PSR-OR700
Caution:
Do not turn off the power or remove the USB flash memory during this operation.
Confirming the version number
1)Turn on the power of the instrument and wait until the main display appears.
2)Press the [FUNCTION] button, then select [UTILITY] → [OWNER] tab.
3)Press the [7▲] or [8▲] button.
4)Check the version number to proceed with the upgrade.
☆ version 1.04 or earlier ; Go on to step1.
☆ version 1.05 or later ; Skip step1-3 and Go on to stepA.
Boot Program Installation
1
Downloading the boot program
1) Download the Zip file.
2) Extract the two files included in the Zip file.
3) Insert the USB flash memory into your computer.
4) Copy the extracted files into the root directory of the USB flash memory.
2
Insert the USB flash memory containing the appropriate
program to the USB TO DEVICE terminal on the instrument.
Caution:
Make sure that the USB flash memory is connected properly to the terminal.
Do not try to force an incorrect connection; doing so may damage the terminal.
3
Installing the boot program
Simultaneously hold down the [PLAY/STOP] button on the panel and turn on the power.
Keep holding down the [PLAY/STOP] button until the following display is shown.
Note :
Please confirm that the System Booter shown as『ver.1.00』.
Installation Procedure
Advertisement
Table of Contents
Related Manuals for Yamaha PSR-OR700
Summary of Contents for Yamaha PSR-OR700
- Page 1 PSR-OR700 Installation Procedure Caution: Do not turn off the power or remove the USB flash memory during this operation. Confirming the version number 1)Turn on the power of the instrument and wait until the main display appears. 2)Press the [FUNCTION] button, then select [UTILITY] → [OWNER] tab.
- Page 2 Press the [PLAY/STOP] button twice to start installation. * When the installation is completed, the following display appears. Turn off the power switch on the instrument, and go on to stepA. Firmware Installation Downloading the firmware 1) Download the Zip file. 2) Extract the six files included in the Zip file.
- Page 3 Installing the firmware Simultaneously hold down the [PLAY/STOP] button on the panel and turn on the power. Keep holding down the [PLAY/STOP] button until the following display is shown. Note : Please confirm that the System Booter shown as『ver.1.01』. Press the [PLAY/STOP] button twice to start installation. * When the installation is completed, the following display appears.
- Page 4 Troubleshooting ☆ The power supply was cut off or the USB flash memory was removed during operation. - A complete reinstall is necessary. Perform the operation again from the beginning. ☆ The installation cannot be executed and an error message appears in the display. Check the following: ✓...
