ASO-Safety contact edges GE F-series
ASO GE F-series stands out due to its flexible basis and
improved product properties. Once clipped into the supporting
profile it disappears completely behind the overlapping
material of the GE contact profile on the side. Due to the flexible
basis an improved actuating response is created.
Integrated contact sensor
Flexible end caps
Concealed mounting rail
GE F45 SK
Type
101 286
Article No.
Approvals
Current test certification available at: www.asosafety.com
Features
side clips base
Dimensions
B 34 mm x H 45 mm
Delivery length
25 m
GE F45 SKLi
GE F65 SK
101 287
101 296
side clips base,
side clips base
sealing lip
B 34 mm x H 65 mm
B 36 mm x H 65 mm
25 m
25 m
Clips on the side
GE F65 SKLi
101 297
side clips base,
sealing lip
B 36 mm x H 85 mm
25 m
Advertisement
Table of Contents
Summary of Contents for ASO Safety Solutions GE F-series
- Page 1 ASO-Safety contact edges GE F-series ASO GE F-series stands out due to its flexible basis and improved product properties. Once clipped into the supporting profile it disappears completely behind the overlapping material of the GE contact profile on the side. Due to the flexible basis an improved actuating response is created.
- Page 2 GE F-Serie Montageanleitung GE F-Series Assembly Instruction Die Montage von Sicherheitskontaktleisten darf nur durch autorisierte Personen erfolgen. Safety contact edges may only be installed by authorized persons. Vorbereitung: Gewünschte Position der Sicherheitskontaktleiste markieren. Das Aluminium Trägerprofil muß 7mm eingerückt montiert werden. (Überstand der Endkappe) Preparation: Mark the wanted position for the safety-contact-edge. Install the aluminium carrier profil 7mm intended. (Oversize of endcap) Einbaurichtung beachten ! Pay attention for the right installation side ! Damit sich die Sicherheitskontaktleiste problemlos montieren läßt, darf das Trägerprofil nur auf ebenen...
