SOCRATES Series
SHDSL.EVB.4CH
User Manual
Revision: 1.0.0, 2019-02-05
Teleconnect GmbH
Am Lehmberg 54
01157 Dresden/Germany
© 2019 Teleconnect GmbH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Socrates Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Teleconnect Socrates Series

  • Page 1 SOCRATES Series SHDSL.EVB.4CH User Manual Revision: 1.0.0, 2019-02-05 Teleconnect GmbH Am Lehmberg 54 01157 Dresden/Germany © 2019 Teleconnect GmbH...
  • Page 2 SHDSL.EVB.4CH User Manual Revision History: Current Revision: 1.0.0, 2019-02-05 Revision Date Comment 1.0.0 2019-02-05 Initial release Revision: 1.0.0, 2019-02-05 2/37 shdsl@teleconnect.de...
  • Page 3: Table Of Contents

    5.3.4 Configuring the system ..................29 5.3.5 Firmware update .....................30 Operation ........................33 Start-up with two boards ..................33 Using SHDSL.EVB.4CH as Module ................34 Scope ........................34 Connection ......................34 Protection .......................34 Literature ........................35 Appendix A. Quick Start-up guide ..................36 Revision: 1.0.0, 2019-02-05 3/37 shdsl@teleconnect.de...
  • Page 4 Figure 15: CLI example: password modification ..............28 Figure 16: CLI example for show modified SHDSL configuration .......... 29 Figure 17: CLI example for net configuration ................ 30 Figure 18: CLI example for show stored firmware list ............31 Revision: 1.0.0, 2019-02-05 4/37 shdsl@teleconnect.de...
  • Page 5: Introduction

    It is the first ever ready-to-copy reference design ® developed for the Intel SHDSL Chipsets. The SHDSL/Ethernet Bridge Modem was developed by Teleconnect and measures only about 11 x 12,5 cm. It is available for online purchase through: • Würth Elektronik webshop (http://www.we-online.com/socratesdemo).
  • Page 6: Content Of The Shdsl.evb.4Ch Evaluation Board Kit

    Intel Ethernet Network Connection GPY112 and offered by Intel ® ® In 2016, Microchip agreed to buy Atmel . That´s the reason why the Atmel microcontroller ATSAM4S is now part of Microchip product spectrum. Revision: 1.0.0, 2019-02-05 6/37 shdsl@teleconnect.de...
  • Page 7: Block Diagram

    The functionality of the Evaluation Board could also be realized with the 1ch versions ® of the Intel SHDSL Chipsets (PEF 21628 E). Teleconnect provides 1ch SHDSL Evaluation Board also (product code: SHDSL.1CH.EVB [2]). You can use one up to four channels with SHDSL.EVB.4CH.
  • Page 8 • Input and Output components (Würth Elektronik eiSos GmbH): o two Rotary switches and one DIP switch 5 pole, o two Push buttons, o ISP pin header for debugging of the microcontroller, o nine LEDs. Revision: 1.0.0, 2019-02-05 8/37 shdsl@teleconnect.de...
  • Page 9: Interfaces

    The connector X107 is an unshielded RJ45 connector. It is used for connecting the SHDSL.EVB.4CH up to four SHDSL lines (according ITU-T G.991.2 [3]). Table 1 shows the pin definition of X107. Revision: 1.0.0, 2019-02-05 9/37 shdsl@teleconnect.de...
  • Page 10 Figure 6 shows the schematic of the SHDSL hybrid with line transformer L101, L102, L103 and L104 and SHDSL data pump V101 (PEF 24628 E). Components and layout are influencing the SHDSL performance. Teleconnect can assist you with the selection of additional line protection at raw ambient conditions.
  • Page 11: Figure 6: (Extract From) Schematic Of Shdsl Hybrid

    SHDSL.EVB.4CH User Manual Figure 6: (Extract from) Schematic of SHDSL Hybrid Revision: 1.0.0, 2019-02-05 11/37 shdsl@teleconnect.de...
  • Page 12: Ethernet Interface Via Phy

    The transformer L302 connects the connector to the Ethernet PHY GPY112 V201 (PEF7072). ® The connection to the SHDSL data pump Intel SHDSL Chipset V101 is realized via standard MII interface. Figure 8 shows the schematic of the Ethernet interface via PHY. Revision: 1.0.0, 2019-02-05 12/37 shdsl@teleconnect.de...
  • Page 13: Figure 8: Schematic Of Ethernet Interface Via Phy

