Summary of Contents for Seca CC100 PREMIUM
- Page 1 SYSTEM MANUAL Radio fire alarm system SeCa CC100 PREMIUM Edition FZ201009...
-
Page 2: Table Of Contents
Contents 1. CC100 PREMIUM radio fire alarm control panel ................4 Versions ........................... 4 Function ........................... 4 Operation and display elements ..................4 Installing the control panel ....................5 Switching on the CC100P radio fire alarm control panel (initialization) ........5 Configuration menu ...................... - Page 3 Monitored operation ....................... 28 10.2 Unmonitored operation ....................28 10.3 Service operation ......................28 Radio module status information ................... 29 Miscellaneous ........................29 12.1 Technical data ....................... 29 12.2 Conformity ........................29 © Copyright SeCa GmbH Page 3 of 32...
-
Page 4: Cc100 Premium Radio Fire Alarm Control Panel
1. CC100 PREMIUM radio fire alarm control panel Versions The CC100 PREMIUM radio fire alarm control panel is available in three models: 1. a version with an integrated power adaptor, 2. a version with a plug-in power unit, and 3. a version for the installer. -
Page 5: Installing The Control Panel
After power is connected, the device undergoes a self-test and then the green Power LED and the red Check Off LED light up to indicate that there is no sensor status monitoring; the number 100 appears in the display. Configuration menu P 1 and P 2 – not assigned © Copyright SeCa GmbH Page 5 of 32... - Page 6 F3 (setting the number) and F4 (confirming the number and changing to the next place). The PIN query can be deactivated though setting ―0000‖ (until the next gen- eral reset). © Copyright SeCa GmbH Page 6 of 32...
- Page 7 If the horn is shut off (setting 0 = factory default setting), only the detector that senses the alarm signals it acoustically. Additionally, the MIDI 100 PREMIUM can signal this visually with a flasher (depending on the settings). The control panel signals every event acoustically, regardless of this setting. © Copyright SeCa GmbH Page 7 of 32...
- Page 8 SE) is reset after maintenance has been performed. For alarm testing the sensors without the CC100 PREMIUM Assistant software, set value 2 (visual only) or 3 (visual and acoustic), the Test On LED glows at this setting. If the alarms are acknowledged at the control panel, they are not forwarded.
-
Page 9: Function Keys
01), and then immediately press F2 and F3 briefly. You can use F3 to call up all assigned addresses. To get the normal display back, use F1 to delete these addresses one after the other. © Copyright SeCa GmbH Page 9 of 32... -
Page 10: System Registration
The radio module has already been logged on and is addressed. Do a general reset of the radio module and log in again. When in doubt, you can use the CC100 PREMIUM Assistant software to read out the data (see Chapter 11, Radio module status information). -
Page 11: General Reset For A System Component
2. Battery not connected, substandard or at low capacity. Replace the batteries! When in doubt, measure the voltage under load! All system CC100 PREMIUM detectors run on premium batteries. Use only those recommended by the manufacturer. - Page 12 If the building is not suitable for a radio system, you can replace it with a combined system or a conventional solution. In either case, contact your supplier’s technical support. © Copyright SeCa GmbH Page 12 of 32...
-
Page 13: Model 100 Premium Radio Repeater
2 Model 100 PREMIUM radio repeater Function Device for extending the radio link between system components and the CC100 PREMIUM radio fire alarm control panel as well as other repeaters (cascading), forwarding of alarms and status reports from a maximum of 16 system components (without repeaters). In a SeCa CC100 PREMIUM system, five 100 PREMIUM radio repeaters can be operated and up to three cascades can be built. -
Page 14: Turning On The Model 100P Radio Telephone Dialler (Initialization)
The signal strength of all system components to the control panel and to all model 100 radio repeaters is measured and serves as the basis for the topology build-up. The CC100 PREMIUM Assistant software shows these values in a signal strength chart with an evaluation. -
Page 15: Installing The 100 Premium Radio Control Module
Insert the batteries, mak- ing sure to observe the correct polarity. 8. Screw the housing cover back on and turn the 230V AC power supply back on. © Copyright SeCa GmbH Page 15 of 32... -
Page 16: Turning On The Model 100P Radio Control Module (Initialization)
In variation from this standard setting you can set up individual assignment of events to the relay con- tacts with the help of the CC100 PREMIUM Assistant software. Expanding the 100P radio control module to 4 or 6 relay contacts Adding two additional relay modules for the 100P radio control module (4800025) allows it to be ex- panded to a maximum of 6 relay contacts. -
