating Contact the Maksiwa Service to change Burned resistance. the resistance. The glue is not at the correct Check the glue temperature temperature.
- Page 12 EDGEBANDER EXPLODED VIEW CBC.EC...
- Page 18 WARNING LABELS: Warning labels are mounted on the right and back sides of the edgebander. Some of the warms on those labels may be additional to the warnings listed above. Be sure to read the warning labels before using the machine. Copies of the English text of the warning labels are reproduced below:...
