Blocked for new applications / Für Neuanwendung gesperrt
Pump safety block
Types DBA, DBAW, DBAE(E)
Sizes 6, 25, 32
Component series 2X
Maximum operating pressure 350 bar
Maximum flow 400 l/min
Table of contents
Content
Features
Function, sections
Technical data
Unit dimensions
Permissible pumps
Type-tested safety valves of type DBA...E,
component series 2X, according to Pressure Equipment
Directive 97/23/EC
(in the following, "PED" in short)
Features
Page
- Pressureless start-up and circulation of the pump
- Provided for direct mounting to the SAE pressure port of the
pump
2, 3
- Low circulation pressure due to short distance
4
- Small compressive volume, hence smooth change-over to
4
pressureless circulation
5
- Fast pressure build-up
6 to 8
- 4 pressure adjustment elements, optional:
9 to
• Rotary knob
2
• Sleeve with hexagon and protective cap
• Lockable rotary knob with scale
3
• Rotary knob with scale
3, 4
- 5 pressure ratings, optional
5 to 20
- Low noise level due to direct flange-mounting to the pump
2, 22
23
24
24
Information on available spare parts:
www.boschrexroth.com/spc
25, 26
RE 25890/07.07
Replaces: 07.03
H5872
/26
Advertisement
Table of Contents
Summary of Contents for REXROTH DBA Series
-
Page 1: Table Of Contents
Blocked for new applications / Für Neuanwendung gesperrt Pump safety block RE 25890/07.07 /26 Replaces: 07.03 Types DBA, DBAW, DBAE(E) Sizes 6, 25, 32 Component series 2X Maximum operating pressure 350 bar Maximum flow 400 l/min H5872 Table of contents Features Content Page... -
Page 2: Ordering Code
Blocked for new applications / Für Neuanwendung gesperrt 2/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Ordering code Pump safety block Without directional valve = No code With built-on directional valve (data sheet RE 2378) With built-on proportional pressure relief valve for external control electronics, valve type DBET-5X/…-27... - Page 3 Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 3/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Further details in clear text Type test No code = Without type test Type-tested safety valve according to PED 97/23/EC Seal material...
-
Page 4: Mating Connectors
Blocked for new applications / Für Neuanwendung gesperrt 4/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Mating connectors to DIN EN 7530-803 for plug-in connector “K4“ For details and further mat- ing connectors, see RE 08006 Material no. -
Page 5: Variant Code
Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 5/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Variant code 4,5,6 5 AF – 2X/ 50 – * E G … *** W 25 BH 2 D 00 Z 6... -
Page 6: Examples Of Possible Symbols 6 To
Blocked for new applications / Für Neuanwendung gesperrt 6/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Examples of possible symbols: (selection) for fixed displacement pumps Type DBA…2X/… Type DBAW.B…2X/.Z Type DBAW.A…2X/… Type DBAE(E)…2X/… Type DBAW.B…2X/… Attention! Port Y of the DBET valve on the DBA block must be connected at zero pressure to the tank! (If required, via leakage line of the hydraulic system.) - Page 7 Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 7/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Examples of possible symbols: (selection) for variable displacement pumps – Preferably for A0VSO with DR, DFR or DFLR controller Type DBAW.B…2X/…A08 Type DBAW.B…2X/.Z…A08 Type DBAE(E)…2X/…A08...
- Page 8 Blocked for new applications / Für Neuanwendung gesperrt 8/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Examples of possible symbols: (selection) for variable displacement pumps – Preferably for A0VSO with DRG controller Type DBAW.B…2X/.Z…A00 Type DBAW.B…2X/.ZZ…A00 Type DBAE(E)…2X/…A00...
- Page 9 Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 9/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Function, sections: Type DBA… General In the basic version, the porting pattern of size 6 is covered by cover plate (4). The pressure applied in the passage connec- Pump safety blocks of type DBA…...
- Page 10 Blocked for new applications / Für Neuanwendung gesperrt 10/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Function, sections: Type DBAW… Pump safety block type DBAW Pressure relief valve type ZDB 6 (6) to RE 2575 and the op-...
- Page 11 Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 11/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Function, sections: Type DBAE(E)… Pump safety block type DBAE(E) for fixed displacement Pump safety block Type DBAE(E) for variable displacement pump (with proportional pressure relief valve) pump type A0V..
