Trough Collector
Trough Conveying and Food Waste Collecting System
2
3
Fabricator Instructions & Installation
4
5
Electrical & Operating Instructions
6
Troubleshooting & How it Works
7
8
FOR PRODUCT/WARRANTY REGISTRATION
•
Go to www.salvajor.com
•
Click on SUPPORT at the top of homepage
•
Click on PRODUCT REGISTRATION
4530 East 75th Terrace Kansas City, MO 64132-2081, USA
Toll Free: 1.888.725.8256
service@salvajor.com
Manufacturers of Commercial Food Waste Solutions - Since 1944
I
Fax: 1.800.832.9373
I
www.salvajor.com
Model S419
TM
ALL INSTALLATIONS SHOULD
BE MADE IN ACCORDANCE WITH
LOCAL AND NATIONAL PLUMBING
AND ELECTRICAL CODES.
Advertisement
Table of Contents
Related Manuals for Salvajor Trough Collector S419
Summary of Contents for Salvajor Trough Collector S419
- Page 1 Troubleshooting & How it Works Warranty General Terms and Conditions of Sale FOR PRODUCT/WARRANTY REGISTRATION • Go to www.salvajor.com • Click on SUPPORT at the top of homepage • Click on PRODUCT REGISTRATION Manufacturers of Commercial Food Waste Solutions - Since 1944 4530 East 75th Terrace Kansas City, MO 64132-2081, USA Toll Free: 1.888.725.8256...
- Page 2 System Components Collector Top Box x 12 Lockwasher (May ship separate) x 12 Hex Nut Diffuser Gusher Head Collector (Optional) Hardware Salvage Basin (Shipped inside of Tank) Scrap Basket (Shipped inside of Tank) Collector Top (May ship separate) Collector Hardware Collector Tank Note: Drain piping, recirculation piping and trough not furnished...
- Page 3 Fabricator Instructions Upon request, the Collector top may be shipped separately to a fabricator for welding to table. TABLE CUT OUT DETAIL FLANGE DIMENSIONS Weld the Trough Col- ø 20" lector top into the table ( ø 50.75) " using these dimensions ( 14.61 ) for the table cut out.
- Page 4 BLENDER CONNECTION CONNECTION WATER HARNESS DETAIL IMPORTANT! The Salvajor Trough Collector is 2" NPT DRAIN equipped with a UPC approved air gap, eliminating the need for vacuum breakers. MAKE ALL PLUMBING CONNECTIONS IN ACCORDANCE WITH NATIONAL AND LOCAL PLUMBING CODES.
- Page 5 Electrical ELECTRICAL Always use watertight The pump motor and solenoid are factory pre-wired. conduit and fittings Only one electrical connection is required if the control is when wiring this installed with the provided wiring and mount. Run power product. from the building source to the 1/2” knockout on the bottom of the control.
- Page 6 Troubleshooting WARNING! DISCONNECT THE POWER TO THE SYSTEM BEFORE SERVICING. This troubleshooting guide is to provide basic checks to facilitate problem isolation and repair. All repairs should be made according to local codes and by a qualified technician. PROBLEM POSSIBLE CAUSE SOLUTION Tank will not fill up.
- Page 7 United States, Hawaii and Canada. of the original disposer assembly or system package. Accessories not manufactured by Salvajor are covered for parts only. Accessories For your nearest and parts sold separately are covered for parts Factory Authorized Service Center:...
- Page 8 GENERAL TERMS AND CONDITIONS OF SALE These Terms and Conditions shall govern the transaction by and between The Salvajor Buyer agrees that in no event shall seller’s liability to buyer and/or its customers ex- Company (herein referred to as the “Seller”) and the customer or person or entity purchas- tend to include incidental, consequential or punitive damages.
