Protective Capony
RTC-15.3
ASSEMBLY AND OPERATION MANUAL
WARRANTY CARD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTC-15.3 and is the answer not in the manual?

Questions and answers

Summary of Contents for PERCo RTC-15.3

  • Page 1 Protective Capony RTC-15.3 ASSEMBLY AND OPERATION MANUAL WARRANTY CARD...
  • Page 2 Protective Canopy RTC-15.3 Assembly and Operation Manual Warranty Card...

  • Page 3: Table Of Contents

    Installation safety requirements..................6  6.2  Operational safety requirements ..................6  7  INSTALLATION WORK ......................7  7.1  General recommendations ....................7  7.2  Installation tools......................... 7  7.3  Canopy installation ......................7  8  TRANSPORTATION AND STORAGE .................. 10  9  WARRANTY PERCo ......................11 ...

  • Page 4: Application

    You have purchased a high quality product, which will be long lasting in operation provided that installation and operation rules are observed. The Operation Manual (the Manual) of the RTC-15.3 Protective canopy for the RTD-15 Full height rotor turnstile contains data on transportation, storage, installation, operation, maintenance and warranty of the product.

  • Page 5: Delivery Set

    Assembly and Operation Manual 4 DELIVERY SET 4.1 Standard delivery set Primary parts: Canopy’s half-frame #1......................1 Canopy’s half-frame #2......................1 Post ............................4 Jointing plate ........................... 1 Fasteners: Hex socket screw M6×20 ......................21 Hex socket screw M8×30 ....................... 8 Washer 6 ..........................16 Washer 8 ..........................

  • Page 6: Jointing Plate

    RTC-15.3 Protective Canopy Figure 2. The canopy design: 1 and 2– half-frames; 3 – post; 4 – bottom flange; 5 – top flange; 6 – jointing plate; 7 – drain...

  • Page 7: Safety Requirements

    Assembly and Operation Manual Figure 3. Mounting half-frames among themselves 6 SAFETY REQUIREMENTS 6.1 Installation safety requirements Installation of the canopy should be carried out by qualified personnel only, in strict accordance with this Manual and general requirements for installation work. Warning! While doing the installation work: ...

  • Page 8: Installation Work

    RTC-15.3 Protective Canopy 7 INSTALLATION WORK 7.1 General recommendations Warning! manufacturer will accept liability damage canopy or other equipment, or otherwise loss caused as a result of improper installation, and will dismiss any claims by the customer should the installation work be carried out not in accordance with this Manual.
  • Page 9 Assembly and Operation Manual Figure 4. Hole pattern for mounting of the canopy posts (3) relative to the turnstile mounting holes: A – mounting point of the turnstile barrier section. L – mounting point of the turnstile left guide barrier section. R –...

  • Page 10: Washer 6

    RTC-15.3 Protective Canopy 4. Set the anchors all the way down the prepared holes. Warning!  Further work should be carried out after installation of the RTD-15 turnstile.  Be particularly careful when installing parts of the canopy before they are secured in place, prevent the parts from fall.

  • Page 11: Transportation And Storage

    Figure 6 The top view of the connected half-frames #1 and #2 with the installed jointing plate The canopy is installed. Consult with PERCo Technical Support Department when necessary. 8 TRANSPORTATION AND STORAGE The canopy in the standard delivery set (Section 4) is packed in three transport boxes, which protect its components from damage during transportation and storage.

  • Page 12: Warranty Perco

    24 hours under operation conditions given in sect.2. 9 WARRANTY PERCo PERCo (the Manufacturer) warrants that the RTC-15.3 Protective Canopy for RTD-15 Full Height Rotor Turnstile (the Product) complies with applicable statutory safety requirements, electromagnetic compatibility provided that the instructions on storage, installation and operation, given in the Assembly &...
  • Page 13 SOPHISTICATED PRODUCTS THAT, IF NOT FAULTY, CANNOT BE RETURNED BACK IF BY SOME REASON THE CUSTOMER DEEMS THEM UNSATISFACTORY The PERCo RTC-15.3 Protective Canopy is in conformity with the essential requirements of the EU’s Machinery, Low-Voltage and EMC Directives and carries the CE marking accordingly.
  • Page 14 WARRANTY CARD RTC-15.3 Protective Canopy for RTD-15 Full Height Rotor Turnstile Date of manufacture: ____________________ 201___ Quality Control Seal _____________________________________________________________ Date of sale: « » ____________________ 201___ ____________________________________ (signature, seal)  Cutting line WARRANTY REPAIR COUPON RTC-15.3 Protective Canopy for RTD-15 Full Height Rotor Turnstile...
