Summary of Contents for Nuvair Titan
- Page 1 User Manual Titan Nitrox System Rev 01.19...
- Page 2 Every effort was made to ensure the accuracy of the information contained within. Nuvair, however, retains the right to modify its contents without notice. If you have problems or questions after reading the manual, stop and call Nuvair at 1-805-815-4044 for information.
-
Page 3: Table Of Contents
Titan Nitrox System Table of Contents Introduction Introduction ............................4 Safety Warnings ..........................5 Safety and Operation Precautions ....................7 Legal Precautions ..........................8 Theory of Operation ......................... 9 Low Pressure Air Compressor Technical Data …………………………………………………………. 10 7.0 High Pressure Compressor Technical Data ……………………………………………………..….. -
Page 4: Introduction
Titan Nitrox System Introduction This manual will assist you in the proper set-up, operation and maintenance of the Nuvair Titan Nitrox System. Be sure to read the entire manual. Throughout this manual we will use certain words to call your attention to conditions, practices or techniques that may directly affect your safety. -
Page 5: Safety Warnings
Titan Nitrox System Safety Warnings Nuvair has taken extreme care in providing you with the information you will need to operate this system. However, it is up to you to carefully read this manual and make the appropriate decisions about system safety. - Page 6 Titan Nitrox System Do not use this system to produce Nitrox mixtures containing more than 40% oxygen. Pumping Nitrox mixtures with higher concentrations of oxygen may lead to fires or explosions, which can cause serious personal injury or death. The use of enriched air Nitrox does not eliminate the risk of decompression sickness (DCS) in diving.
-
Page 7: Safety And Operation Precautions
Safety and Operation Precautions can result in injuries or equipment damage. However, Nuvair does not state as fact or does not mean to imply that the preceding list of Safety and Operation Precautions is all-inclusive, and further that the observance of this list will prevent all injuries or equipment damage. -
Page 8: Legal Precautions
Titan Nitrox System Legal Precautions It is highly recommended that a Nitrox fill log be maintained when filling Scuba cylinders to document the following information. This log must be of permanent binding style with no loose pages. ♦ Fill date and time of day ♦... -
Page 9: Theory Of Operation
Nitrox for precise content. The HP Compressor pumps the Nitrox to a maximum pressure of 3600 psi (250 bar) to fill Scuba Tanks or storage cylinders. A unique feature of Nuvair Nitrox Systems is that the feed air pressure that correlates to a specific Nitrox %O is repeatable. -
Page 10: Low Pressure Air Compressor Technical Data
Titan Nitrox System Low Pressure Compressor Technical Data Capacity and Power Consumption: • Normal working pressure – 165-175 psi (11-12 bar) • Capacity at normal working pressure – 23.5 CFM (666 L/min) Delivery • 29.9 CFM (847 L/min) Displacement • Compressor speed of rotation – 1035 rpm •... -
Page 11: High Pressure Compressor Technical Data
Titan Nitrox System 7.0 High Pressure Compressor Technical Data Capacity and Power Consumption: • Normal working pressure – 3600 psi (250 bar) • Charging Rate - 9 SCFM (255 L/min) * • Compressor speed of rotation – 1350 rpm • Maximum working pressure – 5000 psi (354 bar) •... -
Page 12: System Components
• Low Pressure Compressor, including: ♦ Magnet Motor Starter ♦ Hour Meter ♦ External Lubricant Sight Gauge, Fill, and Drain ♦ Nuvair 455 Food Grade Compressor Lubricant • Low Pressure Volume Tank: ♦ 120 Gallon Horizontal, other remote configurations available ♦ Automatic Condensate Drain •... -
Page 13: Nitrox System Specifications
Titan Nitrox System 9.0 Nitrox System Specifications Delivery @ 175 psi (12 23.5 CFM FAD bar) (666 L/min) Horsepower – 7.5 hp Electric (5.5 kW) Height 52 in (132 cm) Width 89 in (226 cm) Depth 42in (107 cm) Weight... -
Page 14: Nitrox System Component Identification
