Meanings of icons:
Forbidding: forbid improper operations to avoid damaging the
Notebook PC.
Caution: cautions for operators to avoid potential damages.
Please note and remember.
Importance: important information, common notes, definitions,
general knowledge and references, etc.
Other trademarks and trade name may be used in this manual to refer
to either the entities claiming the marks and names or their products.
The manufacture disclaims any proprietary interest in trademarks and
trade names other than its own.
Information in this manual is subject to change without notice.
Reproduction in any manner whatsoever without the written
permission from the manufacture is strictly forbidden.
Product images in this manual are for your reference only.
Directions
1
Advertisement
Table of Contents
Summary of Contents for malata PC-81006
-
Page 1: Directions
Directions Meanings of icons: Forbidding: forbid improper operations to avoid damaging the Notebook PC. Caution: cautions for operators to avoid potential damages. Please note and remember. Importance: important information, common notes, definitions, general knowledge and references, etc. Other trademarks and trade name may be used in this manual to refer to either the entities claiming the marks and names or their products. -
Page 2: Table Of Contents
Content Directions ..........................1 Safety Precautions .......................4 1 Knowing Your Notebook PC ....................6 1-1 Top Side ........................6 1-2 Right Side ........................7 1-3 Left Side ........................7 1-5 Bottom Side ........................7 2 Caring the Notebook PC....................8 2-1 LCD Screen ........................8 2-2 Hard Disk Drive (HDD) ....................8 2-3 Battery Pack .......................9 2-4 Keyboard ........................9 2-5 Touch Pad ........................9... - Page 3 8 Power Managing System....................21 8-1 Battery System ......................21 8-1-1 Checking Battery Power ..................21 8-1-2 Charging the Battery Pack ................22 8-1-3 Low Power Warning ..................22 8-1-4 Battery Power ....................22 8-1-5 Store the Battery Pack ..................22 8-1-6 Prolonging the Battery’s Life ................23 8-2 Power Management Modes ..................23 8-2-1 Standby mode....................23 8-2-2 Suspend mode....................23...
-
Page 4: Safety Precautions
Safety Precautions DO NOT press or touch the LCD Screen. DO NOT place the Notebook PC with small items, they may scratch LCD Screen or enter the Notebook PC. DO NOT expose the Notebook PC to dirty or dusty environment. Keep the environment clean and dry. - Page 5 Notice for the USA FCC Part 15: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 6: Knowing Your Notebook Pc
1 Knowing Your Notebook PC 1-1 Top Side Built-in Camera Click Fn+Num Lk to turn on the light Click Fn+F1 to turn on or turn off and the numeric keypad is the camera function. unlocked. LCD Screen Cap Lock Indicator Power button Light is green when the cap keypad Keyboard... -
Page 7: Right Side
1-2 Right Side SD/MMC/MS Port USB Port (2.0) VGA Port Lock Port 1-3 Left Side Power Jack Ethernet/LAN Port USB Port (2.0) Headphone Jack Microphone Jack Express Card Port The USB card can only be inserted in one orientation. Force to insert the card may in result of damage. -
Page 8: Caring The Notebook Pc
2 Caring the Notebook PC The Notebook PC is a precision device; the error operation may damage the device. 2-1 LCD Screen LCD Screen is the most delicate component of the Notebook PC and comprised of thin glass. It may be broken up by external abrupt force. DO NOT scratch the cover of the Notebook PC, or the scrape on the cover cannot remove. -
Page 9: Battery Pack
2-3 Battery Pack Please recycle the Battery Pack, and check with your Local Authority or retailer for recycling advice. DO NOT put the Battery Pack near or into the fire, or else it may cause fire or explode. ... -
Page 10: If The Water Comes Into The Notebook Pc
2-7 If the water comes into the Notebook PC DO NOT turn on the Notebook PC immediately. Disconnect the outlet cable and detach the Battery Pack in order to turn off the Notebook PC, instead of pressing the POWER button to turn off it. Disconnect all external devices. -
Page 11: Traveling With The Notebook Pc
3 Traveling with the Notebook PC Turn off the Notebook PC and disconnect all lines before moving it. Following the below steps, if you want to travel with your Notebook PC. 3-1 Attention Charge the Battery Pack and the spare Battery Pack fully. Turn off the Notebook PC and disconnect from the wall outlets. -
Page 12: Keep The Data For Future Possible Use
4 Keep the data for future possible use Your computer has been fully tested and complies with the system specifications before shipping. However, incorrect operations, mishandling or any other reasons may loss your data, e.g.: Delete or cover the data by error, Damage the HDD by vibration, Damaged by Network virus, Disaster, Loss the data because of being stolen. -
Page 13: Getting Started
5 Getting Started 5-1 Install the Rechargeable Battery Power the Notebook PC before using it. There are two ways to power the Notebook PC: Use the AC Adapter to power it or use the removable Battery Pack. The Notebook PC is designed to work with a removable Battery Pack. Your Notebook PC may or may not have its Battery Pack installed. -
Page 14: Connecting The Power Adapter
5-3 Connecting the Power Adapter The Notebook PC comes with a universal AC-DC adapter and the allowable input voltage of adapter is from 100V to 240V. Following the below steps to connect the adapter: Take the adapter and the power cord, and then connect the adapter with the power cord. -
Page 15: Using Your Notebook Pc
6 Using Your Notebook PC 6-1 Turning on the Notebook PC Open the LCD screen and adjust the angle of the Notebook PC’s LCD Screen Press the POWER button to turn on the Notebook PC. 6-2 Adjust the Brightness of LCD Screen The Notebook PC uses an active matrix TFT LCD and provides a Display (Monitor) Output Port to connect the external monitor. -
