Unleash Your Inner Pitmaster!

QUEBQ ASSEMBLY MANUAL

The QueBQ smoker firebox provides competition-style smoke flavor to your

kamado. The QueBQ is a stick-burner firebox designed in the same manner

as the firebox on competition-style smokers, and your kamado is the food

chamber. The smoke and hot air from the QueBQ firebox is directed through

ducts and a chimney with a unique air control valve system into the inlet hole

on the body of your kamado.

In this assembly, you'll put together the QueBQ and then readjust your

kamado so that the air inlet is connected to the chimney.

The User Manual has important information on how the QueBQ kamado

smoker works, and how it works with your kamado. The User Manual also

discusses smoking and using the QueBQ as a smoke source for your kamado

cook – an entirely new way to cook barbeque!

PARTS LIST

(1) Stick Burner Main Body

(4) Attachment Angles

(1) Door Latches

(1) Door Vent Slide Handle

(2) Door Vent Slide Brackets

(1) Hardware Pack

(x3) PULL, DULL, STAINLESS STEEL

(x4) CASTER, ½-13 STEM

(x8) DOOR SLIDE BOLT

Summary of Contents for Quebic Industries QueBQ

Page 1 The smoke and hot air from the QueBQ firebox is directed through ducts and a chimney with a unique air control valve system into the inlet hole on the body of your kamado.
Page 2 Allen wrench set LOCATION 1. Plan the location of your QueBQ ahead of time. The firebox should be set up on a secure, level surface. Avoid having to move it up stairs or steep ramps if possible. Use appropriate handling equipment where necessary –...
Page 3 2. The QueBQ should only be used outdoors where good ventilation is present. 3. Do not locate your QueBQ near combustible materials or flammable vapors or liquids. 4. Do not locate under any overhead combustible construction. 5. Do not use on wooden structures without a fireproof mat.
Page 4 See Figure 1 - When received, remove the parts boxes and the fire grate from inside the QueBQ firebox. Do not take the QueBQ body off the cardboard pallet base. Install the four casters on the QueBQ body. On the cardboard base, pull loose the flaps holding the lip of the cardboard.
Page 5 Figure 1...
Page 6 See Figure 2 - Assemble the chimney. Insert 4 bolts (11) through the chimney top (2), the center damper spacer plate (5), and the lower chimney section (1). Install and tighten the nuts. NOTE: orient the center damper spacer plate (5) so that the opening is towards the front depending on which side of the firebox the chimney is to be installed.
Page 7 through the damper slot on the side of the chimney. Using a small phillips head screwdriver, install and tighten the stop screw/nut on the damper. Insert the two outer dampers (2 holes in each) in the guides on the chimney assembly. Install and tighten 2 stop screws/nuts in each damper.
Page 8 See FIgure 3 - Install the door vent. Place two small shoulder bolts (8) through the top holes in the back of the firebox door (1), through the vent plate (3), then started into the top glide bracket (7). Put shoulder bolts through the bottom holes, vent plate holes, and started into the glide brackets (6 and 7), as shown.
Page 9 Place kamado base on QueBQ. Locate your QueBQ where you are going to use it. Be careful not to damage the coating when installing the base. Carefully place the kamado base on top of the QueBQ firebox with the kamado air inlet oriented to the chimney adapter plate and 90 degrees from the front.
Page 10 QueBQ by bolting on its logo. And the journey begins . . . Be sure to read the Users Manual before firing your new QueBQ up. The QueBQ smoker system and a kamado create a cooking system unlike any other you've cooked on. Not only do you have more air and smoke control options, but the QueBQ features the ability to do combo cooks.
