Makro Metal Detectors Racer Instructions

RACER BLUETOOTH HEADPHONES AND DONGLE
INSTRUCTIONS
These instructions explain the usage of the Philips SHB700 Bluetooth headphones with
the Bluetooth dongle used in the RACER metal detector. For more details on using the
headphones with other devices, charging and other features, please refer to the
headphone's original manual included in the box.

Charging the BT Headphones (USB)

• Press and hold the play/pause button for more than 1 second.
• If 1 short beep is heard and the LED starts flashing blue, it means that the charge is over
50%. If LED starts flashing white, it means that the charge is below 50%.
• To charge the headphones, plug the headphones into a powered USB port using the USB
charging cable. LED turns white during charging and turns off when the headphones are
fully charged.

Pairing the Headphones with the Dongle

1. Make sure that the Bluetooth headphones and the device are turned off.
2. To initiate the pairing mode on the headphones, press and hold the play/pause
'
button for at least 4 seconds.
3. The LED will start flashing blue. Keep on pressing the button. When the LED starts flashing
white and blue alternately, it means that the headphones are in pairing mode.
4. The headphones will stay in the pairing mode for about 2 minutes. If it does not pair with
the dongle during this time, it will shut off automatically.
5. Make sure that the device is still off and insert the Bluetooth dongle in its slot on the side
of the system box as shown in the figure. If you insert the Bluetooth
module while the device is on, you need to turn the device off and
on again.
