Wiseup WIFI28 User Manual

Hide thumbs Also See for WIFI28:

Advertisement

Quick Links

Download this manual See also: User Manual
I. Product Review
1
1. Camera Lens
2. MODE
3. SET
4. Indicator Light
5. Power Switch
6. USB Port
7. Time Voice Chime
II. Prepare the Camera
2.1 Please connect the camera to an external DC5V 2A power source.

User Manual

Model Number: WIFI28
(IOS Version)
2
3
4
5
6
MODE
DOWN
SET
UP
TF
USB
ON/OFF
8. UP
9. DOWN
10. Time Set
11. Camera Switch
12. Reset
13. Micro SD Card Slot
7
8
9
TIME
10
11
RESET
12
13

Advertisement

loading
Need help?

Need help?

Do you have a question about the WIFI28 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wiseup WIFI28

Summary of Contents for Wiseup WIFI28

  • Page 1: User Manual

    User Manual Model Number: WIFI28 (IOS Version) I. Product Review TIME MODE DOWN RESET ON/OFF 1. Camera Lens 8. UP 9. DOWN 2. MODE 10. Time Set 3. SET 4. Indicator Light 11. Camera Switch 12. Reset 5. Power Switch 6.
  • Page 2 AC90-250V Outlet Power Supply 2.2 Insert a micro sd card into the sd card slot, make sure the memory card is formatted and the memory capacity is under 32GB. We suggest you to use a micro SDHC class 10 memory card. TIME MODE DOWN...
  • Page 3 III. Network Configuration 3.1 LAN（P2P）Mode Setting 3.1.1 Slide the power switch to the "on" position. TIME MODE DOWN RESET ON/OFF 3.1.2 Press the camera switch button till you see the blue indicator light is solid on. TIME MODE DOWN RESET ON/OFF 3.1.3 Search for the camera wifi signal on your IOS mobile device after 3 minutes, the SSID name should start with CM-*******.
  • Page 4 AT&T 11:57 AM WLAN Settings Wi-Fi CM6F48-5185029FC4B1-86F4A1 3.1.4 Run the APP P2PLiveCam. AT&T 11:57 AM P2PLiveCam...
  • Page 5 3.1.5 Add this camera to the APP P2PLiveCam. AT&T 11:57 AM AT&T 11:57 AM AT&T 11:57 AM < < P2PLiveCam Back Add Device Back Add new online device Add new online Camera Name Setup device WiFi connection Password i,APP VERSION: 2.0.1 Search(LAN) ii,OS VERSION: 12.1 QR Scan...
  • Page 6 3.1.6 The P2P set is successful when you see the camera stay online and this camera is added to your IOS mobile device. CM6F48-5185029 AT&T 11:57 AM Online P2PLiveCam CM6F48-5185029FC4B1-86F4A1 Online Live video Snapshots Recordings Alarms 3.2 WAN (Remote View) Mode Setting 3.2.1 After the LAN(P2P) mode set successfully, make sure this camera is stay online.
  • Page 7 3.2.2 Enter the camera OSD menu, select " Device Settings". AT&T 11:57 AM AT&T 11:57 AM P2PLiveCam P2PLiveCam CM6F48-5185029FC4B1-86F4A1 CM6F48-5185029FC4B1-86F4A1 Online Online Modify Device Delete Device Reconnect Device Settings Cancel Live video Snapshots Recordings Alarms Live video Snapshots Recordings Alarms 3.2.3 Tap "WiFi Config"...
  • Page 8 AT&T 11:57 AM AT&T 11:57 AM < < Back WiFi Config Back Device Settings Current WiFi network Alarm Config Select the network you want to con... WiFi Config SSID-1 Are you sure to connect network SD Card Record Config SSID-1 (Password:gomyhome 2016)? Device reboot Cancel PTZ Config...
