Summary of Contents for Vitrum Clima
- Page 1 Clima controller Temperature Controller Clima Control in style. Product Handbook.
-
Page 2: Table Of Contents
SUMMARY General Introduction Product and functional overview General Parameter configuration Right Button configuration Central/Left button Activation on press/edge Actiovation short/long press Input: Dimming Input: Shutter and Blind Input: Scene Management Commands in Sequence Temperature sensor function Thermostat function Target Setpoint Settings Two Points on-off On-off with PMW control Fan coil on-off... - Page 3 Any information inside this manual can be changed without advice. Exclusion of liability: Despite checking that the contents of this document match the hardware and software, deviations cannot be completely excluded. We therefore cannot accept any liability for this. Any necessary corrections will be incorporated into newer versions of this manual. Symbol for relevant information Symbol for warning SIMPLY INIMITABLE.
-
Page 4: General Introduction
General Introduction • 1 byte commands (unsigned 0-255 or HVAC commands or value % commands). • Sending of long action telegrams on the same address of This manual is intended to be used by installers short action or on a different group address and describes functions and parameters of the •... -
Page 5: General Parameter Configuration
General Parameter Configuration KNX PARAMETER SETTINGS KNX PARAMETER SETTINGS Value associated with Delay on Power-up 5 ÷ 15 seconds 0-100% backlight ON mode [0..100%] Through this parameter is possible to set the delay of tran- With this parameter, during the ETS configuration, you can smission of telegrams after a power on by selecting the time set the brightness of backlight of the button when value is by which the device is allowed to send telegrams. -
Page 6: Right Button Configuration
Right button configuration The right button of the glass room temperature KNX PARAMETER SETTINGS controller can be configured to perform the “fun- ction mode” or “nothing” 0,3 sec Minimum time long 0,5 sec press input KNX PARAMETER SETTINGS 0,8 sec 1,0 sec nothing 2,0 sec... - Page 7 • Note 1: • If you enable the sending of the telegram for button • Toggle where you have already set the cyclic sending ; then the cyclic sending will start automatically at power on; at the end of the fi rst period. Confi gurations for 1 bit object in events of pressing or releasing the button: Note 2:...
-
Page 8: Input: Dimming
Input: Dimming Through the dimming function it’s possible to KNX PARAMETER SETTINGS control a light dimmer using short & long press of a button. Each button uses 2 communication objects: Scene Number Number of the • 1 bit dimension for ON /OFF command scene: associated to short press operation 0 ÷... -
Page 9: Commands In Sequence
Commands in sequence The function allows you to associate to short and long press, sequences of different commands on the bus. For inputs this function is available for short and long press or for toggle evaluation. The sequence consists of 2 or 3 commands which can each be sized as 1 bit or 1 byte. -
Page 10: Temperature Sensor Function
Temperature sensor Function It’s ‘possible to enable/disable the remote temperature sensor with a communication object. When this object is The temperature probe allows a reading of the tem- enabled and receives a telegram “1” the temperature probe perature within its range with resolution 0.1 ° C. is active and sends trigger telegrams according to thresholds T1 and T2 values;... - Page 11 Using the object HVAC MODE (1 byte size), you can set SETPOINT OBJECTS the thermostat in one of the following modes: OFF; ECONOMY; STANDBY; COMFORT; each mode is asso- ciated with a setpoint set by a ETS parameter. Telegram received on: Setpoint changed: OFF mode is associate to setpoint antifreeze in heating mode and high temperature protection in...
-
Page 12: Two Points On-Off
If the telegram received indicates that the window is Surveillance time for 10..255 (min) opened thermostat change its mode or setpoint after additional sensor 1 minute from the reception of the telegram. When it receive a telegram corresponding to state Whenever the thermostat receive a valid data from additio- “window closed”... -
Page 13: On-Off With Pmw Control
on/off control in heating mode: On/off with PWM control On/off with PWM control is an algorithm that reduces the eff ects of hysteresis around the set point value by adjusting the controls on the values ranging from 0% to 100% where 0% means “control off ” and 100% means “maximum control action”. -
Page 14: Fan Coil On-Off
PWM control in heating mode: Control logic for a 3 speed fan coil in heating: When temperature increasing Fan coil on/off Fan coil is a device that controls the fl ow of cooling / Where: heating liquid driving a valve (2-pipe fan coil) or two valves (4-pipe fan coil). -
Page 15: Fan Coil Control % ( Or Genric Continuous Control)
Control logic for a 3 speed fan coil in cooling: Fan coil control % When temperature decreasing (or generic continuous control) Logic and parameters are the same used in On/off with PWM control mode; the diff erence is that now the proportional value is sent to the bus via a 1 byte object format as a % value from 0% to 100%. - Page 16 CONFIGURATION MODE 1 CONFIGURATION MODE 3 Used Not used Internal probe Internal probe Disabled Connected or by bus Additional probe Additional probe NA. (100% internal) 100% external Ratio between probes Ratio between probes Measure of temperature is performed every 60 seconds; if If the additional temperature is out of range or the surveil- the temperature probe is disconnected or in short circuit the lance time expires without any message received, thermostat...
-
Page 17: Behavior Of Thermostat On Voltage Failure, Recovery And Commissioning
Behavior of Thermostat on voltage failure, Control Panel recovery and commissioning. Behavior on bus voltage failure The operator panel mode is used when the device behaves as a user interface while the temperature On failure of bus voltage no actions are executed by control function is delegated to another device or to the device;... - Page 18 THINK SIMPLE S.r.l. SEDE AMMINISTRATIVA E OPERATIVA Viale Lino Zanussi, 3 33170 Pordenone IT 0434 516216 0434 516230 SEDE LEGALE E COMMERCIALE Corso Garibaldi, 86 20121 Milano IT 02 65560029 02 45498295 info@thinksimple.it vitrum.com vitrumsense.com follow Vitrum...
