Summary of Contents for Embed SmartTouch Swipe
- Page 1 smartTouch™ Swipe User Manual Doc No. 720100010 Version 1...
- Page 2 The information in this document is distributed on an “as is” basis, without warranty. While every precaution has been taken in the preparation of this document, neither the author or Embed shall have any liability to any person or entity with respect to any loss or damage caused or alleged to be caused directly or indirectly by the instructions contained in this document or by the computer software or hardware products described herein.
-
Page 3: Table Of Contents
DC ............................... 9 OWER VOLT ..........................10 REDIT ONNECTIONS BASIC CONFIGURATION OF THE SMARTTOUCH SWIPE ................. 11 HOW IT WORKS ..............................11 FCC PART 15B COMPLIANCE STATEMENT ....................12 CE – DECLARATION OF CONFORMITY ......................12 VERSION HISTORY ............................... 13 Notice All images presented in this document are for illustration purposes only. -
Page 4: Safety Information
Do not use in life critical or applications requiring high reliability The smartTouch Swipe is not intended for use in systems that may affect human life or that require a very high degree of reliability such as medical equipment, nuclear facilities, aerospace equipment or transportation equipment. -
Page 5: Introduction
Major Components The smartTouch Swipe The smartTouch Swipe is the guest facing device that features a touchscreen display with a dedicated contactless type cards type reader. Guests will Swipe their card for the primary purpose of transacting at games and attractions. -
Page 6: Recommended Installation Hardware
The following is a recommended range of hardware to securely install and mount the smartTouch Swipe reader. The smartTouch Swipe reader uses 4mm brass inserts in the base of the enclosure so the appropriate length 4mm metric screws must be used to properly secure the smartTouch Swipe reader. -
Page 7: Pre-Installation
Disconnect the power from the game It is vital that you are certain the game is in proper working order before beginning the installation of the Embed hardware. This will prevent confusion later in the process. Never source and use wire taps or wire nuts. Wire taps cut into the wire and make a minimal connection that will deteriorate over time leading to game credit and power supply related problems. -
Page 8: Smarttouch Swipe Reader Installation
Swipe Reader Installation The smartTouch Swipe reader is best mounted and fixed to a location on the game that ensures it’s easily accessible to guests. In many cases it’s recommended to mount the smartTouch Swipe reader over the existing coin entry point as it is readily accessible and allows use of the existing hole for cable entry. - Page 9 Template for the smartTouch Swipe reader mount point drill holes. NOT TO 1:1 SCALE This template is available in scale PDF format from support@embedcard.com www.embedcard.com...
-
Page 10: Video Game Installation
Video Game Installation Standard type Video Games are typically strait forward to install with connections to the 12v DC Power Supply and Credit Input only. From start to finish you can expect to take 25-35 minutes. Harness Required The harness required for this installation is the “Standard Video Harness”. Standard Video Harness –... -
Page 11: Game Credit Connections
On the selected player station you can typically disconnect the common and normally open connectors from the existing coin switch and plug them directly into the pre fitted harness connectors. Connect the other end of the harness to the smartTouch Swipe at connector J7. www.embedcard.com... -
Page 12: Basic Configuration Of The Smarttouch Swipe
How it works The smartTouch Swipe is very simple to use . User simply present their cards over the display or user to transact or insert the card in the card slot and swipe . The user only needs to ensure the... -
Page 13: Fcc Part 15B Compliance Statement
CE – Declaration of Conformity The smartTouch Swipe equipment meets the requirement of EC dircetives for CE certification Directive 2014/53/EU the following standards are applied : EN 60950-1: 2006+A11: 2009+A1:2010+A12:2011+A2:2013 ETSI EN 301 489-1 V2.1.1, ETSI EN 301 489-3 V2.1.1, ETSI EN 301 489-17... -
Page 14: Version History
Version History V 0.0 Initial document T Venter 30/03/2016 V 0.1 Add typical installion picture T Venter 21/04/2016 www.embedcard.com...
