- Page 1 Gasoline Sweeper UKSD3150 Operation Manual IMPORTANT: READ SAFETY RUELS AND INSTRUCTIONS CAREFULLY.
-
Page 2: Table Of Contents
Contents P r e p a r a t i o n … … … … … … … … … … … … … … I n s t a l l a t i o n … … … … … … … … … … … … … … Operation and Regulation ……………………... -
Page 3: Preparation
*Description* Thank you for using our products. We hope you will spend many enjoyable hours using it. Please read through these instructions carefully. Learn all the controls and the correct use of the machine. 1. Preparation 1.1 Purpose and Features This sweeper is designed and built to sweep yards, roads, lanes and storehouses. - Page 4 1.2 Introduction of the Main Parts: 1. Clutch on right handlebar 2. Adjustment rider for brush direction 3. Speed control rider 4. Adjustment rider for head height 5. Clutch on left handlebar 6. Turning alignment pin 1.3 Safety Instruction Before assembly and putting the machine into operation, please read...
- Page 5 ever allow children to operate the equipment. Never allow adults to operate the equipment without proper instruction. Incorrect operation may result in bodily injury and damage to machine. Never use the machine if others, particularly children or pets are in the vicinity.
- Page 6 inspections or approaching running parts. 15. Inspect the air pressure in the tires prior to use and pay attention to sharp objects when using this unit to prevent the tire from being pierced. 16. Replace worn components for safety reasons prior to use. 17.
-
Page 7: Installation
or late at night, when people might be disturbed. Comply with times listed in local ordinances. 25. Limit the number of piece of equipment used at any one time. If use the machine at night, please check if the illumination system is in good condition first。... -
Page 8: Operation And Regulation
4. Put the speed handle into speed spacing frame, then fix the handle on the body of machine by screw. 3. Operation and Adjustment Warning: before using this unit, read through the safety instructions in the first part! 3.1 How to start the engine Turn the switch to “ON”. - Page 9 A. In the loosing position, the sweeper won’t start sweeping B. Press the clutch downward and the sweeper will starts to work. 2. Operation of clutch on right handlebar: the right handlebar with the function of: DRIVE CONTROL. (The user will be able to choose the speed gear according to the at a various speeds need and move the equipment forward handlebar...
-
Page 10: Maintenance
B. Turn the brush to left by pushing the machine left. Warning! Protective equipment recommended when this machine. 4. Maintenance Storage after use: 1． Clear off dirt from the unit. 2． Never place a unit with a gasoline engine in the room. If necessary, keep it away from fire sources. - Page 11 Any failure to work due to manufacturing or testing shall be maintained and repaired by professional customer service agencies. This operation manual is prepared based on the latest type of this unit. The manufacturer reserves the right to modify it without notice.
- Page 12 Troubleshooting Fault Possible cause Corrective actions Engine does not start Consult engine manual Consult engine manual Engine runs Consult engine manual Consult engine manual unevenly(stutters) Machine does not V-belt slack or torn Have slack V-belt sweep tightened. Have torn V-belt replaced.
-
Page 13: Key Technical Parameters
6. Key technical parameters UKSD3150-55 UKSD3150-65 UKSD3150-70 N.W. 66 kg 68 kg 70 kg Cleaning 68cm/27in. 73cm/29in. 78cm/31in. width Brush 40cm/16in. 40cm/16in. 40cm/16in. diameter Chute rotating 20° 20° 20° angle Moving 2.7 ~4.8 km/h 2.7~4.8 km/h 2.7~4.8 km/h speed 5.5hp/4.1kw 6.5hp/4.8kw...