  • Page 9 AT&T 11:57 AM AT&T 11:57 AM WLAN WLAN Settings Settings WLAN WLAN SSID-1 SSID-2 CHOOSE A NETWORK... CHOOSE A NETWORK... SSID-2 SSID-1 SSID-3 SSID-3 SSID-4 SSID-4 Other... Other... AT&T 11:57 AM AT&T 11:57 AM AT&T 11:57 AM WLAN Settings Cellular Settings Settings WLAN...
  • Page 10 3.2.6 Run APP P2PLiveCam again, if you see this camera is stay online, that means the WAN mode setting is successfully and you could remote view this camera with no distance limitation. CM6F48-5185029 AT&T 11:57 AM AT&T 11:57 AM Online P2PLiveCam CM6F48-5185029FC4B1-86F4A1 P2PLiveCam...
  • Page 11 4.2 Enter the camera OSD menu, select "Device Settings", then select "Alarm Config". AT&T 11:57 AM AT&T 11:57 AM AT&T 11:57 AM < P2PLiveCam P2PLiveCam Device Settings Back CM6F48-5185029FC4B1-86F4A1 CM6F48-5185029FC4B1-86F4A1 Online Online Alarm Config WiFi Config SD Card Record Config Modify Device PTZ Config Delete Device...
  • Page 12 AT&T 11:57 AM AT&T 11:57 AM < < Back Alarm Config Back Alarm Config Motion detection sensitivity Disabled Warning Tone Alarm Schedule Email Alert Warning Tone FTP Upload Email Alert disabled Back to Preset Alarm interval FTP Upload 30--240 second Disabled Back to Preset Alarm interval...
  • Page 13 4.5 When the alarm is triggered by the motion detection, you will receive a push notification, and you can check the snapshots by tapping "Alarms" on the bottom of the APP screen. AT&T 11:57 AM AT&T 11:57 AM P2PLiveCam Alarms <All camera>...
  • Page 14 5.2 Tap this camera on the list to check the live video. 11:57 AM P2PLiveCam CM6F48-5185029FC4B1-86F4A1 Online Snapshot Record Alarm 5.3 Record audio and video remotely on the APP. AT&T 11:57 AM AT&T 11:57 AM < < P2PLiveCam Live video P2PLiveCam Live video Live video...
  • Page 15 5.4 Check the video files on your IOS mobile device. AT&T AT&T AT&T 11:57 AM 11:57 AM 11:57 AM < P2PLiveCam Recordings Back Live video Local Camera Download CM6F48-5185029FC4B1-86F4A1 This week, Online Nov 23,2018 at 10:24:06 Nov 23,2018 at 10:21:44 AM, 0.32MByte AM, 0.19MByte Last week,...
  • Page 16 6.2 Enter the camera OSD menu, select "Device Settings", then select" SD Card Record Config". AT&T AT&T AT&T 11:57 AM 11:57 AM 11:57 AM < P2PLiveCam P2PLiveCam Device Settings Back CM6F48-5185029FC4B1-86F4A1 CM6F48-5185029FC4B1-86F4A1 Online Online Alarm Config WiFi Config SD Card Record Config Modify Device PTZ Config Delete Device...
  • Page 17 6.4 Tap "OK" to finish the setting. AT&T 11:57 AM < Back SD Card Record Config Free space:14525 MBytes Record has stopped On alarm Record Resolution File length(minute) 1-60 Minute Record sound Loop recording Cancel Live video Snapshots Recordings Alarms VII.
  • Page 18 VIII. Rename 8.1 Run app P2PLiveCam in the LAN mode, make sure this camera stay online. CM6F48-5185029 AT&T 11:57 AM AT&T 11:57 AM Online P2PLiveCam CM6F48-5185029FC4B1-86F4A1 P2PLiveCam Online Live video Snapshots Recordings Alarms 8.2 Rename the camera as below. AT&T 11:57 AM AT&T 11:57 AM...

