Summary of Contents for AWID HB-2000
- Page 1 HB-2000 Handheld RFID Reader HB-2000 User Operation Manual - 041478 AWID PROPRIETARY...
- Page 2 COPYRIGHT ACKNOWLEDGEMENTS The contents of this document are the property of Applied Wireless Identifications Group, Inc. (AWID) and are copyrighted. All rights reserved. Any reproduction, in whole or in part, is strictly prohibited. For additional copies of this document please contact:...
- Page 3 Further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. AWID PROPRIETARY...
-
Page 4: Table Of Contents
Use Power Supply for Terminal with Battery ................12 ..................13 INDICATORS ON TERMINAL ..........................13 UZZER HB-2000 SYSTEM RESET ..................14 BLUETOOTH MODULE AND CONNECTIVITY ............15 PAIRING HB-2000 WITH A PC ................16 HB-2000 ................. 16 LUETOOTH EVICE HB-2000 ....................... 16 EARCHING ..........................17 AIRING ................. -
Page 5: Revision History
REVISION HISTORY Version Date Sections Remarks Affected 9/2013 Initial version AWID PROPRIETARY... -
Page 6: Introduction
1 Introduction AWID's HB-2000 is a handheld terminal supporting multi-protocol operations. Designed for convenience, mobility and greater flexibility, the HB-2000, via Bluetooth connection, can be operated with a PDA, a Smartphone or a PC/Notebook, to receive and transmit data of RFID labels. -
Page 7: Specifications
Protocol language........... EPC C1 Gen 1 & 2, ISO Type B, C Read range............. Depends on type & size of labels used Output power............26.82 dBm Handheld Reader (HB-2000) Operating temperature range……………………..-20 C to +50 C (-4 F to 122 F) Color……………………..........White (front) Grey (back) Link interface……………………........Bluetooth Class 2... -
Page 8: Setting Up Hb-2000
Verify that all items listed below are present: HB-2000 Terminal Power Supply Battery HB-2000 Terminal The HB-2000 terminal is embedded with an UHF RFID module, UHF antenna, battery and external (left and right) triggers, buzzer sound outlet and LED status indicators. AWID PROPRIETARY... -
Page 9: Scanner Triggers
2) Simultaneously press both left and right triggers for more than 2 seconds puts HB- 2000 in sleep mode. 3) With HB-2000 in sleep mode, simultaneously press both left and right triggers for more than 2 seconds places HB-2000 in stand-by mode: both RFID module and Bluetooth stay off. -
Page 10: Circular Cover
5) With Bluetooth connected, if RFID is off (dimmed green LED), pressing either trigger once will turn on RFID (green LED lights up). 3.3 Circular Cover - Turn the circular cover left (counterclockwise) to open, right (clockwise) to close. AWID PROPRIETARY... -
Page 11: Installing Battery
at same time pull back battery compartment cover until released from latch, pull up. insert battery into compartment, be sure the blue triangle points upward press the cover toward orange latch until snapped in place AWID PROPRIETARY... -
Page 12: Power Charging
1) Power Supply Specifications Input: 100-240 VAC 0.55 A, 50-60Hz Output: 12 VDC 2A / Plug 2) Use Manufacturer Supplied Power Supply 3) Must first have battery in compartment 4) Refer to 3.6 for LED info. AWID PROPRIETARY... -
Page 13: Led Indicators On Terminal
LED indicators on terminal System LED 1) Steady Green - Stand-by 2) Blinking Orange - Data 3) Dimmed - HB-2000 in Sleep Bluetooth LED 1) Blinking Blue - Bluetooth Disconnected 2) Steady Blue - Bluetooth Connected 3) Dimmed - HB-2000 in Sleep... -
Page 14: Hb-2000 System Reset
9/16/2013 4 HB-2000 System Reset When a system reset is called for, remove the battery, wait until HB-2000 is completely powered off then replace the battery. Confidential Page 14 of 21 9/16/2013... -
Page 15: Bluetooth Module And Connectivity
Module remembers the connected device from the most recent successful pairing. Unless the HB-2000 is reset resulting in a re-paring, the Bluetooth Module will not accept a pairing request from another device. Even after a power reset (e.g., due to battery replacement), the module still remembers the most recent successfully paired-up device. -
Page 16: Pairing Hb-2000 With A Pc
6.2 Searching HB-2000 Click the "Add a device" button launches a search to identify Bluetooth device candidates. An example result window is shown in Figure 2 where an HB-2000 is listed. Either with built-in Bluetooth functionality or through use of a Bluetooth Dongle. -
Page 17: Pairing
"Next" brings up a window shown in Figure 3 for selecting a pairing option. Click on "Enter the device's pairing code" brings up window shown in Figure 4. Type in an HB-2000 preset pairing code value of "0000". - Page 18 9/16/2013 Figure 3 Pairing option selection window Figure 4 Pairing code entry Confidential Page 18 of 21 9/16/2013...
-
Page 19: Bluetooth Setup Confirmation
9/16/2013 6.4 Bluetooth Setup Confirmation Figure 5 Pairing completed Figure 6 Resulting Bluetooth Devices window Confidential Page 19 of 21 9/16/2013... - Page 20 HB-2000 for more information: Figure 7 HB-2000 Properties Window A serial communication between computer and HB-2000 can then be established through the displayed COM port at 57600 bps, the HB-2000 then basically functions like a fixed-location RFID reader. Confidential...
-
Page 21: Rfid Reader And Demo Sw
9/16/2013 7 RFID Reader and Demo SW Demo SW applications for testing HB-2000's RFID Tag operations are available for download from http://www.awid.com. Confidential Page 21 of 21 9/16/2013...
