- Page 1 GEKCO MODEL CLK036 DIGITAL CLOCK ASSEMBLY & OPERATION MANUAL GEKCO Inc. Copyright 2018 1565 SW Cypress Ln GEKCO Inc. McMinnville, OR 97128 All Rights Reserved P/N 595-324 REV 1.0 (503) 472-4770 Printed in the United States of America...
- Page 2 This page is intentionally left blank...
-
Page 3: Table Of Contents
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL TABLE OF CONTENTS INTRODUCTION ..............................3 OPERATIONAL SUMMARY .......................... 3 PARTS AND UNPACKING ..........................4 3.1............................4 EVEL ARTS 3.2..........................5 ISPLAY OARD ARTS 3.3............................ 5 OARD ARTS 3.4. - Page 4 GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL LIST OF FIGURES 1: M ....................10 IGURE OARD OMPLETED SSEMBLY 1 ........................10 IGURE OARD 3: M 2 ........................10 IGURE OARD 4: M 3 ........................10...
-
Page 5: Introduction
Operational Summary The Model CLK036 has 8 digits of seven segment displays to display time zone one HOURS (UTC), time zone 2 HOURS (local), MINUTES and SECONDS. -
Page 6: Parts And Unpacking
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL Parts and Unpacking The kit is packaged in the order that the assembly is recommended. Each assembly block has it’s associated parts bag. Only open a parts bag when called for during assembly to avoid misplacing parts. -
Page 7: Display Board Parts List
DIGITAL CLOCK MODEL CLK036 3.2. Display Board Parts List Clock 036 Display Board PCA parts kit, DBR836-KIT ITEM PART NO. DESCRIPTION DBR836-PCA LED Display Module Assembly 7-Segment 8 Digit 0.36” 131-1X05 Connector Header Male 1 row of 5 pins 255-25511... - Page 8 GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL 220-1420 Audio Piezo Transducer 30V 81-180912C Printed Circuit Board Main Board REV 1.0 GEKCO INC.
-
Page 9: Final Assembly Hardware Parts List
DIGITAL CLOCK MODEL CLK036 3.4. Final Assembly Hardware Parts List Clock 036 Final Assembly Hardware parts kit, P/N CLK036HDW-KIT ITEM PART NO. DESCRIPTION 255-25511 Hardware Standoff Nylon M3 x 12 mm 255-29346 Hardware Screw Nylon M3 x 0.50 mm Thread,... -
Page 10: Enclosure Parts List
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL 3.5. Enclosure Parts List Clock 036 Enclosure kit, P/N CLK036ENC-KIT ITEM PART NO. DESCRIPTION 86-18111901 Front Panel Acrylic 3mm Transparent Red 86-18111902 Back Panel Acrylic 3mm Clear 86-18111903 Top Panel Acrylic 3mm Clear... -
Page 11: Assembly Notes
DIGITAL CLOCK MODEL CLK036 Assembly Notes 4.1. TOOLS 4.3. SOLDERING You will need these tools to assemble your kit. Soldering is one of the most important operations you will perform while assembling Diagonal Cutters your kit. A good solder connection will form an ... -
Page 12: Step-By-Step Assembly
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL Step-By-Step Assembly 5.1. Main Circuit Board Figure 3: Main Board Top View 2 C1: 22 pF (22) radial-lead ceramic capacitor Figure 1: Main Board Completed Assembly C2: 22 pF (22) radial-lead ceramic... -
Page 13: Figure 5: Main Board Top View 4
DIGITAL CLOCK MODEL CLK036 fully seated in their holes, solder the rest of the Solder the leads to the foil and cut off pins to the foil. the excess lead lengths. RN1: 10 k 103 resistor pack. The next step is to install the mating... -
Page 14: Initial Tests
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL Main Board DISPLAY BOARD Verify that the resistance with the positive lead on D1 cathode ( the component end with the band) and negative lead on the MAIN ground pad TP1, is greater than 2k ohms. -
Page 15: Final Tests
DIGITAL CLOCK MODEL CLK036 Install the IC on the main circuit board: 3. Check capacitor values carefully. Be sure the proper value part is installed at each ( ) U1: ATMEGA328P IC capacitor location and that the negative ( ) mark or a positive ( ) mark is This completes the assembly. -
Page 16: Figure 9 Enclosure Back
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL Locate the clear back panel and insert Insert the two M3 x 12mm hex two white screws into their respective mounting standoffs and secure to the two rear screws. holes and add two ¼” spacers. Lay this assembly down on the work space with the screw threads facing up. - Page 17 DIGITAL CLOCK MODEL CLK036 Install two spacers over the mounting holes Add the front panel and make sure all pieces are aligned properly. Add two black screws and loosely tighten to secure the enclosure. Congratulations have successfully completed the assembly of the unit and now you can enjoy using a clock that you have assembled yourself.
-
Page 18: Theory Of Operation
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL Theory of Operation 11.1. Block Diagram DISPLAY BOARD UTC/LOCAL HOURS MINUTES SECONDS 8 8 8 8 8 8 DISPLAY DRIVER MAIN BOARD MENU REAL TIME CLOCK MICROCONTROLLER BUZZER The clock consists of two modules, the main board and the display board. The clock was designed this way to allow the same main board to use different display boards which could vary in size. -
Page 19: Display Board Circuit Description
This device uses a 3 wire, I2C interface to communicate with the microcontroller. Connector J2 is the programming interface connector. This allows the firmware to be modified and the ability to reprogram the microcontroller. The CLK036 main board looks just like a Arduino Uno and can use the popular Arduino IDE. -
Page 20: Firmware
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL Firmware 12.1. Flow Chart SET LOOP MENU LOOP 30 SECOND TIME OUT ON ALL FUNCTIONS MENU PLUS SELECT HOURS INCREMENT HOURS DISPLAY TIME MENU SET TIME PLUS MENU SELECT MINUTES INCREMENT MINUTES... -
Page 21: Firmware Design Description
DIGITAL CLOCK MODEL CLK036 12.2. Firmware Design Description PCA Pictorial Diagrams 13.1. Main Board GEKCO INC. Rev 1.0... -
Page 22: Display Board
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL 13.2. Display Board Figure 11 Display Board Top Side REV 1.0 GEKCO INC. -
Page 23: Figure 12 Display Board Bottom Side
DIGITAL CLOCK MODEL CLK036 Figure 12 Display Board Bottom Side GEKCO INC. Rev 1.0... -
Page 24: Schematic Main Board
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL Schematic Main Board REV 1.0 GEKCO INC. -
Page 25: Schematic Display Board
DIGITAL CLOCK MODEL CLK036 Schematic Display Board GEKCO INC. Rev 1.0... -
Page 26: Document Revision History
GEKCO DIGITAL CLOCK P/N CLK036 ASSEMBLY & OPERATION MANUAL Document Revision History 3-Dec-18 Initial Release REV 1.0 GEKCO INC.
