Cleveland Motion Controls Cleveland-Kidder TMI Instruction Manual

Tensi-master indicators

Advertisement

Quick Links

1.0 GENERAL INFORMATION
1.1 RECEIVING AND UNPACKING
Handle and unpack the equipment carefully.
Immediately upon arrival, check the shipment against the
packing list. Any damage should be reported
immediately to the carrier and to the nearest CMC
representative.
Equipment which will not be installed immediately should
be stored in a clean, dry location. Precautions should be
taken to prevent moisture, dust and dirt from
accumulating in storage and installation areas.
1.2 SPECIFICATIONS
Electrical
AC Supply
- 100/115/230VAC ±10%,
Input Power
- 15 VA
Transducer
Excitation
- 5.6 VDC
Tension
Output Signal
- 0-10 VDC, 5 mA
Conditioned
- 0-10 VDC, 5 mA or adjustable
Tension Output
0-2 VDC, approximately 2K
Signal
Calibration
- Full scale range of 8:1
TLD Output
- 1 N.O. & 1 N.C. 5 Amp,
Contactor
(Optional)
Isolation
- 0-10 VDC, 5 mA or 4 to
Amplifier
(Optional)
INSTRUCTION m m . A800-7425 J (Page 1 of 16)
50/60Hz, Jumper selectable
Ohm output impedance
250 VAC resistive (each limit)
20 mADC, 1500 VRMS
(2000V peak) isolated
Operating Conditions
Ambient
Temperature
- 0-40EC (32-104EF)
Relative
Humidity
- 5% to 95% (w/o condensation)
Altitude
- to 6600 Ft. (2000 meters)
Weight
Enclosed Indicators - 12 Lbs.
Open Panel
Indicators
- 3 Lbs.
1.3 DESCRIPTION
The indicators are assembled from modules as shown in
Figure 1 on page 2. The modular approach improves
versatility by increasing the combinations of features
available.
1.3.1 Circuit Boards - There are two circuit boards
available.
- Standard Circuit Board
- TRL Circuit Board
The Standard circuit board amplifies the signals from the
transducer(s) and provides a tension output signal which
represents the total tension measured by the
transducers.
The TRL circuit board independently amplifies the
signals from each of two transducers, the left transducer
and the right transducer of the sensing roll. There are
three tension output signals from this circuit board, one
for the left transducer, one for the right transducer, and
one for the total of the left and the right.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cleveland-Kidder TMI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cleveland Motion Controls Cleveland-Kidder TMI

  • Page 1 1.0 GENERAL INFORMATION 1.1 RECEIVING AND UNPACKING Handle and unpack the equipment carefully. Operating Conditions Immediately upon arrival, check the shipment against the Ambient packing list. Any damage should be reported Temperature - 0-40EC (32-104EF) immediately to the carrier and to the nearest CMC representative.
  • Page 2: General Information

    GENERAL INFORMATION A800-7425 J 2 of 18...
  • Page 3 GENERAL INFORMATION 1.3.2 Operator Panels - There is a selection of five wiring harness extension are used. Shielded wire should operator panels which have the following switches. be used as shown on the installation wiring diagram. - ON/OFF 1.3.6 Connector Plate Option - The connector plate has - ON/OFF + TLD two 5 pin receptacles for transducer cables and a 3 pin - ON/OFF + TLD + TLD...
  • Page 4 when the tension level goes out of range and the switching of the TLD relay. 1.0 GENERAL INFORMATION Figure 2 Tension Limit Detector Level Pot - For TLD 12. Jumper - This moveable jumper should be in option only. This adjustment sets the tension level position 7J for use with digital tension meter.
  • Page 5: Installation

