Hitron HT-DW1 Quick Install Manual/Manual

HT-DW1
Sensor's
LED
housing
Start using your HT-DW1

1. Activate Battery

Slide open the sensor's housing and
pull the tab to activate it for pairing.

2. Join the Network

Follow the instructions on your iControl
touchscreen to add a new HT-DW1.
During the joining needs to be lower
case, the LED on the HT-DW1 will blink
while it's searching for the network.
More information about this process can be
http://www.hitron-americas.com
found at:
Quick Install Guide / Manual
Tab Magnet
Hitron's HT-DW1 is a micro door / window sensor,
uses a magnetic reed switch to detect when a
door, window, cabinet, garage door or any other
object is opened.
Tamper
switch
Battery
Key Features
Unobtrusive Compact Design
3+ Year Coin Cell Battery Life
Easy Installation with Tape or
Screws
Tamper Switch for Extra Security
100m Free Field, 60m+ Inside
Range

LED Indicators/ Troubleshooting

Status/Action
The LED will light
HT-DW1 is ON
battery is inserted.
The LED will flash
Search for network
quit flashing when it finds a network.
Holding the tamper switch, inserting the battery,
Factory reset and releasing it while the LED is green (within 2
seconds of inserting the battery).
Pressing and releasing the tamper switch 5 times
Forced rejoin
within 5 seconds.
Contents
HT-DW1
1 CR-2032 Battery
Screws and Tape (4 each)
Description
green for 2 seconds when the
( )
green 3 times each time. It will
( )
0440010170N0(1A)