  • Page 19: Change Password

    AT&T 11:57 AM AT&T 11:57 AM < < Back Back Name Name Home CM6F48-518502 CM6F48-518502 Password Password Search(LAN) Search(LAN) QR Scan QR Scan Cancel Cancel Live video Snapshots Recordings Alarms Live video Snapshots Recordings Alarms IX. Change Password 9.1 Option 1 9.1.1 Tap the camera on the list, tap "Change"...
  • Page 20 9.1.2 Change the password as below and then tap "OK" to save the change. AT&T 11:57 AM AT&T 11:57 AM AT&T 11:57 AM < < < Back Change password Back Change password Back Change password Current Password Current Password Current Password New password New password New password...
  • Page 21 9.2.2 Enter the default password "8888", input a new password, tap "OK" to save the change. AT&T 11:57 AM AT&T 11:57 AM < < Back Change password Back Change password Current Password Current Password New password New password New password Confirm password Confirm password Confirm password...
  • Page 22 X. Time Set Important: the clock camera will back to factory default setting and clock time will display 12:00 after each reboot. TIME MODE 12 00 DOWN RESET ON/OFF 10.1 Press SET button, year display will flash. 20 10 TIME MODE DOWN RESET...
  • Page 23 20 18 TIME MODE DOWN RESET ON/OFF 10.3 Press SET again to save year, month display will flash. TIME MODE DOWN RESET ON/OFF 10.4 Press UP or DOWN to set month. TIME MODE DOWN RESET ON/OFF...
  • Page 24 10.5 Press SET again to save month, date display will flash. TIME MODE DOWN RESET ON/OFF 10.6 Press UP or DOWN to set date. TIME MODE DOWN RESET ON/OFF 10.7 Press SET again to save date, hour display will flash. 12 00 TIME MODE...
  • Page 25 10.8 Press UP or DOWN to set hour. 13 00 TIME MODE DOWN RESET ON/OFF 10.9 Press SET again to save hour, minute display will flash. 13 00 TIME MODE DOWN RESET ON/OFF 10.10 Press UP or DOWN to set minute. 13 01 TIME MODE...

  • Page 26: Alarm Setting

    10.11 Press SET again to save minute. 13 01 TIME MODE DOWN RESET ON/OFF XI. Alarm Setting 11.1 Press MODE once to start setting. If you see " - ： -", that means alarm is turned off. TIME MODE DOWN RESET ON/OFF 11.2 Press UP button to turn on or turn off alarm.
  • Page 27 TIME MODE 0 00 DOWN RESET ON/OFF 11.3 Press SET button once, hour display will flash. TIME 0 00 MODE DOWN REST ON/OFF 11.4 Press UP or DOWN to set hour. 1 00 TIME MODE DOWN RESET ON/OFF...
  • Page 28 11.5 Press SET button again to save hour, minute display will flash. 1 00 TIME MODE DOWN REST ON/OFF 11.6 Press UP or DOWN to set minute. 1 01 TIME MODE DOWN RESET ON/OFF 11.7 Press SET button again to save minute. TIME MODE DOWN...
  • Page 29 11.8 Press UP or DOWN to set snooze function, the setting range is 1-60 minutes. TIME MODE DOWN RESET ON/OFF 11.9 Press SET button again to save snooze setting. TIME MODE DOWN RESET ON/OFF 11.10 Press UP or DOWN to set alarm tone, there are 6 tones in total. TIME MODE DOWN...
  • Page 30 11.11 Press SET button again to save tone setting. 1 01 TIME MODE DOWN RESET ON/OFF 11.12 Press MODE button to exit alarm setting. 13 05 TIME MODE DOWN RESET ON/OFF...
  • Page 31 XII. 12/24 Hour Format Setting Press UP button to switch 12/24 hour display format when the clock is powered on. 13 05 TIME MODE DOWN 1 05 RESET ON/OFF XIII. Time Voice Chime Function Press Time Voice Chime button to hear the current time when the clock is powered on. TIME MODE DOWN...
  • Page 32 XIV. Nature Sound Player Setting 14.1 Press TIME button to enter the nature sound player setting when the clock is powered on. TIME MODE DOWN RESET ON/OFF 14.2 Press TIME button again to set the play time, the time range is 10-60 minutes. TIME MODE DOWN...
  • Page 33 -The End-...
