  • Page 1 (Version: V2.1) ACA Digital Corporation February -2009...
  • Page 2 ACA Digital has many years experience in designing computers to meet severe environmental applications. These applications include those found by military as well as industrial users. The P37B has been designed to comply with the relevant requirements of MIL_STD-810F, MIL-STD-461E and IP67. These include EMC, EMI, temperature, Shock, vibration, humidity, dust and water.
  • Page 3 Regulatory Compliance Statements FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 • Use only the AC adapter, power cord, and batteries that are approved for use with this P37B. Use of another type of battery or AC adapter may cause risk of fire or explosion. • If you use an extension cable with the AC adapter, ensure that the total ampere rating of the products plugged in to the extension cable does not exceed the ampere rating of the extension cable.
  • Page 5 Battery Safety • There is a risk of explosion if the battery is replaced by an incorrect type. • Dispose of used batteries according to the instructions. • Do not dispose of batteries in a fire. They may explode. Check with local authorities for disposal instructions.

  • Page 6: Table Of Contents

    Table of Contents Chapter ONE.........................8 1.1. Introduction ........................8 1.1.1. Features ..........................8 1.1.2. Package Contents ........................10 1.1.3. Optional Accessories......................10 1.2. Familiarize with the P37B..................11 1.2.1. Front View ..........................11 1.2.2. Right View ..........................12 1.2.3. Bottom View ........................13 1.2.4. Left View ..........................13 1.2.5. Back View...........................14 1.2.6.
  • Page 7 3.5. Removing a CF Card....................27 3.6. Inserting an Micro SD Memory Card ..............27 3.7. Removing a Storage Card..................28 3.8. Connecting Devices to the P37B ................28 3.9.1. Connecting USB .........................28 3.9.2. Connecting a Serial Device ....................30 3.9.3. Connection to a LAN ......................30 3.9.4.

  • Page 8: Chapter One

    Total Cost of Ownership (TCO). The P37B incorporates a transflective LCD with touch-screen, keypad, Wifi, and Bluetooth communication capability. To minimize the Total Cost of Ownership the P37B is sealed to meet IP67 standards and complies with IEC 68-2-32 5 foot drop to concrete. 1.1.1. Features...
  • Page 9 P37B Military PDA Specification Items Description Windows Mobile 6.1 / Windows CE 5.0 Intel PXA270 624MHz Memory 256MB SDRAM on board 256MB/512MB Flash ROM on board Display 3.7” transflective TFT LCD, VGA resolution (640 X 480)/QVGA resolution (320 X 240)

  • Page 10: Package Contents

    7. External Military Connector Box: converting 2 XRS-232 and 2 XUSB to one military connector 8. 4-IN-1 battery charger 1.1.2. Package Contents The standard P37B includes the following items: P37B PDA unit power cord & Adapter battery stylus & string 1.1.3.

  • Page 11: Familiarize With The P37B

    Navigation Keys Power Button Item Description LCD touch Displays the applications and data stored the P37B. It screen is a touch-sensitive screen and can be operated using the stylus or finger. Navigation Press these keys to navigate in the P37B interface.

  • Page 12: Right View

    SW Reset Press the end of the stylus into the button to reset the Switch P37B. A reset allows your device to get a fresh start, similar to warm rebooting a computer. Earphone Plug Connects to audio line-out devices (earphones or headphones) for use in noisy environments.

  • Page 13: Bottom View

    1.2.3. Bottom View Cradle Connector Battery Cover Latch Item Description Cradle Connects the P37B to cradle, enabling battery connector charging also connects RS232, USBA and USB mini B). Battery Cover Unlock the latch to open the battery compartment Latch cover, to place or remove battery.

  • Page 14: Back View

    1.2.5. Back View Stylus Battery Compartment Item Description Stylus Enables you to interact with the operating system. Remove the stylus from the holder and hold and use it the same way you would a pen or pencil. For use with the touch screen..