Titan Nitrox System 10.0 Nitrox System Component Identification Air Intake Filter HP Compressor Filter Canister Permeate Oxygen Fill Whip Analyzer Fill Oxygen Analyzer Volume Tank Pressure Fill Pressure Gauge Gauge LP Compressor Feed Air Control Filtration Switch (3 Stage) Feed... -
Page 15: System Drawing/Schematic
Titan Nitrox System 11.0 System Drawing / Schematic NUVAIR www.nuvair.com Page... -
Page 16: System Flow Chart
Titan Nitrox System 12.0 System Flow Chart LP Compressor Produces LP LP Aftercooler Removes Feed Air (Supply Air) Moisture LP Volume Tank Collects Moisture and Delivers Feed Air LP Feed Air On/Off Flow Titan Valve Controls Feed Air Nitrox System Components Shown Within Dashed Lines LP>LP Regulator Reduces... -
Page 17: Installing The Nitrox System
Titan Nitrox System 13.0 Installing the Nitrox System If any information in this manual conflicts with any of the other manuals call Nuvair before proceeding. Ambient room temperature should never exceed 100 F (38 C) during operation of the Nitrox System. -
Page 18: Electrical Power Connection
Titan Nitrox System 13.3 Electrical Power Connection Never use extension cords to provide power to your Nitrox System. The system must be properly wired according to national and local electrical codes by a qualified electrician. Improper wiring may lead to fires, which can cause serious personal injury or death. -
Page 19: Pre-Operation Instructions
Titan Nitrox System 14.0 Pre-Operation Instructions Do not allow Nitrox to be discharged into the air storage system. Nitrox introduced into the air storage system could cause a diver to suffer from oxygen poisoning at depth. Oxygen poisoning is extremely dangerous and can lead to drowning. -
Page 20: Oxygen Analyzer Calibration
Titan Nitrox System Oxygen Analyzer Calibration Gas production may be monitored with the Permeate Oxygen Analyzer before entering the HP Compressor to obtain a rough estimate of %O (+/- 2%); however, do not rely on this reading as an indication of %O at the HP Compressor outlet. - Page 21 Titan Nitrox System Calibrate Oxygen Analyzers as follows: 1) Turn off the LP Feed Air by rotating the feed air supply valve slowly up to the closed. LP Feed Air Switch LP Feed Air Supply Valve (on position) 2) Slightly open fill whip valve on HP...
-
Page 22: Attaching Scuba Cylinder
Titan Nitrox System Fill Oxygen Analyzer - Alternate Calibration Method Fill Oxygen Analyzer The Fill Oxygen Analyzer can also be calibrated in ambient air as an alternative. This is especially useful during routine re-calibration while the system is operating. Different settings may be used depending on location, so verify your actual ambient conditions and refer to the Oxygen Analyzer manual for details. -
Page 23: Producing Nitrox
Titan Nitrox System 15.0 Producing Nitrox The equipment you will be using to manufacture Nitrox (oxygen rich air) will expose you to both low and high-pressure gas. Gas, even under moderate pressures, can cause extreme bodily harm. Never allow any gas stream to be directed at any part of your body. -
Page 24: Setting Proper Pressure
The Heater Thermostat Control green indicator light will stay on until operating temperature is reached. Do not change the temperature setting on the Thermostat Control without contacting Nuvair. Changes in temperature settings may cause Membrane damage. A damaged membrane will not produce the correct Nitrox mixture which can lead to severe personal injury if the gas is used for diving purposes without proper analysis. -
Page 25: Pumping Nitrox
Titan Nitrox System 15.4 Pumping Nitrox The use of enriched air Nitrox does not eliminate the risk of decompression sickness (DCS) in diving. Decompression sickness lead permanent disability death. The Permeate O Analyzer supplies oxygen readings that can vary +/- 2% O... - Page 26 5) Test the Nitrox %O in the cylinder using an independent Oxygen Analyzer such as the Nuvair O Quickstick. Calibrate analyzer before use in accordance with manufacturer’s instructions. 6) Repeat steps 1-5 until you have filled all Scuba cylinders.
