DW200C manual
Product Name：2.4GHz Wireless digital AV transmitter
Product Model：DW200C
1

Introduction

This mini size product adopt with an advanced microwave and wireless transfer
technology developed and manufactured by 2.4GHz wireless digital receiving
modules, which has a stable performance and strong anti-interference function.
This product can be used for wireless cameras to record wireless camera signals.
2

Main features..

Digital 2.4G wireless modules.
2.1
Support A/V output
2.2
Support AE and AWB
2.3
Transmission distance up to 100M ( open space )
2.4
M-JPEG format Compression
2.5
Support 2 times digital zoom
2.6
3

Camera Installation

DC 5V input
3.1
Pairing button
3.2
Press the Pair the button on camera and wait for a while, the monitor
which connected to the corresponding receiver will appear the image
from the camera that have matched. Pairing succeeded.
4

Troubleshooting

Symptom
The power does
not turn on.
No image display
on monitor
Remedy
Check that the AC power cord is connected securely.
(In case of power failure) Check the breaker.
Check if Monitor it is on and work under NTSC / PAL
model
Check monitors video cable and connections.