  • Page 15: 4-In-1 Battery Charger (Optional)

    Lock Battery pack into position for Battery Holder charging. DC IN Jack Connect the AC adapter to this jack to supply power to the charger and charge the P37B Battery. Status LED Indicates that power and the P37B battery is charging. RED light -Battery is charging.

  • Page 16: Cradle (Optional)

    USB type A port Connects a USB type A (host) cable. (host) Cradle Connects the P37B to the cradle, Provides connections connector for RS232, USB type A and mini USB type B. USB mini type B Connects a USB mini type B (client) cable.

  • Page 17: Chapter Two

    Chapter TWO 2.1. Getting Started This chapter explains how to install and charge the battery, how to check the battery status, how to turn on the P37B, and how to calibrate the screen. 2.2. Connecting the P37B 2.2.1. Installing the battery This part explains how to install the battery.
  • Page 18 Status Charging Ready Power ．Amber flashing ．Amber light light ．Amber flashing Power ON ．Amber light with Green light 1. Remove the battery compartment cover. 2. Align the battery contacts with the contacts in the compartment and place the battery in the compartment as shown below. 3.

  • Page 19: Charging The Battery

    2.2.2. Charging the Battery Before using the P37B for the first time it will need charging for about 3 hours. The P37B can be charged using the power adaptor or the Cradle. NOTE: When the battery power is below 10%, the P37B will enter suspend mode.

  • Page 20: Charging The Battery With The Cradle

    2.2.4. Charging the Battery with the Cradle 1. Slide the P37B into the cradle until it clicks into place. 2. Plug the AC adapter cable into the power connector on the cradle (A). 3. Plug the power cable connector into the AC adapter (B), Plug the...

  • Page 21: Powering Up For The First Time

    After you have charged the P37B for about 3 hours the device is ready to be used. You can now start up the P37B when you can calibrate the touch screen, practice with the stylus and set the date, time and zone.

  • Page 22: Setting The Time And Date

    calibrated. 3. After calibration is finished, press the Enter key to save the settings or press Esc to revert to the previous settings. NOTE: To recalibrate the screen at any time, tap Start ? Settings? Control Panel. Then double-tap Stylus. Tap the Calibration tab, and tap Recalibrate.

  • Page 23: Adjusting The Screen Brightness

    4. Select a field in the time box and tap the arrows next to the time to change the value of the field. 5. Tap the drop-down arrow next to Time Zone to select the correct time zone for your area. 6.
  • Page 24 4. Under Backlight Control, click the Dark arrow to make the screen darker, or click the Bright arrow to make the screen brighter. 5. Click OK to save and exit the utility.

  • Page 25: Chapter Three

    3.1. Using the Hardware 3.2. Keypads and Function Buttons The keypad enables you to both enter information and interact with the P37B operating system. 3.2.1. Entering Characters with the Keypad The operating system has an onscreen keyboard that enables you to enter alphanumeric characters with the stylus.

  • Page 26: Using The Stylus

    4. Double-tap on the checkerboard graphic to set your double tap rate. 3.4. Inserting a CF Card The P37B accommodates a CF card. You can to the functionality of the P37B by installing a CF memory card NOTE: It is not exhaustive.

  • Page 27: Removing A Cf Card

    2. Press the button again to push the CF card out. 3.6. Inserting an Micro SD Memory Card The P37B has a SD card slot compatible with a wide range of Micro SD cards, which are primarily used to back up or transfer files and data. The slot also supports SDHC cards.

  • Page 28: Removing A Storage Card

    Connecting a USB Type A The illustration below shows how to connect a USB type A device to the P37B. The connector can only go in one way. If it does not go in smoothly, check the orientation and try again.
  • Page 29 Connecting a MINI USB Type B The illustration below shows how to connect a mini USB type B cable to the P37B. The connector is keyed to only go in one way. If it does not go in smoothly, check the orientation and try again.

  • Page 30: Connecting A Serial Device

    3.9.2. Connecting a Serial Device Connect a serial device to the P37B to perform serial communications. Please see below illustration 3.9.3. Connection to a LAN The P37B is connected using a RJ-45 connector. See below:...