- Page 12 Blocked for new applications / Für Neuanwendung gesperrt 12/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Technical data (for applications outside these parameters, please consult us!) General Size Size Weight With SAE flange 3000 5000 3000 5000 3000 5000 –...
-
Page 13: General Notes 3
Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 13/26 RE 25890/07.07 DBA, DBAW, DBAE(E) General notes – With types DBAW.B and DBAE/DBAEE the lowest settable pressure (circulation pressure) is set in the event of a power failure, and type DBAW..A changes over to the pressure... -
Page 14: Characteristic Curves 3, 4
Blocked for new applications / Für Neuanwendung gesperrt 14/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Characteristic curves (measured with HLP46, ϑ = 40 °C ± 5 °C) Minimum set pressure and circulation pressure in dependence on the flow Standard version Types DBA…... - Page 15 Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 15/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Unit dimensions: Type DBA… (dimensions in mm) 34,5 32,5 26,3 0,01/100 Rtmax 4 Required surface quality of For explanations of items, see page 20 valve mounting face Standard flanges type DBA…F…...
- Page 16 Blocked for new applications / Für Neuanwendung gesperrt 16/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Unit dimensions: Type DBAW… (dimensions in mm) 0,01/100 Rtmax 4 Required surface quality of valve mounting face For explanations of items, see page 20 For dimensions for –...
- Page 17 Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 17/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Unit dimensions: Type DBAW…Z… (dimensions in mm) 0,01/100 Rtmax 4 Required surface quality of valve mounting face For explanations of items, see...
- Page 18 Blocked for new applications / Für Neuanwendung gesperrt 18/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Unit dimensions: Type DBAE(E)… (dimensions in mm) For explanations of items, see page 20 For dimensions for – pump safety block, – pressure switch type HED 8 and –...
- Page 19 Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 19/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Unit dimensions (dimensions in mm) Standard flanges type DBA…F… to DIN ISO 662- Permissible pressures Ports 4 valve mounting screws Tightening ISO 4762 - 10.9...
- Page 20 Blocked for new applications / Für Neuanwendung gesperrt 20/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Unit dimensions: Explanations of items 1 Nameplate 17 Dimension for solenoid with concealed manual over- ride “N9“ (standard) – the manual override can only 2 Cover plate type HSA 06 A00-3X…...
- Page 21 Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 21/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Permissible pumps: Standard flange (3000 psi) Pump safety block Size 16 Size 25 Size 32 Port P SAE 3/4“ SAE “ SAE /4“...
-
Page 22: Permissible Pumps 2
Blocked for new applications / Für Neuanwendung gesperrt 22/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Permissible pumps: High-pressure flange (5000 psi) Pump safety block Size 16 Size 25 Size 32 Port P SAE 3/4“ SAE “ SAE /4“... -
Page 23: Ordering Code
Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 23/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Ordering code: Type-tested safety valves of type DBA…E, component series 2X according to Pressure Equipment Directive 97/23/EC Permissible Set re- max. flow q... -
Page 24: Deviating Technical Data
Blocked for new applications / Für Neuanwendung gesperrt 24/26 Bosch Rexroth AG Hydraulics DBA, DBAW, DBAE(E) RE 25890/07.07 Safety notes: Type-tested safety valves of type DBA…E, component series 2X according to Pressure Equipment Directive 97/23/EC – Before ordering a type-tested safety valve, please note that... - Page 25 Blocked for new applications / Für Neuanwendung gesperrt Hydraulics Bosch Rexroth AG 25/26 RE 25890/07.07 DBA, DBAW, DBAE(E) Safety notes: Type-tested safety valves of type DBA…E, component series 2X according to Pressure Equipment Directive 97/23/EC Permissible maximum flow q in dependence on backpressure p...
-
Page 26: Characteristic Curves
© This document, as well as the data, specifications and other information Hydraulics set forth in it, are the exclusive property of Bosch Rexroth AG. It may not be Zum Eisengießer reproduced or given to third parties without its consent. - Page 27 © This document, as well as the data, specifications and other information Hydraulics set forth in it, are the exclusive property of Bosch Rexroth AG. It may not be Zum Eisengießer reproduced or given to third parties without its consent.
- Page 28 © This document, as well as the data, specifications and other information Hydraulics set forth in it, are the exclusive property of Bosch Rexroth AG. It may not be Zum Eisengießer reproduced or given to third parties without its consent.