Page 16: Card Reader Usage
Function Keys These function keys with the color word or icon sign means that their function only can be activated when clicking the function key and the <Fn> key at the same time. <Fn>+<F1>：Turn on or turn off the camera window. ... -
Page 17: Internet Connection
7 Internet Connection 7-1 Connecting with the network via Wired LAN You can go online automatically that the Notebook PC can auto search an IP address to wired network connection with a DHCP server; otherwise, you can also take the following operation: Before connecting the network with your computer, setup your network system first, and then connect telecommunication line to your Notebook PC. -
Page 18: Wireless Lan
Wireless LAN Your Notebook PC comes with a built-in Wifi wireless card that you can click <Fn>+<F2> to turn the wireless network on or off. When the wireless network turns on, the WIFI Indicator turns on and the icon of WIFI will display on the right-bottom corner of the desktop. -
Page 19: Dsl
Wireless Security On the menu, choose the right encryted way in “Security”. See as right: IPv4 Settings On the menu, input the correct IP address, subnet masks, default gateway, DNS and ect. See as right: Click OK to start connection after finished the settings and click the icon in the right-bottom corner of the screen to check if the connection is successful or not. -
Page 20: The Wireless Lan Express Card
On the above menu, select one way to connect the network ---“DSL” and click “Edit” in the list to enter the ”Editing DSL connection 1” as shown right: On the menu, input the related address and the information according to the indication. Click OK to start the connection after setting. -
Page 21: Power Managing System
8 Power Managing System 8-1 Battery System The Notebook PC is designed to work with a removable and high capability Battery Pack. 8-1-1 Checking Battery Power Click the right button of the mouse on the icon to show the KPowersave menu as shown below: On the menu, click “Configure KPowersave”... -
Page 22: Charging The Battery Pack
The Battery Pack has limit on the number times it can be recharged. In any case, the Battery Pack’s usage time will eventually decrease and a new Battery Pack must be purchased from an authorized dealer for this Notebook PC. 8-1-2 Charging the Battery Pack When you use your Notebook PC first time, check the remaining battery power, and make sure that the new Battery Pack has been completely charged before the Notebook... -
Page 23: Prolonging The Battery's Life
8-1-6 Prolonging the Battery’s Life Use the AC adapter wherever the AC wall outlet is available. Charge the battery completely for using in your traveling. Take the card from the Express Card port when the Notebook PC does not connect to the electric outlets in order to save the power of Battery Pack. -
Page 24: Restart The System
If the system is force to turn off because of using up the power in the standby mode. Your current data and status will be stored on the HDD. The system will operate again after changing a power-full battery or connecting the wall outlets. When the power is used up, the Notebook PC will exit the standby mode and turn off. -
Page 25: Upgrading Your Notebook Pc
9 Upgrading Your Notebook PC 9-1 Connect the External Monitor The Notebook PC supplies a VGA port for connecting External Monitor or projective device. 9-1-1 How to connect the External Monitor Turn off the Notebook PC and insert the 15-pin D-sub monitor plug to the external monitor. -
Page 26: Lock Port
9-1-4 Lock Port The Lock Port allows the Notebook PC to be secured using and can prevent the Notebook PC to be removed from a fixed object. 9-2 Enter the BIOS Setup Menu Follow the below steps to enter the BIOS Setup Menu: Click F2 button quickly during loading the system, then the system will enter “Setup Utility”... - Page 27 Click the up/down direction keys to select “Boot Type Order” and click the Enter button to enter the below menu: Click the “Shift” + ”+” / ”-“ to remove the item position and then click the up/down direction button to select the startup option. Proceed to click F10 to popup the dialogue box and select “Yes”...
-
Page 28: Appendix
10 Appendix 10-1 Troubleshooting Q1：How to turn off the Notebook PC when the halted system cannot warm boot? A：Press the POWER button and hold 4 or 6 seconds to turn off the Notebook PC. Q2：How to check the Notebook PC if the Notebook PC cannot be turned off? A：1.If the power is low, connect to the electric outlets. - Page 29 Q6：How to check the system which cannot recover? A：1.Remove the external devices and their device program. 2.Refresh BIOS system 3.Refresh the appropriate program. 4.Remove the error application program. 5.Reinstall the operating system. 6.Send back the Notebook PC for checking. Q7：How to prolong the life of the Battery Pack? A：...
-
Page 30: Specifications
10-2 Specifications Main Feature Intel Atom N270 CPU Power Consumption 2.5W Clock Rate (#) 1.6GHz Front Side Bus Speed 400/533-MHz FSB support On-die, primary 32-kB instructions cache and L1 Cache Size 24-kB, write-back data cache L2 Cache Size 512-kB on-die second level cache Memory (#) Min 128 MB Max 2GB Memory Type... - Page 31 Resolution 640*480 Video/Audio Feature Video Card Type Integrate video card Video Card Capacity Share Dynamic EMS Memory 128MB(Max) Audio System Built-in speaker Sound Card Type HD Codec Network Card 100Mbps I/O Device Mouse Touch Pad Keyboard U.S 85-key keyboard Condition Operating Temperature 5-35℃...
- Page 32 Voltage 7.4V Port Standard LAN Type：10/100Base-T Port：RJ45 Headphone Port, Speaker, Built-in Microphone, Audio Port Microphone Port USB Port USB-A Port(x3)，USB2.0 SD Card Port Support SD/MMC/MS Card Express Card Port Express Card/34 VGA Port D-15 Output Physical Features No battery About 1.1Kg Weight With battery About 1.3Kg...