  • Page 31: Connecting Headphones And A Microphone

    3.9.4. Connecting Headphones and a Microphone The P37B utilizes an external microphone and speaker. A headset and microphone can be used in noisy environments. See the illustration above. 3.9.5. Connecting to the Cradle (Optional) The cradle allows for charging the batteries as well as connecting USB...
  • Page 32 Connecting USB There is one USB Type A connector on the back which supports both USB keyboard and mouse. In addition there is one Mini Type B USB port next to the Type A USB connector. See the above illustration Connecting a Serial Cable A serial cable can be connected theP37B cradle.

  • Page 33: Chapter Four

    In order to exchange data between your computer and the P37B and install extra applications or utilities to the P37B, Microsoft ActiveSync must be installed on your computer. Connect the P37B to a PC using a USB type B cable. Download the latest version of Microsoft ActiveSync from the Microsoft website.
  • Page 34 5. Follow the onscreen instructions. 6. When the configuration process is complete, the ActiveSync window appears. 7. Synchronization will be initialized and will take place if you’ve chosen to synchronize periodically or upon connection. 8. ActiveSync detects the P37B and establishes a connection.

  • Page 35: Connecting With Bluetooth

    9. Click No, and then click Next. 4.3. Connecting with Bluetooth Your device is equipped with Bluetooth wireless technology that you can use to synchronize information with a computer equipped with a Bluetooth adapter or access point. Bluetooth wireless technology allows you to communicate with the computer whenever it is within range.
  • Page 36 Authenticate: tap to authenticate the device and add the device to the trusted devices list. Encrypt: tap to enable or disable encryption of data transferred between the P37B and a Bluetooth device. Delete: Deletes the device from the Bluetooth Manager list...

  • Page 37: Connecting To A Wlan (Wifi)

    4.4. Connecting to a WLAN (WiFi) Through a WiFi (wireless) connection you can add a new network, connect to an existing network, change the advanced wireless settings and view wireless networking log information. To establish a WiFi connection, follow the steps below: 1.

  • Page 38: Connect To An Existing Network

    2. When the following screen displays, input the required parameters as explained in the following table: 3. Click OK to connect. 4.4.2. Connect to an Existing Network 1. Select a network from the list and press Connect or right-click for more options.

  • Page 39: Changing The Advanced Settings

    2. Click OK to connect. 4.4.3. Changing the Advanced Settings 1. Tap the Advanced button to display the advanced wireless settings (the preferred networks will be listed and preference is given to networks at the top of the list). 2. To move a network up or down in priority, tap the Up or Down buttons. 3.
  • Page 40 4. To automatically connect to non-preferred networks, click the box. 5. To select which networks to access, tap the drop down menu and choose the required option.

  • Page 41: View Wireless Networking Log Information

    4.4.4. View Wireless Networking Log Information Tap the Log button to display the log information.

  • Page 42: Chapter Five

    13%. If the battery does not accept a charge, contact Technical Support. 5.3. Optimizing Battery Life You can extend the P37B battery life by doing either of the following: • Change the automatic power settings • Minimize the use of the backlight 5.3.1.

  • Page 43: Adjusting Backlight Settings

    – Switch state to User Idle: P37B enters power saving mode when there is no user input after the selected timeout. The backlight brightness is reduced. The backlight resumes normal brightness when the LCD is Touched.

  • Page 44: Performing A System Reset

    1. Remove the stylus from its holder. 2. Lightly press the tip of the stylus to the reset button located on the P37B. 5.5. Changing the Screen Resolution It may be necessary to change the screen resolution from VGA to QVGA, or from QVGA to VGA.

  • Page 45: Rotate Screen

    2. Wait for the P37B Re-start. 5.6. Rotate Screen It may be necessary to rotate the screen display from standard throught either 90, 180 or 270 degrees.
  • Page 46 1. Start -> PROGRAM-> Utilizes-> DispSet 2. Select the angle of rotation.