    SHDSL.EVB.4CH User Manual Figure 8: Schematic of Ethernet Interface via PHY Revision: 1.0.0, 2019-02-05 13/37 shdsl@teleconnect.de...
  • Page 14: Ethernet Interface Via Switch

    USB host interface with a short and high-quality USB cable. Beside the Micro USB connector SHDSL.EVB.4CH provides the possibility to use the pin header X801 spaced 2.54 millimeters (0.1 in) for power supply. Table 4 gives the pin definition. Revision: 1.0.0, 2019-02-05 14/37 shdsl@teleconnect.de...
  • Page 15: Power Consumption

    SHDSL.EVB.4CH features a serial interface (UART) for controlling and monitoring purposes. The interface is usable in two ways: UART emulation via USB interface and TTL-compatible interface via connector X601. Both interfaces have the same function and can work simultaneously. Revision: 1.0.0, 2019-02-05 15/37 shdsl@teleconnect.de...
  • Page 16: Debug Interface

    A normal firmware update can be done by the CLI firmware update procedure. Please see chapter 5.3.5 Firmware update for further information. During runtime and active BSI mode (DIP switch 3 = 0), Revision: 1.0.0, 2019-02-05 16/37 shdsl@teleconnect.de...
  • Page 17: Dip Switches

    2 x 192 Kbps = 384 Kbps Note: The test mode configuration via switch number 4 and 5 like at the SHDSL.EVB.1CH is not supported with SHDSL.EVB.4CH. This configuration can be done by the CLI (chapter 5.3). Revision: 1.0.0, 2019-02-05 17/37 shdsl@teleconnect.de...
  • Page 18: Rotary Switch (10 Pole)

    The configuration of fixed bitrates in extended rates mode is only possible by SHDSL Master (CO mode, STU-C). The SHDSL Slave (CPE mode, STU-R) ignores the switch position and always uses line probing (switch position 0). Revision: 1.0.0, 2019-02-05 18/37 shdsl@teleconnect.de...
  • Page 19 A red LED H506 (“ERROR”) indicates an error state. For normal operation this LED is off. The LED is on or starts blinking if an error has occurred. The error type will also print to the serial interface (USB UART emulation and hardware UART). Revision: 1.0.0, 2019-02-05 19/37 shdsl@teleconnect.de...
  • Page 20: Software

    If you have installed another revision than 2.18, you may experience errors with the driver. Or if Windows version (8 or lower) loads another driver version via Windows Update called "Bossa Program Port" please do not hesitate to contact us by E-mail: shdsl@teleconnect.de. The “Bossa Program Port” driver should work for Windows 10.
  • Page 21: Figure 10: Sam-Ba Menu: Select Connection And Board

    Select the firmware image Download the image to SHDSL.EVB.4CH Figure 11: SAM-BA menu: select firmware image and download them 8. The file will download. After that you can lock the involved lock regions or not. Revision: 1.0.0, 2019-02-05 21/37 shdsl@teleconnect.de...
  • Page 22: Shdsl.evb.4Ch Firmware 3.0

    • Usage of one, two, three or four SHDSL lines (PAF bonding). Teleconnect provides this free firmware image for evaluation proposes only. You can buy software license for commercial use from Teleconnect. Please see an overview over possible functionalities and packages in the following chapter. Beside this, Teleconnect can assist you in SHDSL software development for your customized version.
  • Page 23: Functions And Packages

    4.3 Functions and packages The following chapter should give you a short overview over functionalities provided by Teleconnect. All packages are included in this free firmware image for evaluation purposes. For further information and prices please contact us at shdsl@teleconnect.de.
  • Page 24: User Interfaces

    -- Startup -- ======================================================= Boot-Ver#: 3.0-R2559 SW-Ver#: 3.0-R2569 PHY-Ver#: 1.1-2.1.0__001 IDC-Ver#: 2.1.0.0 Serial#: 0123.E60B.C44F.2007 Vendor: Teleconnect GmbH Am Lehmberg 54 - 01157 Dresden - Germany shdsl@teleconnect.de Copyright (c) Teleconnect GmbH 2013-2018. All rights reserved. ======================================================= Revision: 1.0.0, 2019-02-05 24/37 shdsl@teleconnect.de...
  • Page 25 If you press the “ERASE” button, you will get a summary of state information. It looks like this: ####################################################### Boot-Ver#: 3.0-R2559 SW-Ver#: 3.0-R2569 PHY-Ver#: 1.1-2.1.0__001 IDC-Ver#: 2.1.0.0 Serial#: 0123.E60B.C44F.2007 Vendor: Teleconnect GmbH Am Lehmberg 54 - 01157 Dresden - Germany shdsl@teleconnect.de Copyright (c) Teleconnect GmbH 2013-2018. All rights reserved. ======================================================= Revision: 1.0.0, 2019-02-05 25/37 shdsl@teleconnect.de...
  • Page 26: Cli - Command Line Interface

