Summary of Contents for ENJI PRIME Enji MiniEye
-
Page 1: Quick Start Guide
FULL HD MINI DV SPORTS CAMERA QUICK START GUIDE... - Page 2 Please read this user manual carefully before any attempt to operate this product and keep it for your future reference. FEATURES: MINI camera recorder High definition full HD 1080P/720P Compact design, portable handheld Supports TV out, TV monitor video connection ...
- Page 3 Note:This item is without waterproof. OPEARTIONS: OPERATIONS: 1. CHARGING: When you receive your Enji MiniEye Camera, use the provided cable to fully charge the camera. Plug the mini-USB connector into the camera and the normal USB plug into your computer or use an external charger.
- Page 4 red LED indicates the charging cycle. After charging is completed, the LED turns into solid red. Keep charging the camera for additional 30 minutes. Battery life varies from 30 to 100 minutes depending on the use of the device. You can also connect the camera to an external power source to charge, while you are using the camera (in case that an SD-card is inserted already) It...
-
Page 5: Powering The Camera On/Off
2. POWERING THE CAMERA ON/OFF: To POWER ON the camera, push the ON/OFF button for 2 seconds to power the camera on. NOTE: If NO memory card is inserted, a blue LED will light for a few seconds, after that a red LED will flash and the camera turns off. - Page 6 To POWER OFF the camera, push the ON/OFF button for 6 seconds and the camera will turn off. 720P VIDEO RECORDING: With a blue LED light, push on/off button once to begin recording. The blue LED will flash 3 times and recording starts. At this time the LED light is off.
-
Page 7: Video Recording
1080P VIDEO RECORDING: Change to 1080P by using the 'Mode' button. Push the 'Mode' button once, and the LED will turn from blue to blue/red. Push the ON/OFF button once to begin recording. The LED will flash blue and red three times and the recording in 1080P begins. -
Page 8: Shooting Images
SHOOTING IMAGES: Change to Photo Mode by using the 'Mode' button. Push the 'Mode' button twice. The LED will turn from blue to red. Press the ON/OFF button to take photos. Press once, the red light flashes and takes a photo. NIGHT VISION: To activate night vision mode, make sure that the camera is on. - Page 9 off Night Vision. Then the red LED light will flash 2 times and night vision is off. 720P MOTION DETECTION : Power on the camera and wait until the blue LED lights up. Press the 'Mode' button for about 3 seconds. The blue/red LED light will flash three times indicating that motion detection is active.
- Page 10 blue/red flashing LED. Stop the detection mode by pressing the ON/OFF button. 1080P MOTION DETECTION : Power ON the camera and wait until the blue LED lights up. Change to 1080P by using the 'Mode' button. Push the 'Mode' button once, and the LED light will turn from blue to blue/red.
- Page 11 go to motion detection stand by. Once a new movement is detected, the camera begins to record again. A new movement detection is indicated by a short blue/red flashing LED. Stop the detection mode by pressing the ON/OFF button. RESETTING THE CAMERA Reset camera when it does not...
- Page 12 into the mic hole. When the blue LED light is off, the reset is done. Turn on the camera to resume use. 10. HOW TO VIEW YOUR VIDEO & PHOTO Use the provided cable to connect the camera to your computer or laptop. Plug the mini-USB connector into camera and the USB plug in your computer/ laptop.
- Page 13 11. HOW TO VIEW THE VIDEO IN REAL TIME ON TV Use the provided cable to connect the camera to the TV. Plug the mini-USB connector into the camera and the AV connector to your TV, so you can then watch your video live after you start the camera in any one of the modes.
-
Page 14: Time Stamp
'N' or 'Y' at the end to display or not the time stamp in your video/photo. 13. USING ENJI MINIEYE AS A WEBCAM It is possible to use the Enji MiniEye as a webcam, but not all programs support this... - Page 15 camera. One very interesting program is the 'Debut Video Capture Software' from NCH. Click on this link to download the software: http://www.nchsoftware.com/capture/index.html Installing and Using the software: Download the program from the website and install it.
- Page 16 Connect your Enji MiniEye to your computer and wait until the drivers are installed. (Note: you do not need to remove the SD-card.) The LED first lights up blue, then turns into blinking red, which means that the camera is in charging mode.
- Page 17 Open the 'Tools' menu, then 'Options'. In the Video tab, choose the device 'GENERAL-UVC '. The Enji MiniEye is now ready for use.
-
Page 18: Relevant Parameters
14. RELEVANT PARAMETERS: Items Relevant Parameters Video Resolution 1920*1080/1280*720 Image Resolution 12MP(4032x3024) Video Coding M-JPEG Video Frames 30fps Storage Max support 32GB Micro SD Card Type of Interface Mini 8 pin USB Battery Capacity Built-in 200mah Charging Time About 30-100 mins Working Duration About 2-3 hours Charging Voltage... -
Page 19: Frequently Asked
Get max 1 amp charger so that it won’t overheat. Does the Enji MiniEye Camera work without a TF card? No, it does not work without a TF card. What should I do when pause and frame skip occur in... - Page 20 TF card. Use a card reader to read the images and videos. Or install another video player or try a new formatted high-speed memory card. Is this camera bluetooth and wifi capable? No it is not. Must use the USB cable. Why is there noise when recording? Because of low battery, please make sure the camera is fully charged.
- Page 21 card (not included). It does not work with 64 GB TF card. 1080P (FHD) - 30fps or 15fps? Video Frame Rate: 30fps. How do you mount the camera to a bicycle handle bar or drone? It comes with an alligator type clip that clips to a snap on bracket at the back of the camera.
- Page 22 5 meters, yes, it can record the entire time while on Motion Detection mode. Can you also take pictures with this camera? Yes, absolutely you can take a picture with the camera. Can I put this on my door so I can see who is knocking? Only if you connect the camera to a PC or Mac like a webcam.
- Page 23 item is unable to support this function. How will I know when the camera is recording or when it is not recording? Is there an indicator? Yes, it has an indicator. How much does it weigh? 19 grams w/ memory card Can it be watched from iPhone? No.
- Page 24 Are there accessories to make it go underwater? Currently, there is no accessory to make it go underwater. Will this work outdoors where there is no electricity? Yes, it has an internal battery that will run from 30 to 100 minutes depending on the mode you are using.
