Summary of Contents for Albixon UL-P100
- Page 1 POOL LIGHT UL - P100 (12V/75W) INSTALLATION AND USER GUIDE VERZE 13. 11. 2017 / REVIZE: 13. 11. 2017...
- Page 2 Preparatory steps must be performed by an electrician before installing the light: see picture 1. PIC. 1 Connecting box for the light (not included) Non-flexible conduit Water level There must be space for the compact sealing from the plaster around the recess in the concrete. 120 cm min.
- Page 3 After meeting requirements for the electrical electrical system, carry out the following steps 1. Find a place on the vertical wall where you want to install the light. The top edge of the lens should be placed 45 cm under the water level in the pool, see picture 1. 2.
- Page 4 Winterisation The light should remain in place during the winter. Light Mounting bracket Conduit Do not mount on surface with inverse radius Do not mount on irregular or uneven surface Mount on flat surface Mount on walls with a radius that is not less than 1.83 m when viewed from above Open position Closed position...
- Page 5 List of parts Item Amount Description Coloured shade Screw Cover frame Cover Lens Lens gasket Sealing nut with a screw Bulb 12 V/75 W Bulb holder Mirror Head with a recess O-ring seal Body Sealing nut with a screw Screw Lamp holder Bracket for attachment to the wall Pool light UL - P100 (12V/75W) /...
- Page 6 Warranty conditions Warranty conditions The warranty conditions are governed by the commercial and warranty conditions of your supplier. Safe liquidation of the product at the end of its useful life Once the product’s useful life has ended, please ensure its ecological liquidation by a specialised company. Complaints and Service Claims are governed by the relevant acts on consumer protection.
- Page 7 Notes Pool light UL - P100 (12V/75W) /...
- Page 8 Thank you for using ALBIXON products ALBIXON export@albixon.com www.ALBIXON.com Note that the photos used in the manual are illustrative only. Printing and typesetting errors reserved.
