Light Efficient Design LED-8929***-HAZ Series Installation Instructions Manual

Prior to installation, read the entire instructions
WARNING – Risk of fire or electric shock.
LED Retrofit Kit installation requires
knowledge of luminaires electrical systems.
If not qualified, do not attempt installation.
Contact a qualified electrician.
WARNING – Risk of fire or electric shock.
Install this kit only in the luminaires that
have the construction features and
dimensions shown in the photographs
and/or drawings and where the input
rating of the retrofit kit does not exceed
the input rating of the luminaire.
WARNING – Do not make or alter any open
holes in an enclosure of wiring or electrical
components during kit installation.
WARNING – To prevent wiring damage or
abrasion, do not expose wiring to edges of
sheet metal or other sharp objects.
• Make all electrical connection according to
national and local codes.
• Installers should not disconnect existing wires
from lampholder terminals to make new
connections at lampholder terminals. Instead
installers should cut existing lampholder lead
away from the lampholder and make new
electrical connections to lampholder lead
wires by employing applicable connectors.
• This retrofit kit is accepted as a component of
a luminaire where the suitability of the
combination shall be determined by
authorities having jurisdiction.
Input Rating:
Voltage: 120-277 VAC or 347VAC for C-HAZ
Frequency: 50/60Hz
Wattage: 24W
Included with the kit:
1. LED lamp
2. Label for modified luminaire
3. Instructions
4. Wire connectors (2)
Installation Instructions LED-8929***-HAZ
Luminaire Fittings Reference Table
GE Lighting Filtr-
1
& LED-8929***C-HAZ
Luminaire
Fitting
Gard®
Crouse-Hinds
Champ® VMV
Appleton
Mercmaster® III
Appleton
Mercmaster® II
Page Number
2
4
6
8