-
Page 27: Pumping Air
Auto shut off switch at the factory ( This is set based on purchasers directions to Nuvair) . 2) Manually shut off the Membrane System by turning the Feed Air Regulator adjustment knob CCW to reduce pressure to minimum setting and then turn off the LP Feed Air Valve. -
Page 28: Nitrox Operational Notes
Titan Nitrox System 16.0 Nitrox Operation Notes 16.1 Correlation of Feed air Pressure to Oxygen Content After the 10 hour break-in period for your Nitrox System, you will notice that specific Nitrox %O ’s always match specific feed air pressures once the System has warmed up. These pressures will be repeatable. -
Page 29: Maintenance
2) HP Compressor Lubricant: Change Compressor Lubricant every 100 hours or annually, whichever comes first. Only use lubricants rated for use with Nitrox, such as Nuvair 455 Never mix Compressor Lubricants. See Section 17.4 and HP Compressor manual for details. - Page 30 Titan Nitrox System 3) LP Air Filtration Inspection: On a weekly basis, inspect each Filter Bowl for the presence of moisture and each Element for any unusual degradation or wetness. See Section 17.5 for details. 4) LP Air Filtration Elements: Change LP Filter Elements every 200 hours. When a dryer (see page 33) is used with the system or hot and humid environment exists this number can vary to maintain CGA Grade D air standards.
-
Page 31: Compressor Lubricant
Titan Nitrox System 17.3 Compressor Lubricant The LP and HP Compressors in your Nitrox System comes standard with Nuvair 455 Synthetic Food Grade Compressor Lubricant. Check lubricant levels at each Sight Gauge and add lubricant as required through the appropriate Fill Plug. Lubricant is removed through the Drain Plugs. See LP and HP Compressor manuals for details on servicing Lubricant. -
Page 32: Lp Feed Air Filtration
2) Inspect Elements for any unusual HF7-20 HF5-20 HF1-20 degradation or wetness. Element Partical Coalescing degradation can indicate more serious Vapor & &Water/Oil problems. Contact Nuvair for assistance. Removal Moisture Vapor Removal Removal Replacement Element Part Number E7-20 E5-20 E1-20 HF1-20 Filter... - Page 33 This will assist to prolong the life of the element, bowl, and auto drain. Titan Refrigerated Air Dryer Option (pictured) With the addition of a Refrigerated Air Dryer you will extend the life of your Low Pressure Filters.
-
Page 34: Hp Compressor Filtration
Titan Nitrox System 17.5 HP Compressor Filtration The HP Compressor comes standard with Triplex filtration, utilizing a single Filter Element. Do NOT use any substitute. Change Filter Element every 13,000 cubic feet of air or Nitrox processing. If the Nitrox System is operated in high humidity and/or high temperature, Filter Element must be changed more often. -
Page 35: Spare Parts List
Titan Nitrox System 17.6 Spare Parts List See LP and HP Compressor manuals for Compressor parts lists. Other Nitrox System components and related items are listed below. Nitrox System Components Type Part Number LP Compressor Consumables Reciprocating Compressor Lubricant, Food... -
Page 36: Service Record Log
Titan Nitrox System 17.7 Service Record Log Technician Name Date Service Performed NUVAIR www.nuvair.com Page... -
Page 37: Appendix
Titan Nitrox System Appendix Supply and Breathing Air Specifications All supply and breathing air must meet the following requirements of CGA G-7.1-1997. Supply air delivered to the Membrane System must be purified to meet Grade D or E quality, and periodic air quality testing to assure compliance is recommended. -
Page 38: Owner's Warranty Responsibilities
• To prevent Membrane damage, drain all low pressure filter and volume tank condensate on a daily basis. • If you become aware of an operational fault, stop using the equipment immediately and contact Nuvair for assistance. Maintenance: • Change low pressure filter elements on a schedule determined by filter capacity and ambient temperature and humidity. -
Page 39: Warranty
NUVAIR has employed in the installation or use of any OEM component. This warranty is not transferable. NUVAIR will, at it’s discretion and according to the terms as set forth within, replace or repair any materials which fail under normal use and service and do not exhibit any signs of improper maintenance, misuse, accident, alteration, weather damage, tampering, or use for any other than the intended purpose. - Page 40 Nuvair Phone +1 805 815 4044 Fax +1 805 486 0900 1600 Beacon Place Oxnard, CA 93033 USA info@nuvair.com www.nuvair.com Rev 01.19...