Page 17: Model S Smoke Detector With S 100 Premium Radio Module
(the LED stays off) after the battery is connected, repeat the process. Note: Previously addressed radio modules are in receiver mode for the first 30 sec. after the voltage is applied. Meanwhile, all other functions are locked. © Copyright SeCa GmbH Page 17 of 32... -
Page 18: Temperature Detector With 01 100 Premium Radio Module
Temperature detector reports ambient temperature rise, triggers at 57°C, with plug-in 01 100 PREMIUM radio module for transmitting alarms and status reports to the CC100 PREMIUM radio fire alarm control panel or 100 PREMIUM radio repeater. It additionally signals alarms and malfunctions using an LED and horn on the detector. -
Page 19: 100 Premium Radio Push-Button Alarm
(the LED of the radio module stays off) after the batteries are connected, repeat the process. Note: Previously addressed radio modules are in receiver mode for the first 30 sec. after the voltage is applied. Meanwhile, all other functions are locked. © Copyright SeCa GmbH Page 19 of 32... -
Page 20: Midi 100 Premium Radio Siren And Flasher
P5, System parameter 7, ―Detector horn‖). This configuration is done at the CC100P radio fire alarm control panel (only global ON or OFF for all) or by using the CC100 PREMIUM Assistant software (individual). The factory default setting for this system parameter (= detector horn off) shuts off the acoustic signal. -
Page 21: Medium / Large 100 Premium Radio Telephone Dialler
If the radio module does not initialize (the LED stays off) after the battery is connected, repeat the proc- ess. Note: Previously addressed radio modules are in receiver mode for the first 30 sec. after the voltage is applied. Meanwhile, all other functions are locked. © Copyright SeCa GmbH Page 21 of 32... -
Page 22: Configuring The Radio Telephone Dialler
An entered call number will be changed as follows. As you page through the RUFNR menu with the key to the call number, press the key and the NEIN key to erase it. New entry as described above. © Copyright SeCa GmbH Page 22 of 32... - Page 23 Endmeldung? After the signal tone, please press 55 on your telephone to confirm receipt of the mes- 8 sec. (end message) sage. Hilfsmeldungen? – Are recorded at the factory. (help messages) © Copyright SeCa GmbH Page 23 of 32...
-
Page 24: Call Service
4. Confirmation by dialling 55 subsequent to the end message ends the call service. © Copyright SeCa GmbH Page 24 of 32... -
Page 25: Resetting All System And Line Parameters
If that doesn’t work, environmental conditions have changed since the last commissioning. Fix this by changing the topology. For this you can use the CC100 PREMIUM Assis- tant software’s Analyser function in the context menu. If the system components cannot be reached, or no alarm can be set off, bring the system component near the assigned repeater or the control panel and try again. -
Page 26: Battery Malfunction
No status from repeater This report appears only in the main window of CC100 PREMIUM Assistant, and not at the control panel. This report indicates that a repeater is no longer communicating with the control panel. In such a situa- tion, no status reports are received for the system components that communicate through it. -
Page 27: Alarm
(J5), or between an alarm duration for acoustic (siren) signalling of 4 and 30 minutes (J4). These settings can only be made when the power is off. CC100 PREMIUM radio fire alarm control panel operational status (see Operational statuses) ... - Page 28 Parameter 8 to make service settings. Recommendation: Always record the annual service or maintenance work in the maintenance log (CC100 PREMIUM Assistant), test the alarm reports and check the signal strengths and battery voltage. © Copyright SeCa GmbH Page 28 of 32...
- Page 29 Fundamentals for the authorized professional installer 11 Radio module status information With the CC100 PREMIUM Assistant software, the software versions and status information (address, group, horn settings and production parameters) of the detectors, signal devices and radio repeaters can be displayed. These data are radio transmitted as follows: Press and hold the programming key on the radio module until its LED blinks (after about 10 sec.), and then release the key.
- Page 30 System parameters 4, 5, 7, 11, 21, 22, 27 System stability 7 LED for control panel status 5 LED for system component status 4 Test On 5, 8, 28 List of indirect system components 9 © Copyright SeCa GmbH Page 30 of 32...
- Page 31 SeCa CC100 PREMIUM system manual Fundamentals for the authorized professional installer © Copyright SeCa GmbH Page 31 of 32...
- Page 32 SeCa GmbH Schwabenmatten 17a 79292 Pfaffenweiler Germany Telephone +49 (0) 7664/504030 +49 (0) 7664/504040 www.seca-online.de info@seca-online.de © Copyright SeCa GmbH Page 32 of 32...
