Roadmaster Even Brake Programming Instructions

Towing and Suspension Solutions
253649-01 02-08
ROADMASTER, Inc. 6110 NE 127th Ave.
T
he Even Brake motorhome monitor and the ICX transmitter must be programmed as a set. If a re-
placement monitor, a replacement ICX transmitter or a second vehicle kit is to be installed, follow the
instructions below.

Program the motorhome monitor

Until both the motorhome monitor and the ICX trans-
mitter are programmed as a set, the motorhome monitor
will not receive the signal from the ICX transmitter. Follow
the instructions below to program the monitor.
A second 12-volt outlet (in addition to the towed ve-
hicle's) will be necessary.
1. Before programming, first install Even Brake in the
towed vehicle — follow the installation instructions. Even
Brake must be completely installed, with both the ICX
transmitter cord and the power cord plugged in.
Read the installation instructions and the owner's
manual before installing or operating Even Brake.
Failure to understand how to install or operate Even
Brake could result in property damage, personal in-
jury or even death.
Note: Before transferring Even Brake to a second (or
third, or fourth) vehicle, it may be necessary to adjust
the feet to maintain stability. Refer to the section titled
"Adjust the feet and the seat pad" in the Even Brake
owner's manual.
2. Next, plug the motorhome monitor power cord into
the second 12-volt outlet. (This outlet must be receiving
power for the monitor to operate.) The LCD text display
will read "Even Brake."
3. Now, press the "Dim" button on the motorhome monitor
(Figure 1) for approximately six seconds, until the LCD
text display reads "Receiver is in Learn Mode."
4. Release the "Dim" button. The LCD text display will
read "Learning ICX #1 — Advance? OK ."
If you are installing a replacement motorhome monitor
or a replacement ICX transmitter into the towed vehicle,
press the button with the right-hand arrow (>) on the mo-
torhome monitor. The LCD text display will read "Press
Even Brake Test Button."
(If you are programming the monitor for a second
towed vehicle, press the button with the left-hand ar-
row (<) on the monitor to scroll to the next message
— "Learning ICX #2 — Advance? OK ." If you are pro-
gramming the monitor for a third or fourth towed ve-
hicle, continue to press the button with the left-hand ar-
ICX transmitter or second vehicle kit
Programming Instructions
Vancouver, WA 98682 800-669-9690
row (<) on the motorhome monitor to scroll to the ap-
propriate message in this series — "Learning ICX #3..."
or "Learning ICX #4...")
5. Press the green "Test" button (Figure 2) on the Even
Brake touch pad control panel. Even Brake will begin a
self-diagnostic test.
pedal clamp up and down three times. When the brake
Even Brake
replacement motorhome monitor,
part numbers 9410, 9420 and 9430
All specifications are subject to change without notice.
Fax 360-735-9300
2. LCD text display reads
Figure 1
"Receiver is in Learn Mode."
(As part of the test, Even Brake will cycle the brake
Figure 2
www.roadmasterinc.com
1. Press the "Dim" button
for six seconds.
continued on next page
Press the
"Test"
button.
