Summary of Contents for dji IN2BS
- Page 1 Battery Station ( For TB50 ) User Guide 使用说明 使用說明 ユーザーガイド 사용자 가이드 Bedienungsanleitung Guía de usuario Guide de l'utilisateur Guida dell'utente Gebruiksaanwijzing Manual do utilizador Руководство пользователя V1.2 2018.04...
- Page 2 This product and document are copyrighted by DJI with all rights reserved. No part of this product or manual shall be reproduced in any form without the prior written consent or authorization of DJI.
- Page 3 24. Air Intake 11. Firmware Update Port (Micro USB) 25. WCH2 Charging Hub Slot 12. Air Vent 26. WB37-4920mAh-7.6V Intelligent Battery Slot 13. AC Power Cable Slot 27. TB50 Intelligent Battery Slot 14. Battery Port © 2018 DJI All Rights Reserved.
- Page 4 When both pairs reach 90%, the station will continue to charge until all the batteries are fully charged. • Inserting already-paired batteries into the same pair of battery ports to charge is recommended. © 2018 DJI All Rights Reserved.
- Page 5 6.6A 34.2 33.8 29.9 29.7 15min 13min 47min 43min : Battery communication failure, failed to charge a battery, or permanent battery failure. : Short circuit on the remote controller charging port. : Fan blocked. © 2018 DJI All Rights Reserved.
- Page 6 Beeping Pattern Intelligent Battery (Batteries) in a pair of Quick beeping Battery ports is (are) fully charged Alternating two short and one long beeps, lasting for All Intelligent Batteries are fully charged about 1 hour © 2018 DJI All Rights Reserved.
-
Page 7: Specifications
1. Connect the Battery Station to a power outlet and press the Power Button to turn on the Battery Station. Connect the Battery Station to a computer using a Micro USB cable. 2. Launch DJI Assistant 2 and log in with a registered DJI account. 3. Select “Battery Station” and click “Firmware Upgrade” on the left-hand side.