    Please contact us at shdsl@teleconnect.de, and we can provide you your password. When you have changed the first password into your individual password the output will be deactivated (please see chapter 5.3.3).
  • Page 27: Cli Commands

    Manage system configuration sets /config/upload/ Upload new configuration sets /iface/ Manage interfaces /iface/net/ Manage network interface /iface/shdsl/ Manage SHDSL interface /sys/ Get the system information /sys/fw/ firmware update functions /sys/syslog/ Access the systems error log Revision: 1.0.0, 2019-02-05 27/37 shdsl@teleconnect.de...
  • Page 28: Password Modification

    The current password is needed to change it. It will be saved at flash memory after the confirmation of the new password and is active for the next login. The password needs between 5 and 20 characters. Figure 15: CLI example: password modification Revision: 1.0.0, 2019-02-05 28/37 shdsl@teleconnect.de...
  • Page 29: Configuring The System

    All configuration options related to the IP interface can be found in the directory /iface/net. Network can either be used on SHDSL line side or system side (Ethernet port) of one SHDSL Configuration. The following example changes IP address, netmask, gateway and side of the network interface. Revision: 1.0.0, 2019-02-05 29/37 shdsl@teleconnect.de...
  • Page 30: Firmware Update

    Both terminal applications ("Transfer XMODEM send" and "File send") are not supported by Putty by default. At this point we recommend the terminal program TeraTerm, where both actions can be found under the menu item "File". Revision: 1.0.0, 2019-02-05 30/37 shdsl@teleconnect.de...
  • Page 31: Figure 18: Cli Example For Show Stored Firmware List

    It can happen that the start of the file transfer leads to a series of error outputs. In this case, the upload of the firmware file can be repeated. After successful file transfer (may take several minutes), the output is made: APP#2 firmware update successful finished. / #> Revision: 1.0.0, 2019-02-05 31/37 shdsl@teleconnect.de...
  • Page 32 If the previously running firmware is not the one of the active firmware bank, the firmware is unpacked and copied to the flash area of the current firmware and started. This completes the firmware update process. Revision: 1.0.0, 2019-02-05 32/37 shdsl@teleconnect.de...
  • Page 33: Operation

    Connect the wall outlet to the Ethernet connector to the second board. • The green Ethernet LED is on if Ethernet connection was established. • The amber Ethernet LED starts blinking indicating Ethernet traffic. 7. Ready! You are using SHDSL for your data connection. Revision: 1.0.0, 2019-02-05 33/37 shdsl@teleconnect.de...
  • Page 34: Using Shdsl.evb.4Ch As Module

    The SHDSL.EVB.4CH is conceptualized as an evaluation platform. For this, SHDSL.EVB.4CH includes only basic protection. It is possible to add additional protection circuits on the host board to use SHDSL.EVB.4CH in rough environments. For further assistance you can contact Teleconnect at shdsl@teleconnect.de. Revision: 1.0.0, 2019-02-05 34/37...
  • Page 35: Literature

    [1] IEEE, „IEEE Std. 802.3-2008, Section 5: Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) access method and physical layer specifications,“ 2008-12-26. [2] Teleconnect GmbH, SOCRATES Series, SHDSL.EVB.1CH, User Manual, Dresden, 01/2019. [3] ITU, „ITU-T G.991.2: Single-pair high-speed digital subscriber line (SHDSL) transceivers,“ 12/2003.
  • Page 36: Appendix A. Quick Start-Up Guide

    Connect the wall outlet to the Ethernet connector to the second board. • The Ethernet green LED is on if Ethernet connection was established. • The Ethernet amber LED starts blinking indicating Ethernet traffic. Ready! You are using SHDSL for your data connection. Revision: 1.0.0, 2019-02-05 36/37 shdsl@teleconnect.de...
  • Page 37 * The configuration of fixed bitrates in extended rates mode is only possible by SHDSL Master (CO mode, STU-C). The SHDSL Slave (CPE mode, STU-R) ignores the switch position and always uses line probing (switch position 0). Revision: 1.0.0, 2019-02-05 37/37 shdsl@teleconnect.de...
