ENERAL NFORMATION ® ® The eForce Prox (3090P) and eForce iCLASS (3090C) lever operators have integrated contactless proximity readers that communicate with a Weigand protocol access control system. Utilizing HID 125kHz Prox or HID 13.56MHz ® iCLASS technology, the eForce offers reliable and secure ®...
FCC S TATEMENT This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
PERATIONAL ESCRIPTION Manual Operation – Key Cylinder 1. Insert key into lock cylinder. 2. Turn the key to the detent position. 3. Rotate the lever until latch or deadbolt clear the strike and open the door. 4. Return the key to a non-detent position that will allow the key to be removed.
ROUBLE HOOTING Green light comes on, but lever will not retract latch or deadbolt: ® ● Check the eForce body connection with lock/latch mechanism. ● Check the cylinder tailpiece length (see installation instructions). ● Check for proper door preparation (refer to door templates). Operator stays unlocked (unsecured): ●...
& E NSTALLATION OOLS QUIPMENT IMPORTANT NOTES: ● The 3090P-01 & 3090C-01 are designed exclusively for latching hardware including: 4500/4900 Deadlatches and 8000 Series Exit Devices. ® ● The 3090P-02 & 3090C-02 are compatible with MS Series Deadbolts only! These units are not interchangeable! ●...
STEP 1 DOOR PREPARATION (Fig. 1) • Select the stick-on template to match the application. • Mark the backset and horizontal centerlines. • Apply clear template over the centerline marks. (Fig. 1) • Center-punch four (4) referenced mounting holes and remove template.
STEP 3 CONFIGURE FOR LOCK SERIES Mortise Latch Application – 3090P-01 & 3090C-01 for 4500/4900 (including 8300/8400 Exit Devices) Configure the supplied cam plug to match the hand of door and insert into latch case with notch on the cam pug aligned with latch case setscrew. Tighten setscrew and secure with the two brass cam plug screws.
Page 11
RIM Exit Device Application – 3090P-01 & 3090C-01 for 8700/8800 • On the back side of the exit device, remove only the lower Phillips head screw, depending on hand of door, to free up the cylinder actuator for use. (Fig. 9) YLINDER CTUATOR SCREW Fig.
® STEP 4 HANDING THE eForce Prox & iCLASS • ® The eForce is shipped in a non-handed neutral position with the access cover off as shown. • ® To hand the eForce rotate the handle into the desired position until two detent clicks are completed.
STEP 5 MORTISE CYLINDER INSTALLATION • Using a Philips Head Screwdriver, remove the eight (8) #10-32 x 5/8” screws on ® the back of the eForce gently lift the back plate off the housing. ! There are wires AUTION connecting the housing and back plate assembly.
Page 14
® Mounting the eForce • Insert the properly dimensioned spindle into the output hub. • ® Mount eForce onto mounting bracket and guide spindle into Cam Plug (MS 1850 configuration shown). (Fig. 14) • ® The eForce must sit flush on the door surface.
Adams Rite Manufacturing Co. (hereinafter ADAMS RITE) manufactures its products in a manner to be free of defects. Should any defect of manufacture (in material or workmanship) occur in its products, ADAMS RITE, upon prompt notification and proof to its satisfaction that the product was defective in manufacture for the use intended by ADAMS RITE, will at its option, exchange the product, repair the defect or refund the price charged by ADAMS RITE, FOB factory based on the following schedule:...
