FB2
Floating
Quarter Turn Soft Seated
Ball Valves
2 Piece Valve
Storage, Installation, Operation
& Maintenance Manual
PUBLICATION No: JAG.FB2-IOM.Rev.0
Issued: 10/2012
Advertisement
Table of Contents
Summary of Contents for Jag FB2
- Page 1 12315 Parc Crest Dr. # 190 Stafford, TX 77477 USA tel. 1+ 281.933-5775 fax: 1+ 281.933.5779 Floating Quarter Turn Soft Seated Ball Valves 2 Piece Valve Storage, Installation, Operation & Maintenance Manual PUBLICATION No: JAG.FB2-IOM.Rev.0 Issued: 10/2012...
- Page 2 JAG flocomponents FB2 IOM 2012 INDEX OF CONTENTS SECTION 1: STORAGE SECTION 2: UNPACKING & INSPECTION SECTION 3: PRE-INSTALLATION SECTION 4; HANDLING SECTION 5: INSTALLATION SECTION 6: OPERATION SECTION 7: MAINTENANCE SECTION 8: MAINTENANCE KITS SECTION 9: SAFETY PRECAUTIONS BEFORE REMOVING VALVE FROM PIPELINE.
-
Page 3: Section 1 - Storage
JAG flocomponents FB2 IOM 2012 SECTION 1 - STORAGE Ensure end covers remain securely in place until the valve is ready for installation. Pre Despatch This will prevent ingress of dirt and damage to ball surface and end connection surface Non corrosion resistant valves shall be finish. -
Page 4: Section 6 - Operation
Each seat is made of RTFE or similar Seals. material. JAG valves are designed for ease of service The valve seals by pressure in the line and assembly in the field. The only pushing the ball into the opposite seat... - Page 5 JAG flocomponents FB2 IOM 2012 seat or ball necessitates dismantling the Fit cap (2) over studs (12) and replace and valve. tighten nuts (13). (See Section 11.1 for tightening torques); Leakage at Pipeline Joint: Test for tightness of flange bolting. If slack, tighten bolting to...
- Page 6 There can be no risk to health and safety when the valve is properly used. JAG flocomponents shall not be liable for any Failure/Damage/Injury where valve parts are not of the Company's original design or specification.
- Page 7 JAG flocomponents FB2 IOM 2012 SECTION 11 - VALVE FASTENERS 11.1 Valve Fasteners - Approximate Torque Values Bolt Size Material B7/L7 Material B7M/L7M 3/8” 16 UNC 33.50 ft/lbs 25.50 ft/lbs 1/2” 13 UNC 73.80 ft/lbs 36.40 ft/lbs 5/8” 11 UNC 149.00 ft/lbs...
- Page 8 JAG flocomponents FB2 IOM 2012 Page 8 of 8 www.JAGvalve.com JAG.FB2.IOM.Rev.0...