    The indication system shown in Figure 3 utilizes two strain gate transducers and sums the signals in the indicator. The Tensi-Master indicators can also be used for cantilever, wire, and single transducer applications. 1.0 GENERAL INFORMATION Figure 3 2.0 INSTALLATION AC VOLTS JUMPER WARNING...
  • Page 6 CMC P/N DESCRIPTION Transducer X43-06825 5 Pin Connector Cable MS-3106A-14S-5P X43-06928 Clamp and Bushing Amphenol 97-3057-1007-1 Tension X43-07181 3 Pin Connector Output MS-3106A-14S-7P Signal X43-06928 Clamp and Bushing Amphenol 97-3057-1007-1 2.0 INSTALLATION 2.1 AC POWER CORD HOOKUP (MO-03074) Position on wire Position the strain relief bushing on the line cord as shown.
  • Page 7 Route the required output contact wiring from the Tension Limit Detection Relay Card terminal block through this conduit. See Figure 5. 1 /2" AC POWER CORD 1 .7 MOUNTING LOCATION, TLD OUTPUT CONTACTS SIZE HOLE FOR 1/2 INCH ELECTRICAL CONDUIT Figure 5 3.0 ADJUSTMENTS WARNING...
  • Page 8 3.0 ADJUSTMENTS the right transducer. Calibrate the left transducer with be suitable to calibrate using a 100 lb. weight (or the TRL switch in the left position and calibrate the right 100 lbs. force on a spring scale). transducer with the TRL switch in the right position. Using the CALIBRATE adjustment bring the With a screwdriver, turn the calibrate adjustment meter needle to the desired reading.
  • Page 9 ADJUSTMENTS 3.4.1 TLD Low Limit Calibration - Put TLD select DIGITAL TENSION METER switch to L position. In order for the TLD circuit to operate, the TLD switch on the front cover must be on A signal conditioning circuit is included on the indicator (illuminated).
  • Page 10: Troubleshooting

    TROUBLESHOOTING WARNING These Troubleshooting Instructions are for use by qualified personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the Operating Instructions unless you are qualified to do so. EXCESSIVE OUTPUT SIGNAL WITH NO LOAD Try to re-zero with zeroing pot(s).
  • Page 11: Replacement Parts

    6.0 SERVICE ASSISTANCE AND OUTPUT SIGNAL NOT LINEAR, OR ZERO SHIFTS DURING OPERATION REPAIR Check transducer and tension roll mounting. All For additional service assistance, please obtain the mounting bolts must be tight. Check that there is no dirt Type, MWF, and Serial Number from the nameplate. or foreign matter interfering with the transducer Contact the Factory Service Department.
  • Page 12: Outline Dimensions

    OUTLINE DIMENSIONS A800-7425 J 12 of 18...
  • Page 13 OUTLINE DIMENSIONS A800-7425 J 13 of 18...
  • Page 14: Installation Wiring Diagram

    INSTALLATION WIRING DIAGRAM CIRCUIT BOARD ASSEMBLY T L D CARD T L D 1 OFF SCHEMATIC, TLD OPTION CIRCUIT BOARD ASSEMBLY TRANSDUCER TENSION SIGNAL T L D CARD T L D NOTE: T L D TERMINALS 1 & 2 NORMALLY CLOSED AND 3 &...
  • Page 15 INSTALLATION WIRING DIAGRAM INSTRUCTION m m . A800-7425 J (Page 1 of 16) A800-7425 J 15 of 18...
  • Page 16 INSTALLATION WIRING DIAGRAM A800-7425 J 16 of 18...
  • Page 17: Warranty And Limitation Of Liability

    WARRANTY AND LIMITATION OF LIABILITY CLEVELAND MOTION CONTROLS, INC. LIMITED WARRANTY. OF GOODS. ALL GOODS ARE SOLD SUBJECT TO THE MUTUAL AGREEMENT THAT THEY ARE WARRANTED BY THE COMPANY TO BE FREE FROM DEFECTS MATERIAL WORKMANSHIP FOR ONE YEAR FROM THE DATE OF SHIPMENT. THE...
  • Page 18 LIMITATION OF REMEDY AND LIABILITY. THE REMEDY PROVIDED HEREIN IS BUYER'S SOLE AND EXCLUSIVE REMEDY. THE BUYER'S REMEDY AND THE COMPANY'S LIABILITY (WHETHER UNDER THE THEORIES BREACH WARRANTY, CONTRACT, TORT INCLUDING NEGLIGENCE OR STRICT LIABILITY OR ANY OTHER LEGAL THEORY) SHALL BE LIMITED EXCLUSIVELY AT THE COMPANY'S OPTION TO REPLACING...
